Bomet Libra Owner's Manual

1-beam plough mounted
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
------------
-------------
OWNER'S MANUAL
WARRANTY CARD
SPARE PARTS CATALOGUE
1-BEAM PLOUGH mounted
Libra
U 068 - 3-furrow plough
U 068/1 - 4-furrow plough (3+1)
U 068/2 - 4-furrow plough
U 068/3 - 5-furrow plough (4+1)
PRIOR TO STARTING WORK, PLEASE READ
THIS OPERATING INSTRUCTIONS
®
BOMET
Spółka z ograniczoną odpowiedzialnością
Spółka Komandytowa
07-100 Węgrów, ul. B. Joselewicza 2
tel. (0 prefix 25) 691 78 06
Węgrów 2017, Edition 3, Eng
Original manual
Printing date: 08/01/2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Libra and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Bomet Libra

Summary of Contents for Bomet Libra

  • Page 1 ------------- OWNER'S MANUAL WARRANTY CARD SPARE PARTS CATALOGUE 1-BEAM PLOUGH mounted Libra U 068 - 3-furrow plough U 068/1 - 4-furrow plough (3+1) U 068/2 - 4-furrow plough U 068/3 - 5-furrow plough (4+1) PRIOR TO STARTING WORK, PLEASE READ THIS OPERATING INSTRUCTIONS ®...
  • Page 2 ® Copying of the manual or its parts is allowed only with the written permission of Bomet...
  • Page 3 Spółka Komandytowa 07-100 Węgrów, ul. B. Joselewicza 2 tel. (0 prefix 25) 691 78 06 http:www.bomet.pl; e-mail: bomet@bomet.pl DECLARATION OF CONFORMITY for a machine According to the Ordinance of Minister of Economy of 21 October 2008 (Journal of Laws [“Dziennik Ustaw”] No 199, item 1228) and European Union Directive 2006/42/WE of 17 May 2006 (Journal of Laws [Dz.
  • Page 4 - 2 -...
  • Page 5 Spółka Komandytowa 07-100 Węgrów, ul. B. Joselewicza 2 tel. (0 prefix 25) 691 78 06 http:www.bomet.pl; e-mail: bomet@bomet.pl DECLARATION OF CONFORMITY for a machine According to the Ordinance of Minister of Economy of 21 October 2008 (Journal of Laws [“Dziennik Ustaw”] No 199, item 1228) and European Union Directive 2006/42/WE of 17 May 2006 (Journal of Laws [Dz.

  • Page 6: W A R R A N T Y C A R D

    W A R R A N T Y C A R D U068 1-beam plough mounted type Serial number ..........201 ..Date of production ..Inspector signature ..........Date of sale ..........Seller signature ..................Seller stamp CAUTION: It is seller’s obligation to fill in the warranty card and complaint forms carefully (legibly). Lack of e.g.
  • Page 7 Complaint form no 1 1-beam plough mounted U 068 / ..Serial number ..........Date of sale ..........…………………………………………………………. seller’s signature and stamp Complaint protocol number ......Complaint form no 2 1-beam plough mounted U 068 / ..Serial number ..........Date of sale ..........
  • Page 8 After repair I received technically efficient machine on ..........…………………………………………………….. user’s signature Notices: ........................................................................After repair I received technically efficient machine on ..........…………………………………………………….. user’s signature Notices: ........................................................................After repair I received technically efficient machine on ..........……………………………………………………..
  • Page 9 IDENTIFICATION 1-BEAM PLOUGH MOUNTED 1-beam plough mounted of U068 series has a rating plate, fitted in the front part of the plough frame. Basic data which serves for identification of the machine: manufacturer’s name, machine symbol, serial number, year of production, is put there. Data placed on the rating plate serves for identification of the plough and ought to correspond to the following data, filled in during the sales.

  • Page 10: Table Of Contents

    TABLE OF CONTENTS W A R R A N T Y C A R D ......................4 1. INTRODUCTION ........................9 2. INTENDED USE OF THE PLOUGH ................... 9 3. SAFETY PRECAUTIONS AND WARNINGS ................10 3.1. Symbols: meaning and application ..................10 3.2.

  • Page 11: Introduction

    1. INTRODUCTION This manual aim is to make a user acquainted with a proper operation, usage and adjustment of the mounted plough. Its aim is also warning about existing or possible threats. The manual also contains information on preparation of the plough for operation and for transportation on public roads.

  • Page 12: Safety Precautions And Warnings

    3. SAFETY PRECAUTIONS AND WARNINGS 3.1. Symbols: meaning and application In the present manual symbols are used in order to draw the reader’s attention and stress certain particularly important aspects requiring discussion. DANGER This indicates danger, with a possible serious accident risk. Not obeying recommendations marked with this sign may cause a situation of a serious risk of sustaining an injury by the operator and/or people nearby! Obey strictly these recommendations!

  • Page 13: Estimation Of Residual Risk

    ® Although BOMET company takes responsibility for pattern-designing and construction in order to eliminate danger, certain risk elements during mounted plough operation are unavoidable.
  • Page 14 General regulations  Apart from this manual, one shall also follow traffic regulations and occupational safety and health regulations.  Warnings (pictograms) placed on the plough give advice concerning safety of the user and other people, and avoiding accidents.  When driving on public roads, it is obligatory to follow regulations included in Highway Code.
  • Page 15  At each getting off the tractor by the operator, leave the plough in the lowered position.  Removing clogs can be performed after lowering the tool onto the ground and turning off the tractor engine.  It is not allowed to use tractor reverse gear during work, when the tool is in the working position.

