Let's get started!

Read through all of
the instructions
before starting
Approx. 60 minutes
assembly time
2 people recommended
for assembly
Furniture components:
1 Top Board
2 Bottom Board
3 Left Side Board
4 Right Side Board
5 Middle Support
6 Backboard
Provided hardware:
A Cam Lock Ø15 mm
B Cam Bolt Ø7.5 x 32 mm
C Cam Cover Ø17 mm
D Plastic Dowel Ø6 x 30 mm
E Screw M 6 x 8 mm
F Screw M 6 x 13 mm
G Screw M 4 x 19 mm
H Screw M 10 x 33.5 mm
Missing parts or hardware? Need assistance?
Contact us before returning your item. We're here to help!
609.256.9000 • cs@modway.com
Care instructions are
listed in the last step
of this manual
Make sure you have all
parts and components
before discarding any
packing materials
7 Leg
x1
8 Drawer Front Board
x1
9 Drawer Back Board
x1
10 Drawer Left Board
x1
11
x1 Drawer Right Board
x1 12 Drawer Bottom Board
x6 I
x10 J
x6 K
x26 L
x12 M
x8
N
x16 O
x8
Only use hand tools to assemble this item. Do not use power tools.
Do not tighten bolts or screws completely until all hardware is lined up
and inserted into the holes.
Do not over-tighten screws and bolts to avoid stripping the hardware
or cracking the item.
Assemble your item on a fl at, carpeted area, with plenty of space to work.
This will prevent damage and scratches to your fl oors or the item while
you're assembling the product.
Keep all components and packaging out of reach of children or animals
to avoid risk of choking or suff ocation.
x4
x2
x2
x2
x2
x2
Sleeve Nut x4
Backply Stopper x16
Push to Open x2
Allen Key x1
Drawer Runner
x2
Cam Lock Ø12 mm x4
Cam Cover Ø15 mm x4

What you need:

Phillips Head Screwdriver
Phillips
