OWNER'S MANUAL
WARRANTY CARD
SPARE PARTS CATALOGUE
1-BEAM PLOUGH mounted
Libra
U 031 - 3-furrow plough
U 031/1 - 4-furrow plough (3+1)
U 031/2 - 4-furrow plough
U 031/3 - 5-furrow plough (4+1)
PRIOR TO STARTING WORK, PLEASE READ
THIS OPERATING INSTRUCTIONS
®
BOMET
Spółka z ograniczoną odpowiedzialnością
Spółka Komandytowa
07-100 Węgrów, ul. B. Joselewicza 2
tel. (0 prefix 25) 691 78 06
Węgrów 2017, Edition 1, Eng
Original manual
Printing date: 09/05/2019
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Bomet U 031
Summary of Contents for Bomet U 031
- Page 1 WARRANTY CARD SPARE PARTS CATALOGUE 1-BEAM PLOUGH mounted Libra U 031 - 3-furrow plough U 031/1 - 4-furrow plough (3+1) U 031/2 - 4-furrow plough U 031/3 - 5-furrow plough (4+1) PRIOR TO STARTING WORK, PLEASE READ THIS OPERATING INSTRUCTIONS ®...
- Page 2 ® Copying of the manual or its parts is allowed only with the written permission of Bomet...
- Page 3 Spółka Komandytowa 07-100 Węgrów, ul. B. Joselewicza 2 tel. (0 prefix 25) 691 78 06 http:www.bomet.pl; e-mail: bomet@bomet.pl DECLARATION OF CONFORMITY for a machine According to the Ordinance of Minister of Economy of 21 October 2008 (Journal of Laws [“Dziennik Ustaw”] No 199, item 1228) and European Union Directive 2006/42/WE of 17 May 2006 (Journal of of Laws [Dz.
- Page 4 - 2 -...
- Page 5 Spółka Komandytowa 07-100 Węgrów, ul. B. Joselewicza 2 tel. (0 prefix 25) 691 78 06 http:www.bomet.pl; e-mail: bomet@bomet.pl DECLARATION OF CONFORMITY for a machine According to the Ordinance of Minister of Economy of 21 October 2008 (Journal of Laws [“Dziennik Ustaw”] No 199, item 1228) and European Union Directive 2006/42/WE of 17 May 2006 (Journal of of Laws [Dz.
-
Page 6: Warranty Card
W A R R A N T Y C A R D U031 1-beam plough mounted type Serial number ..........201 ..Date of production ..Inspector signature ..........Date of sale ..........Seller signature ..................Seller stamp CAUTION: It is seller’s obligation to fill in the warranty card and complaint forms carefully (legibly). - Page 7 Complaint form no 1 1-beam plough mounted U 031 / ..Serial number ..........Date of sale ..........…………………………………………………………. Seller’s signature and stamp Complaint protocol number ......Complaint form no 2 1-beam plough mounted U 031 / ..Serial number ..........
- Page 8 After repair I received technically efficient machine on ..........…………………………………………………….. user’s signature Notices: ........................................................................After repair I received technically efficient machine on ..........…………………………………………………….. User’s signature Notices: ........................................................................After repair I received technically efficient machine on ..........……………………………………………………..
- Page 9 IDENTIFICATION 1-BEAM PLOUGH MOUNTED 1-beam plough mounted of U031 series has a rating plate, fitted in the front part of the plough frame. Basic data which serves for identification of the machine: manufacturer’s name, machine symbol, serial number, year of production, is put there. Data placed on the rating plate serves for identification of the plough and ought to correspond to the following data, filled in during the sales.
