- Page 1 Manual for type series MBH: MBH1260K MBH1800/2400 MBHST1260/1800/2400 MEIER-BRAKENBERG GmbH & Co. KG Brakenberg 29 ● 32699 Extertal ● Germany Tel: +49(0)52 62/993 99-0 ● Fax: +49(0)52 62/993 993 E-mail: info@meier-brakenberg.de Internet: www.meier-brakenberg.de Soaking units ● Disinfection ● Animal weighing machines ● Intensive cleaning ●...
-
Page 2: Table Of Contents
Contents 1. Introduction ........................2 2. Use ..........................3 3. Safety regulations ......................3 4. Start of operation ......................4 4.1 Components of high pressure cleaner ................4 4.2 Oil level check ......................4 4.3 Power supply ......................5 4.4 Water supply ......................5 4.5 Starting the cleaner .....................5 4.6 Function Start/Stop model .....................6 5. -
Page 3: Use
High-pressure cleaners of type series MBH are exclusively for the indoor use of hog and chicken houses.To be used only with water. Hot water feed (up to 40 °C) increases cleaning effect. Use only accessories and spare parts approved by MEIER-BRAKENBERG. Mind the correct jet size when using and/ or changing jets and dirt blasters! 3. -
Page 4: Start Of Operation
- The ejected water of the high-pressure jet produces repulsive force on the handgun. Hold the spray lance and steel pipe with both hands to ensure firm stand. - A competent person (customer service) must check the high-pressure cleaner at least every 12 months to verify whether a continued safe operation is ensured. -
Page 5: Power Supply
4.3 Power supply Electricity must be connected by an electrician. Caution: Verify that the voltage stated on the type plate complies with the voltage of the power supply. Unsuitable extension cables can be dangerous. For outdoor operation use only approved and correspondingly marked leads. 4.4 Water supply For connection values refer to type plate. -
Page 6: Function Start/Stop Model
4.6 Function start/stop automatic Only for start/stop type: The motor starts („EIN“) when opening the high-pressure torch. The device switches off („AUS“) after the preset overtravel time of approx. 30 sec. (torch not being used for more than approx. 30 sec.) Operational availibility: Switch the device to „Betriebsbereit“... -
Page 7: Mode Of Operation
5. Mode of operation The high-pressure pump is driven by an electric motor and is supplied with water through a hose, directly or through a feed tank, increases the pressure to the required operating pressure and leads the water through the high-pressure hose to the torch or jet spraying device. A special nozzle generates a fan- shaped spray sheet with the best possible cleaning effect. -
Page 8: Filter
Oil change: - Open oil-drain screw. - Let oil drain off into collecting tray. - Close oil-drain screw. - Fill in new oil slowly, oil must reach the middle of the oil level indicator. Applicable oil: SAE 10W-60 fully synthetic (Item.-No.: WB0011-01) 7.4 Filter The standard water filter is on the backside of the device at the water inlet connection behind the Geka- coupling towards the high-pressure pump. -
Page 9: Special Lances
8.3 Special lances Special lances are extra equipment and supplied on request. Lances can be changed with the KEW fast coupling system on the torch. The double lance allows stageless pressure adjustment with the handle. The dirt blaster lance is suitable for very heavy contamination. The rotating pencil-jet generates a very aggressive cleaning jet. - Page 10 9.3.1 Connecting the injector Switch off the main switch of the high-pressure device. Afterward disconnect the fast coupling connection between device and hose or hose drum (KEW coupling system). When using a stationary high-pressure line coupling must be between tap and high-pressure hose. Couple the injector in flow direction between device and hose.
- Page 11 Wrong flow direction: Check the arrows at the injector indicating the direction of flow. Flow directions differ depending on whether coupling at the tap or direct connection to the high- pressure device. Do you have any questions? We would be glad to help. Please call us! Tel.:+49 (0) 5262 / 993 99-0 page 11 of 11...
- Page 12 Ersatzteilliste HD-Pumpe HE006, passend für: MBH1800 MBH2400 MBHST1800 MBHST2400 Verschleißteil-Sätze HE006 / Part-Kits HE006 Kit-Nummer Bezeichnung Artikelnummer Rep.Satz Ventile für Pumpe HE006 HE006E-A (Pos. 5 + 6) Kolbenkit für Pumpe HE006 HE006E-B (Pos. 19) Dichtsatz für Pumpe HE006, Ölseite HE006E-C (Pos.
- Page 13 Standard-Einzelersatzteile HE006 / Spareparts HE006 Kit-Nummer Bezeichnung Artikelnummer Ventilstopfen ms. an HD-Pumpe HE006 HE006E03 Dichtring für Ventilstopfen HE006E03 HE006E04 O-Ring an Stopfen Eingang 23,81 x 2,62 HE006E08 Stopfen ms. 3/8“, an Pumpe HE006 HE006E10 Front-Kolbenführung f. Pumpe HE006 HE006E13 Dichtring Wasser, braun, an Pumpe HE006 HE006E14 O-Ring aus Dichtsatz HE006E-D, 37,82 x 1,78 HE006E16...
- Page 14 Ersatzteilliste HD-Motorpumpe HE007, passend für: MBH1260K MBHST1260 Verschleißteil-Sätze HE007 / Part-Kits HE007 Kit-Nummer Bezeichnung Artikelnummer Rep.Satz Ventile für Motorpumpe HE007 HE004E006 Kolbenkit für Motorpumpe HE007, Ø 22 mm HE004E005 Dichtsatz für Pumpe HE007, Ölseite, Ø 22 mm HE004E007 Dichtsatz für Pumpe HE007, Wasserseite, Ø 22 mm HE004E002 Rep.Satz Kolbenführung/Stützring, Ø...
- Page 15 Ersatzteilliste Regelventil HE008, passend für: Alle MBH Alle MBHST Standard-Einzelersatzteile /Spareparts HE008 Kit-Nummer Bezeichnung Artikelnummer O-Ring Ø 5,94 x 3,53 HE008E09 Düse in Regelventil HE008E10 Feder 9,5x17,5x0,7 HE008E11 O-Ring Ø 17,86 x 2,62 HE008E12 Gewindeadapter 3/8“ AG HE008E13 Feder 21x50x6 HE008E14 Kolben HE008E16...
- Page 16 Explosionszeichung Schlauchroller HST Modelle: HST30 HST70 HST100 Bestellungen/technische Fragen: +49(0)52 62 / 993 99-0 MEIER-BRAKENBERG GmbH & Co. KG Brakenberg 29 32699 Extertal...
- Page 17 Ersatzteilliste HD-Pistole HP001, passend für: Alle MBH Alle MBHST Standard-Einzelersatzteile / Spareparts Bezeichnung Art.-Nr. Bezeichnung Art.-Nr. Frontstecker M10 x 1, Messing HP001E02 Bolzen 4 x 20 HP001E20 Stützring 3,2 x 7,5 x 1,2 mm HP001E03 Bolzen 4 x 13 HP001E21 O-Ring 2,62 x 2,84 mm HP001E04 Vorderrohr 2 x 1/4“...
- Page 18 HZLSE019 Blende 25 x 0,5 mm VA HZLSE003 O-Ring 1,78 x 20,35 mm HZLSE006 Vordere Düse - LS12 HZLSE007 Filtertuch für Schaumlanze HZLS01 HZLSE101 Bestellungen/technische Fragen: +49(0)52 62 / 993 99-0 MEIER-BRAKENBERG GmbH & Co. KG Brakenberg 29 32699 Extertal...
