USE AND CARE GUIDE
WIRED OR WIRELESS UNIVERSAL DOORBELL
Questions, problems, missing parts? Before returning to the store, call Defiant
Customer Service 8 a.m. - 7 p.m., EST, Monday - Friday, 9a.m. - 6 p.m., EST, Saturday
1-866-308-3976
HOMEDEPOT.COM
ILLUSTRATIONS MAY VARY FROM ACTUAL UNIT.
THANK YOU
We appreciate the trust and confidence you have placed in Defiant through the purchase
of this wired or wireless door chime.
We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of
products available for your home improvement needs. Thank you for choosing Defiant!

Advertisement

Chapters

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 18000019 and is the answer not in the manual?

Questions and answers

Wayne
February 28, 2025

I have installed a w 108 A Defiant digital wired chime with a ring camera door bell. I have also installed the supplied kit with the ring camera door bell ? When I hook the wires up to the 16 ga terminals the chime continuously chimes ???

1 comments:
Mr. Anderson
February 28, 2025

The Defiant digital wired chime model W 108 A may continuously chime when connected to a Ring camera doorbell using part number 18000019 because a diode may be installed on more than one push button. To resolve this issue, remove each push button and check for a diode. If a diode is installed on more than one push button, loosen the screws and remove all diodes except for the one on the front door push button. Additionally, if a video doorbell is connected, contact the video doorbell manufacturer for installation instructions and troubleshooting.

This answer is automatically generated

Summary of Contents for Defiant 18000019

  • Page 1 ILLUSTRATIONS MAY VARY FROM ACTUAL UNIT. THANK YOU We appreciate the trust and confidence you have placed in Defiant through the purchase of this wired or wireless door chime. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of...
  • Page 2: Table Of Contents

    The manufacturer reserves the right to discontinue products and to change specifications at any time without incurring any obligation to incorporate new features in products previously sold. Contact the Customer Service Team at 1-866-308-3976 or visit www.HOMEDEPOT.COM. Models: 18000019, 18000020...
  • Page 3: Pre-Installation

    Pre-Installation PLANNING INSTALLATION Before installing the doorbell base, ensure that all parts are present. Compare parts with the Hardware Included and Package Contents sections. If any part is missing or damaged, do not attempt to assemble, install, or operate this doorbell base.
  • Page 4: Hardware Included

    Part Description Quantity Screw Wall anchor Diode (Type 1N4001-50V-1A) PACKAGE CONTENTS SYNC – PRESS AND RELEASE. RESET – HOLD 10 SECONDS. 1008504804 1008504903 TUNE – HOLD FRONT TRANS REAR 1 SECOND. 18000019 18000020 Part Description Quantity Doorbell cover Doorbell base...
  • Page 5: Installation - Wired Application

    Installation - Wired Application Verifying the transformer NOTE: DO NOT install batteries if connecting doorbell power rating base to transformer wires. Power must be supplied from a 16 volt AC transformer with a 10 watt or greater rating. To test the transformer output, see Troubleshooting, page 10.
  • Page 6: Installation - Wireless Application

    Installation - Wired Application (continued) Installation - Wired Application Wiring the doorbell base □ Connect the doorbell wires to the doorbell FRONT TRANS REAR base (B): □ Wire “F” to screw terminal “FRONT” □ Wire “T” to screw terminal “TRANS” □...
  • Page 7 Installation - Wireless Application (continued) Installation - Wireless Application Syncing the doorbell base and SYNC – PRESS push button (not included) RELEASE. RESET – HOLD 10 SECONDS. Refer to the manual included with the wireless push button for additional information. TUNE –...
  • Page 8: Operation

    Operation Adjusting the doorbell base volume The doorbell base (B) has an adjustable volume control. Rotate the volume control to adjust the volume. □ Remove the doorbell cover (A) from the doorbell base (B). The doorbell cover (A) is press fitted to the doorbell base (B). Selecting a musical tune - SYNC –...
  • Page 9: Tunes

    Operation (continued) Operation Selecting a musical tune - NOTE: Doorbell is designed to work with up to 10 wireless installation wireless push buttons (sold separately). The doorbell base (B) has different selectable tunes. NOTE: Doorbell is designed to play only sixteen different The push button set as the “REAR”...
  • Page 10: Troubleshooting - Wired Installation

    Troubleshooting - Wired Installation Problem Possible Cause Solution □ □ The doorbell The trans- Test transformer voltage output with a volt meter. Set the volt meter base does not former may to read A/C voltage. Voltage should read between 18 - 22 volts A/C sound.
  • Page 11: Troubleshooting - Wireless Installation