-
Page 10: Table Of Contents
TABLE OF CONTENTS WARRANTY CARD……………………………………………………………………………. 4 1. INTRODUCTION…………………………………………………………………………….. 9 2. INTENDED USE OF THE PLOUGH…………………………………………………….. 9 3. SAFETY PRECAUTIONS AND WARNINGS…………………………………………… 10 3.1. Symbols: meaning and application……………………………………….……………. 10 3.2. Expected use of the machine.................. 10 3.3. Description of residual risk..................10 3.4. -
Page 11: Introduction
1. INTRODUCTION This manual aim is to make a user acquainted with a proper operation, usage and adjustment of the mounted plough. Its aim is also warning about existing or possible threats. The manual also contains information on preparation of the plough for operation and for transportation on public roads. -
Page 12: Safety Precautions And Warnings
3. SAFETY PRECAUTIONS AND WARNINGS 3.1. Symbols: meaning and application In the present manual symbols are used in order to draw the reader’s attention and stress certain particularly important aspects requiring discussion. DANGER This indicates danger, with a possible serious accident risk. Not obeying recommendations marked with this sign may cause a situation of a serious risk of sustaining an injury by the operator and/or people nearby! Obey strictly these recommendations! -
Page 13: Estimation Of Residual Risk
® Although BOMET company takes responsibility for pattern-designing and construction in order to eliminate danger, certain risk elements during mounted plough operation are unavoidable. - Page 14 General regulations Apart from this manual, one shall also follow traffic regulations and occupational safety and health regulations. Warnings (pictograms) placed on the plough give advice concerning safety of the user and other people, and avoiding accidents. When driving on public roads, it is obligatory to follow regulations included in Highway Code.
- Page 15 At each getting off the tractor by the operator, leave the plough in the lowered position. Removing clogs can be performed after lowering the tool onto the ground and turning off the tractor engine. It is not allowed to use tractor reverse gear during work, when the tool is in the working position.
-
Page 16: Standard Conformity
General principles. 3.7. Manufacturer’s responsibility and guarantee ® In relation to described in this manual machine types, BOMET company does not acknowledge any civil responsibility towards: - improper or inconsistent with the manufacturer’s recommendations using the machine,... -
Page 17: Usage Regulations
entirely due to the proper operation of the plough, there are warning signs – pictograms which indicate for possibility of danger and present manners of avoiding it. In table 1 pictograms placed on the machine and their meaning have been specified. -
Page 18: Construction And Operation Of The Plough
4.2. Construction and operation of the plough 1-beam mounted ploughs of U031 series (figure 1) are tools mounted on the tractor three-point suspension system. Construction of the ploughs is modular, i.e. they have the same structural elements but only differ in the number of bodies and the size of the frame. Figure 1. -
Page 19: Equipment And Fittings
with divided mouldboards (breast and wing), ploughshare with screwed chisel, scraper bars mounted over the mouldboard and the skid are attached to the body core. Saddles of plough bodies are attached to the plough frame with screw connections. The leg of the plough body is connected to the saddle with screw connections, which protect the body against overload. -
Page 20: Preparing The Plough To Work
Wheel spacing - adjustment When ploughing the wheel spacing should always be measured inside the tires. Internal distance between the front tires must be at least equal to the internal distance of the rear tires. It is permitted that the front wheels are wider by approx. -
Page 21: Mounting The Plough With The Tractor
4.6. Aggregation of the plough with a tractor When connecting the plough with a tractor, it is necessary to make sure that: - tractor lower rods are below plough suspension studs, - connecting points of the tractor and plough are in the same category, - In the transportation and working positions, lower and upper connecting points of the plough with a tractor three-point suspension system are set in a vertical plane, - during operation side stops of the lower rods allow for small clearance of the plough to... -
Page 22: Initial Adjustment
ploughing, the field should be cleaned of excessively long, loose (post-harvest) plant equals remnants. Permissible stubble height 20 cm. In the event of occuring working resistance beyond the towing capacity of the tractor, the last plough body can be uninstalled or a tractor with higher power should be used. When starting ploughing from the field edge, the first furrow must be put to the inside of the field. -
Page 23: Operation With The Mounted Plough
frame was at the same height H. The upper connector can be installed on the plough in three positions, see Figure 3. Figure 6. Plough longitudinal levelling Properly leveled plough should have the frame set in parallel to the field surface and three- point suspension system rack should be set vertically. -
Page 24: Plough Adjustment
- during operation, the plough should move in rectilinear motion with the constant speed adjusted to conditions of the performed ploughing. Operation with too low speed impairs the operation quality of the bodies, worsens soil crumbling and also quality of mixing and covering fertilizers and plant remnants, - turning and returning with the tool lowered may lead to serious damage both to the plough and the tractor,... - Page 25 If the first body does not cut furrows of the desired width, perform adjustment of the first furrow. This adjustment is performed with the screw A (Fig. 10). By moving the slider of the frame along the ledger to the left (to the undisturbed soil) the width is increased, to the right the width of the first furrow is reduced.
