- Page 1 Motorized CAUTION: DO NOT EXCEED RATED LISTED WEIGHT. SERIOUS INJURY OR PROPERTY DAMAGE MAY OCCUR! TV Wall Mount 200x200 60" 300x300 TVL1102 40kg 400x200 (88lbs) 400x400 RATED Installation Manual...
-
Page 2: Component Checklist
NOTE: Read the entire instruction manual before you start installation and assembly. Component Checklist IMPORTANT: Ensure that you have received all parts according to the component checklist prior to installation. If any parts are missing or faulty, telephone your local distributor for a replacement. WARNING •... - Page 3 1. Separat ing t he Decorat ive Covers from t he W all M ount 4a. For Wood Stud Wall Mounting 55mm 55mm (2.2") (2.2") ø 4.5mm (ø 3/16") Forward installation Find and mark the exact location of mounting holes 2.Opening Hard t he Sw ing Arm Drill pilot holes 90°...
- Page 4 4b. For Solid Brick and Concrete Mounting 60mm 60mm (2.4") (2.4") ø 10mm (ø 3/8") Forward installation Mark the exact location of mounting holes Drill pilot holes √ Reverse installation √ Screw the wall mount onto the wall Tighten the screw leaving a 7mm space from the wall.
- Page 5 5. I nst alling t he Decorat ive Covers and t he Cable Clips √ Screw the wall mount onto the wall...
- Page 6 6. Installing the Adapter Brackets 6-2 For Recessed Back Screens or to Access A/V Inputs Remove the screws on the adapter brackets and keep the screws for later use. 6-1 For Flat Back Screens Note: Choose the appropriate screws, washers and spacers (if necessary) according to the type of screen. ·...
- Page 7 7. Hooking the TV onto the Wall Mount 8. Cable Management 90° Hook the TV over the swing arm. Reinstall the bottom screws to secure the adapter brackets to the swing arm. 90° Important:Make sure the TV is correctly hooked before releasing the TV. Connect the cables to your TV and route through the cable clips.
- Page 8 9. Placing the IR Receiver Reset mode Do not open the electrical cover please. STEP 1: Restart the power. STEP 2: Press and hold for 3 seconds and repeat three times. The system will start automatic positioning: First positioning TV wall mount with flat against the wall, then positioning TV wall mount with 90°of lateral rotation until the TV wall mount automatically stop at 90°position.
-
Page 9: Remote Control Problems
LEARN MODE instructions as shown below: STEP1: Press and hold for 3 seconds until LED light on the matched remote control stays on, and then press . The buzzer will sound once, the red LED light on the IR receiver will stay on, then the LEARN MODE will be entered. -
Page 10: Abnor Mal Noise
Can ’t Oper a te Please check if the power adaptor is properly connected to the product. If so, please turn the power on. If there is no buzzer sound or red light power indication, please check if the power adaptor works properly. If the power adaptor doesn’t work please contact us to replace the power adaptor.
