- Page 1 Models Evolve ESS AU -13 kWh / -26 kWh / -39 kWh Evolve LFP AU -14 kWh / -28 kWh / -42 kWh Evolve 0513 Owner’s Manual...
- Page 2 This manual contains important product information for your Evolve battery energy storage system (BESS). This document is accurate at the time of publishing. Eguana reserves the right to make updates to the product without notice. For the latest Evolve documents, please visit our website at www.eguanatech.com WARNING! Read this document in its entirety before using this product.
-
Page 3: Table Of Contents
Table of Contents Contents 1 SAFETY ....................................1 1.1 I ............................1 N CASE OF EMERGENCY 1.2 G .......................... 2 ENERAL SAFETY PRECAUTIONS 1.3 E ..........................2 NVIRONMENTAL PROTECTION 2 INTRODUCTION ................................... 3 2.1 O ................................3 VERVIEW – A 2.2 S ...................... -
Page 4: Safety
1 Safety Throughout this manual, the following symbols will be used to highlight important information and procedures: Symbol Definition WARNING! A dangerous voltage or other condition exists. Use extreme caution when performing these tasks. CAUTION! This information is critical to the safe installation and or operation of the system. Follow these instructions closely. -
Page 5: General Safety Precautions
1.2 General safety precautions Important! Never operate the system in a manner not described by this manual. Only qualified personnel should service this product. Risks of Fire Do not expose the system to temperatures exceeding 45 degrees Celsius. Avoid installation in direct sunlight. Do not store objects on top of the cabinet. -
Page 6: Introduction
2 INTRODUCTION 2.1 Overview This manual contains instructions for the operation of the Eguana Evolve™ home energy storage system. This product, when installed, is permanently wired to the home electrical panel. There are two main components as shown below, including the energy storage system (1), and the energy meters installed in the main electrical panel (2). -
Page 7: System Monitoring - Account Setup
2.2 System Monitoring – Account Setup To view your system online, download the Stormcloud by SwitchDin app (available in IOS & Android) and enter the login credentials provided in the account invitation email issued by your installer. Alternatively, access the monitoring system via web-browser @ https://pwa.switchdin.com/account/login 3 Operation The Evolve home energy storage system is fully automated. -
Page 8: Service Button
3.2 Service Button The service button can be used to wake the LED display, and either put the system into or out of service mode, as well as cycle through various operating modes. IMPORTANT! In the event that the system has gone out of service, please consult your installer for guidance. -
Page 9: Restarting The Battery System After Low Battery Shutdown
5.2 Restarting the battery system after low battery shutdown The system will shutdown when the battery reaches a critically low level during backup operation. To restart the system: IMPORTANT! Direct sunlight is required to charge the battery. If the battery system is installed without PV connected to the backup panel, do not attempt the restart. -
Page 10: Manually Setting The Battery Minimum Soc Reserve
5.3 Manually setting the battery minimum SOC reserve The default minimum SOC reserve is set to optimize the system’s operation in a solar self-consumption mode. In the case of a scheduled grid outage, or a weather event which risks a grid outage, the battery minimum reserve can be manually set to its maximum value to maintain a full battery. -
Page 11: Maintenance
6 Maintenance The Evolve home energy storage system is a maintenance free product. Regularly scheduled inspection of the airflow path for the active cooling fans on the bottom side of the PCS cabinet is all that is required. This inspection should occur on annually. If the fan ventilation holes are obstructed with dust / debris, a soft-bristled brush can be used to wipe them clean. -
Page 12: Installer Checklist
8 Installer Checklist Following the completion of your energy storage system installation, ensure your installer has provided you with the following information for your personal records. Note that we may ask you for this information in the event you need to make a warranty claim: •...
