Audibax AT2020 User Manual

USER MANUAL
AT2020
BROADCASTING AND RECORDING MICROPHONE
This is a cardioids polar pattern microphone, which means it records in one direction. Adopts the
exacting complete electronic circuit control and a well sound capturing capsule, low self-noise.
and the accurate reproduction of even the most subtle sound, suitable for game streaming,
vocals, podcasting, voiceover, Skype/VoIP, and instruments.it can fulfill the requirement of your
needs.

Specification:

Element: Φ 16 Pressure Gradient Transducer
Polar Pattern: Cardioids
Frequency Response: 50Hz-20kHz
Sensitivity: -43dB±3dB (0dB=1V/Pa at 1kHz)
Output Impedance: < 2.2KΩ (at 1kHz)
Operating voltage:1-10V
Max. SPL: 120dB (at 1kHz ≤ 1% T.H.D)
S/N Ratio: 66dB
Electrical current: 3mA

Helpful Tips

• Aim the microphone toward the desired sound source (such as the gamer, streamer, rage
quitter talker, singer, or instrument)
• Aim the microphone away from fans, air conditioners, PC fans, keyboards, mice, and anything
else that may pick up noise
• Place the microphone as close as practical to the desired sound source, it is recommended
that you use the microphone arm if you can as this will provide the best results
• Work close to the microphone for extra bass response. (You know you are too close when you
are getting pops in your audio (AKA Plosives)
• Use only one microphone to pick up a single sound source, less is best.
• Place microphones as far as possible from reflective surfaces, use sound proofing if possible.
• Add the windscreen when using the microphone to help prevent breathing and wind blowing
into the microphone (also good if you have a fan or air conditioner on)
• Avoid excessive handling to minimize pickup of mechanical noise and vibration, try not to
bump your desk or the microphone.
• Do not cover any part of the microphone grille with your hand, as this will adversely affect
microphone performance.

FREQUENCY RESPONSE GRAPH
