3M
Ranger
Pressure Infusor
™
™
Quick
Start Guide
Refer to the Operator's Manual for warnings, instructions and
other information related to this product.
Instructions For Use
1.
Locate the main power switch on the
underside of the base of unit (as shown).
Turn the unit ON.
2.
Verify pressure range visual alerts ("Low",
"High", "in Range") on control panel turn ON.
after two seconds, turn off.
3.
Verify Start/Stop button indicators on control
panel change to Standby mode (amber).
4.
Prepare warming unit, warming set and spike
fl uid bags.
5.
Open pressure infusor door and slide fluid
bag into infusor chamber ensuring bag port
and spike hang below the metal retaining
fi ngers.
6.
Securely close and latch the pressure infusor
door.
Main power
switch
Power entry
module
3M
Ranger
™
™
Pressure Infusor
High
High
In Range
In Range
300 mmHg
Low
Low
Start /Stop buttons
