High-pressure cleaner
- mobile –
cold water
-
Manual
for type series MBH:
MBH1260/1500K
MBH1800/2400
MBHST1260/1500/
1800/2400
MEIER-BRAKENBERG GmbH & Co. KG
Brakenberg 29 ● 32699 Extertal ● Germany
Tel: +49(0)52 62/993 99-0 ● Fax: +49(0)52 62/993 993
E-mail: info@meier-brakenberg.de
Internet: www.meier-brakenberg.de
Soaking units ● Disinfection ● Animal weighing machines ● Intensive cleaning ●
Hihg-pressure cleaner
● Stable cooling ● Watering units
Advertisement
Table of Contents
Related Manuals for MEIER-BRAKENBERG MBH1260
Summary of Contents for MEIER-BRAKENBERG MBH1260
- Page 1 MBH: MBH1260/1500K MBH1800/2400 MBHST1260/1500/ 1800/2400 MEIER-BRAKENBERG GmbH & Co. KG Brakenberg 29 ● 32699 Extertal ● Germany Tel: +49(0)52 62/993 99-0 ● Fax: +49(0)52 62/993 993 E-mail: info@meier-brakenberg.de Internet: www.meier-brakenberg.de Soaking units ● Disinfection ● Animal weighing machines ● Intensive cleaning ●...
-
Page 2: Table Of Contents
Contents 1. Introduction ........................2 2. Use of MBH Cleaners ......................3 3. Safety regulations ......................3 4. Start of operation ......................4 4.1 Components of high pressure cleaner ................4 4.2 Oil level check ......................4 4.3 Power supply ......................4 4.4 Water supply ......................4 4.5 Starting the cleaner .....................5 4.6 Function start/stop automatic ..................5 5. -
Page 3: Use Of Mbh Cleaners
High-pressure cleaners of type series MBH are exclusively for the indoor use of hog and chicken houses.To be used only with water. Hot water feed (up to 40 °C) increases cleaning effect. Use only accessories and spare parts approved by MEIER-BRAKENBERG. Mind the correct jet size when using and/ or changing jets and dirt blasters! 3. -
Page 4: Start Of Operation
Source: Carl Heymanns Verlag Gereonstraße 18-32 50670 Köln Germany Please observe the relevant local directives regarding liquid blasters! Caution : Apart from the repulsive force the wrist is affected by torsional movement during ejecting. 4. Start of operation 4.1 Components of high pressure cleaner 1. -
Page 5: Starting The Cleaner
When operating in suction process from a feed tank use a 1 1/2 " suction hose of max. 5 m with suction coupling. Devices with control (start/stop automatic): backfitting is required for suction process! Cleaners with backfitting kit (see point 4.6): When operating in suction process from a feed tank use a 1 1/2 "... -
Page 6: Mode Of Operation
Direct start: Pressing the green I-button „Direktstart“ (direct start) makes the high-pressure cleaner operate at turned on operational availibility without using the torch. Also turns off after approx. 20 to 30 sec. Operation of accessories of the high-pressure cleaner MBH in suction mode: 1. -
Page 7: Maintenance
7. Maintenance 7.1 Before each use Check the power supply cable. The cable must not be damaged (risk of electric shock). An authorised electrician must replace the damaged power lead immediately. Check high-pressure hose for damages (risk of bursting); if damaged replace immediately. Measures at risk of frost: Store the device safe from frost! 7.2 Service notes on high-pressure pump (drawing) -
Page 8: Hose Coiler
Clean only suitable surfaces which are resistant to the strong jet. The foam lance is used for foam output which is injected to the lance from the solution tank. 9 Injector with coupling f. MBH1260 (jet size, screw-on: 2.1 mm) Models: HZ07701 f. -
Page 9: General Safety Information
The injector serves the targeted feeding of cleaning agents to the water and the rinsing operation with water. Suitable dosing media are fluids of group 2 of the pressure equipment directive (Druckgeräterichtlinie DGRL). 9.2 General safety information: The injector must only be used with bypass and in accordance with this operation manual to ensure safe operation. -
Page 10: Foam Lance For Injector
The valve drains off excess water to prevent damages to the control valve of the high-pressure device. 9.6 Foam lance for injector: The metered medium can be sprayed with the double lance. The foam lance HZ079Z01 with integrated air injector is used for foaming. Connect this lance to the high-pressure gun with the supplied KEW-fitting. 9.7 Troubleshooting: Injector does not aspirate any medium or does not develop any foam: Clogged dosing nozzle –... - Page 11 Ersatzteilliste HD-Pumpe HE006 / HE003 passend für: • MBH1500 (HE003) • MBHST1500 (HE003) • MBH1800 (HE006) • MBHST1800 (HE006) • MBH2400 (HE006) • MBHST2400 (HE006) Verschleißteil-Sätze HE006 und HE003 / Part-Kits HE006 and HE003 Kit-Nummer Bezeichnung Artikelnummer Rep.Satz Ventile für Pumpe HE006/HE003 HE006E-A (Pos.