    Troubleshooting - Wireless Installation Problem Possible Cause Solution □ □ The doorbell base The push button and Follow step 2 under Installation - Wireless application does not sound. doorbell base are not to sync. synced. □ □ The batteries are not Make sure the batteries are installed according to the installed correctly.
  • Page 12 Questions, problems, missing parts? Before returning to the store, call Defiant Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday 1-866-308-3976 HOMEDEPOT.COM Retain this manual for future use. 09-050-22...
  • Page 13 Las ilustraciones pueden ser diferentes de la unidad comprada. GRACIAS Agradecemos la confianza que han depositado en Defiant al comprar este timbre. Procuramos crear continuamente productos de calidad diseñados para mejorar su hogar. Visítenos en internet para ver nuestra línea completa de productos disponibles que necesita para el mejoramiento de su hogar.
  • Page 14: Contenido

    Póngase en contacto con el personal de servicio al cliente al 1-866-308-3976 o visite el sitio www.HOMEDEPOT.COM. Modelos: #18000019, 18000020...
  • Page 15: Antes De La Instalación

    Antes de la instalación PLANIFICACIÓN DE LA INSTALACIÓN Antes de instalar la base del timbre de puerta, asegúrese de tener todas las piezas. Compare las piezas con las indicadas en las secciones ferretería incluida y contenidos del paquete. Si alguna parte falta o está dañada, no intente ensamblar, instalar u operar esta base del timbre de puerta.
  • Page 16: Ferretería Incluida

    Ancla de expansión de pared Diodo (tipo 1N4001-50V-1A) CONTENIDO DEL PAQUETE SYNC – PRESS AND RELEASE. 1008504804 1008504903 RESET – HOLD 10 SECONDS. TUNE – HOLD FRONT TRANS REAR 18000019 18000020 1 SECOND. Pieza Descripción Cantidad Tapa del timbre Base del timbre...
  • Page 17: Instalación - Base Cableada Del Timbre De Puerta

    Instalación - Aplicación cableada Verificación de la potencia NOTA: NO instale las baterías si conecta la base del nominal del transformador timbre de puerta a los conductores del transformador. La energía debe ser provista por un transformador de 16 voltios CA, de 10 o 15 vatios. Para probar el rendimiento del transformador, consulte Análisis de averías, página 22.
  • Page 18: Instalación - Base De Timbre De Puerta Inalámbrico

    TUNE SELECT Instalación - Aplicación cableada (continuación) Cableado de la base del timbre de puerta □ Conecte los cables del timbre a la base del FRONT TRANS REAR timbre (B): □ El cable “F” al terminal de tornillo “FRONT” □ El cable “T”...
  • Page 19 Instalación - Aplicación inalámbrica (continuación) Sincronización de la base SYNC – PRESS del timbre de puerta con el RELEASE. RESET – HOLD pulsador (no incluido) 10 SECONDS. TUNE – HOLD FRONT TRANS Consulte el manual incluido con el pulsador 1 SECOND. inalámbrico para obtener información adicional.
  • Page 20: Operación

    Operación Regulación del volumen de la base del timbre de puerta La base del timbre (B) tiene un control de volumen regulable, gire el control de volumen para regular el volumen. □ Retire la tapa (A) del timbre de puerta de la base del timbre de puerta (B).
  • Page 21: Tonos

    Operación (continuación) Operación Selección de una melodía NOTA: Todos los modelos de timbre están diseñados para musical: Instalación funcionar hasta con 10 pulsadores inalámbricos (vendidos por separado). inalámbrica NOTA: Todos los timbres están diseñados para reproducir La base del timbre de puerta (B) tiene diferentes solo dos tonos diferentes no importa cuantos pulsadores se utilicen.
  • Page 22: Análisis De Averías - Base Cableada Del Timbre De Puerta

    Análisis de averías - Aplicación cableada Problema Causa Probable Solución □ □ La base del timbre El transformador Pruebe la salida de voltaje del transformador con un voltímetro. Ajuste el de puerta no suena. puede no estar voltímetro para que lea el voltaje CA. La lectura del voltaje debe estar entre funcionando co- 18 y 22 voltios de CA en el lado de bajo voltaje del transformador cuando rrectamente.
  • Page 23: Inalámbrico

    Análisis de averías - Aplicación inalámbrica Problema Causa Probable Solución □ □ El timbre de puerta El pulsador y la base Siga el paso 2 en la sección aplicación inalámbrica de no suena. del timbre de puerta no puerta para sincronizar. están sincronizados.
  • Page 24 Este aparato cumple con la Parte 15 de las Reglas de la FCC. La operación está sujeta a las dos siguientes condiciones: (1) este aparato no puede causar interferencias perjudiciales y (2) este aparato debe aceptar cualquier interferencia recibida, incluyendo una interferencia que pueda causar un funcionamiento indeseado. Advertencia: los cambios o modificaciones en esta unidad que no estén expresamente aprobados por la parte responsable del cumplimiento pueden anular la autoridad del usuario para operar el equipo.
  • Page 25 ¿Tiene preguntas, problemas o piezas faltantes? Antes de la devolución al almacén llame al Servicio al Cliente de Defiant de 8 a.m.-5 p.m., Hora del Central, de lunes a viernes. 1-866-308-3976 HOMEDEPOT.COM Guarde este manual para uso futuro. 09-050-22...