- Page 26 perpendicular to the latching axle of the suspension system. It should be noted so that after submerging the plough, the tractor lower rods are at the same distance from the tractor axis of symmetry, and the upper connector runs along the axis of the tractor.
- Page 27 Adjustment of the shear fuse 1-beam ploughs of U031 series are equipped with a shear fuse of the bodies in the form of a screw M16x90-5.8. In the body saddle there are two holes in which fuses are mounted. As a standard, the fuse is mounted in the hole A (see Fig. 14), if field conditions are harder, the fuse should be shifted into the hole B which will cause that more force will be required to release the fuse.
- Page 28 Adjustment of the skimmer The primary function of skimmers is cutting off and reversing the top layer of soil, so that all remnants of sowings and weeds are covered. At the properly adjusted skimmer, the cut off soil layer is thrown onto the bottom of the groove and covered with the furrow. Properly used skimmers are the best way for mechanical elimination of weeds.
-
Page 29: Technical Operation
5. TECHNICAL OPERATION To ensure a lasting and reliable operation of 1-beam plough, condition of screw connections should be checked and tightened in case of loosening. After work, the plough should be cleaned thoroughly. Worn or damaged working parts should be replaced following these recommendations: all worn elements of the plough shall be exchanged in the proper time, for exchange only original parts ensuring good quality shall be used, it comprises... -
Page 30: Lubrication Instruction
CAUTION All activities connected with uninstalling and installing of worn parts of the plough shall be performed on the tough and flat ground, after lowering the plough onto the ground or supports. Exchange of the ploughshare Work surfaces of plough bodies should be equal, without bends in the contact places of a ploughshare, a breast and a wing of the mouldboard. -
Page 31: Detection And Removal Of Failure
Fig. 19. Lubrication points Table 3. Lubrication points Frequency Lubrication place Grease type of lubrication ŁT 42 grease Rotation stud of the plough 10 h ŁT 42 grease Main stud of the plough frame 10 h ŁT 42 grease Guide of the slider and ledger 10 h ŁT 42 grease Stud of the wheel rotation... -
Page 32: Transportation On Public Roads
REMEMBER! Inefficiencies and damages noticed shall be removed without delay. 6. TRANSPORTATION ON PUBLIC ROADS 6.1. Plough transportation by means of transport Mounted ploughs can be transported from the manufacturer to the sales person or client by trailers of means of transport. Ploughs are transported assembled and ready for operation. -
Page 33: Totaling
keys. In case of worn parts, follow ‘Totaling’ point. CAUTION Lifting devices used during disassembly can be operated only by a person properly authorized and qualified. 8. TOTALING Totaling of the plough should be performed after its previous complete disassembly and inspection of the machine parts. -
Page 34: Spare Parts Catalogue
SPARE PARTS CATALOGUE How to use the catalogue. Spare parts catalogue includes other assemblies of the plough, marked with proper numbers of tables. The catalogue should be used as follows: - determine the proper assembly the exchanged part belongs to according to the tables, - find the needed part on the assembly table following the reference number from the assembly drawing. - Page 35 Table 1. Frame and suspension system rack of the 1-beam plough Number of pieces in the plough Position KTM symbol or Part name Fig. standard number U031 U031/1 U031/2 U031/3 Head set 1031-01-001 Ledger set 1031-02-001 Slider set 1031-03-001 The main frame Po3 1031-04-001 The main frame Po4 1031-04-002...
- Page 36 Table 2. Plough body Number of pieces in the plough Position KTM symbol or Part name Fig. standard number U031 U031/1 U031/2 U031/3 Core 1031-05-001 Skid 1031-05-002 Ploughshare 16'' 1031-05-003 Ploughshare chisel 1031-05-004 Breast 1031-05-005 Mouldboard wing 1031-05-006 Stiffening bracket 1031-05-007 Bracket fixing 1031-05-008...