- Page 12 Standard-Einzelersatzteile HE006 / Spareparts HE006 Kit-Nummer Bezeichnung Artikelnummer Ventilstopfen ms. an HD-Pumpe HE006 HE006E03 Dichtring für Ventilstopfen HE006E03 HE006E04 O-Ring Ø20,29x2,62 mm für Ventilstopfen HE006E03 HE006E05 O-Ring an Stopfen Eingang 23,81 x 2,62 HE006E08 Stopfen ms. 3/8“, an Pumpe HE006 HE006E10 Front-Kolbenführung f.
- Page 13 Standard-Einzelersatzteile HE003 / Spareparts HE003 Artikelnummer der Einzelteile siehe Einzelersatzteile HE006 / Item-No. of individual components see spareparts HE006 Abmessungen Pumpe HE006/HE003 Dimensions pump HE006/HE003...
- Page 14 Ersatzteilliste HD-Motorpumpe HE007 passend für: • MBH1260K • MBHST1260 Verschleißteil-Sätze HE007 / Part-Kits HE007 Kit-Nummer Bezeichnung Artikelnummer Rep.Satz Ventile für Motorpumpe HE007 HE004E006 Kolbenkit für Motorpumpe HE007, Ø 22 mm HE004E005 Dichtsatz für Pumpe HE007, Ölseite, Ø 22 mm HE004E007 Dichtsatz für Pumpe HE007, Wasserseite, Ø...
- Page 15 Standard-Einzelersatzteile HE007 und HE004 / Spareparts HE007 and HE004 Kit-Nummer Bezeichnung Artikelnummer O-Ring 17,86 x 2,62 mm HE008E12 Kolbenführung 22 mm für Pumpe HE004, Pos. 13 HE004E013 Lager für Pumpe HE004, Pos. 20 HE004E020 Öl-Peilstab für Motorpumpe HE007 HE004E001 Kupferscheibe/Ring f. Keramikkolben in Pumpe HE004 HE004E024 Keramikkolben einzeln für Pumpe HE004, Ø22 HE004E003...
- Page 16 Ersatzteilliste Regelventil HE008, passend für: • Alle MBH • Alle MBHST Standard-Einzelersatzteile /Spareparts HE008 Kit-Nummer Bezeichnung Artikelnummer O-Ring Ø 5,94 x 3,53 HE008E09 Düse in Regelventil HE008E10 Feder 9,5x17,5x0,7 HE008E11 O-Ring Ø 17,86 x 2,62 HE008E12 Gewindeadapter 3/8“ AG HE008E13 Feder 21x50x6 HE008E14 Kolben...
- Page 17 Trommelseite rechts 1/2", 3/4" und 1" HE016E002 Trommelseite links kpl. 1/2“ HE016E001 PVC-Griff an Kurbel für Schlauchroller HE016 HE016E004 Sprengring an Kurbel für Schlauchroller HE016 HE016E003 Bestellungen/technische Fragen: +49(0)52 62 / 993 99-0 MEIER-BRAKENBERG GmbH & Co. KG • Brakenberg 29 • 32699 Extertal...
- Page 18 Ersatzteilliste HD-Pistole HP001, passend für: • Alle MBH • Alle MBHST Standard-Einzelersatzteile / Spareparts Bezeichnung Art.-Nr. Bezeichnung Art.-Nr. Frontstecker M10 x 1, Messing HP001E02 Bolzen 4 x 20 HP001E20 Stützring 3,2 x 7,5 x 1,2 mm HP001E03 Bolzen 4 x 13 HP001E21 O-Ring 2,62 x 2,84 mm HP001E04...
- Page 19 Blende 25 x 0,5 mm VA HZLSE003 O-Ring 1,78 x 20,35 mm HZLSE006 Vordere Düse - LS12 HZLSE007 Filtertuch für Schaumlanze HZLS01 HZLSE101 Bestellungen/technische Fragen: +49(0)52 62 / 993 99-0 MEIER-BRAKENBERG GmbH & Co. KG • Brakenberg 29 • 32699 Extertal...