  • Page 16: Standard Conformity

    General principles. 3.7. Manufacturer’s responsibility and guarantee ® In relation to described in this manual machine types, BOMET company does not acknowledge any civil responsibility towards: - improper or inconsistent with the manufacturer’s recommendations using the machine,...

  • Page 17: Safety Signs And Captions

    3.9 Safety signs and captions ® 1-beam mounted ploughs of U068 series of BOMET company are equipped with all devices that ensure safe work. Where it is not possible to secure dangerous places entirely due to the proper operation of the plough, there are warning signs – pictograms which indicate for possibility of danger and present manners of avoiding it.

  • Page 18: Usage Regulations

    4. USAGE REGULATIONS 4.1. General information 1-beam mounted ploughs of U068 series are produced in series as 3-furrow and 4- furrow ploughs with the possibility of mounting an attachment with 1-furrow. They are adjusted to work on terrain slopes not exceeding 8.5 and cooperate with tractors equipped with suspension system category II or III (see technical characteristics –...

  • Page 19: Equipment And Fittings

    Mounted ploughs of U068 series are connected to a tractor with the use of three-point suspension system consisting of the suspension axle with a rack which is supported by the long stay. The suspension axle is mounted in the hitches of the coupler head with the use of bearings which enable its movement and tilting.

  • Page 20: Preparing The Plough To Work

    Figure 2. Position of the lower rods Before suspension of the machine, lower rods of the tractor’s suspension system shall be set in lower position at the same height (distance between joints and the ground is minimum 200 mm). Rods set at the equal height from the ground facilitate mounting the plough on the tractor.

  • Page 21: Safety Instructions

    - tighten gently chains of lower rods of the tractor, keeping the symmetry between the plough suspension and the tractor, - link quick connects of hydraulic actuator hoses; - install portable light and warning signs and a triangular sign for low-speed vehicles transported on the tractor, CAUTION It is forbidden to connect the machine with a tractor when the tractor engine is running.

  • Page 22: Operation With The Mounted Plough

    Figure 4. Plough longitudinal levelling Properly levelled plough should have the frame set in parallel to the field surface and three-point suspension system rack should be set vertically. In such an adjusted plough, all plough bodies should work at the equal depth. After performing ploughing with such a levelled plough there should not be visible differences between the height of furrows put aside by individual bodies of the plough in the field.

  • Page 23: Plough Adjustment

    impairs the operation quality of the bodies, worsens soil crumbling and also quality of mixing and covering fertilizers and plant remnants, - turning and returning with the tool lowered may lead to serious damage both to the plough and the tractor, - during returns made with the tool opening the soil, it is necessary to increase the headland strip in order not to cause the collision between the plough and the tool, - in case of clogging of working elements (stone, plant remnants, other foreign matters in...
  • Page 24 Adjustment of the first furrow - setting the width of the first furrow is performed by shifting the three-point suspension system rack on the suspension axle (after loosening 3 screws) and adjustment with a turnbuckle B (Fig. 7) so as the point of the ploughshare first body is in the distance equalling nominal width of the body from the internal part of the right rear wheel.

  • Page 25: Technical Operation

    Adjustment of the mouldboard - the inclination angle of the mouldboard can be adjusted to a small extent by means of the rear bracket of the mouldboard connecting the skid strip with the rear wall of the mouldboard. IMPORTANT! As the working parts of the plough (skid, ploughshare) are subject to wear, the adjustment of the plough must be performed with the use of longitudinal adjustment.

  • Page 26: Working Parts Exchange

    elements shall be repeated in case of the preservative layer rinsed. Light and warning signs and a triangular sign for low-speed vehicles should be uninstalled from the plough and placed in a dry room, to be protected from being damaged. 5.4.

  • Page 27: Detection And Removal Of Failure

    5.5. Detection and removal of failure During ploughing, following failure can occur, which can affect unfavourably the plough operation quality, raise the application cost and also lead to damage both of the plough and the tractor. Table 2. Table of inefficiency reasons and methods of removal Symptoms Reason Method of removal...

  • Page 28: Transportation On Public Roads

    Table 3. Lubrication points Frequency Lubrication place Grease type of lubrication ŁT 42 grease Joints of the central connector 50 h ŁT 42 grease Bearings of the hitch lower axle 10 h ŁT 42 grease Adjustment screw of the first furrow 10 h ŁT 42 grease Bearings of the hydraulic actuator...

  • Page 29: Disassembly

    7. DISASSEMBLY Disassembly of the machine should be performed by people equipped with protective gloves and previously acquainted with its construction, after disconnecting it from the tractor, setting the machine on the flat and tough ground. Due to a number of plough parts exceeding 20 kg (frame, leg), during disassembly use lifting devices.

  • Page 30: Spare Parts Catalogue

    SPARE PARTS CATALOGUE How to use the catalogue. Spare parts catalogue includes other assemblies of the plough, marked with proper numbers of tables. The catalogue should be used as follows: - determine the proper assembly the exchanged part belongs to according to the tables, - find the needed part on the assembly table following the reference number from the set drawing.
  • Page 31 Table 1. 1-beam plough Positi Number of pieces in the plough KTM symbol or Part name standard number U068 U068/1 U068/2 U068/3 Fig. Main frame set 1068-01-001 1068-01-002 Subframe set 1068-01-003 1068-01-004 The main frame +1 1068-01-005 Subframe +1 1068-01-006 Coupler head with a handle 1068-02-001 Rack...
  • Page 32 Table 2. Plough body Positi KTM symbol or Number of pieces in the plough Part name standard U068 U068/1 U068/2 U068/3 Fig. number Core 1068-05-001 Skid 1068-05-002 Ploughshare 1068-05-003 Ploughshare chisel 1068-05-004 Breast 1068-05-005 Mouldboard wing 1068-05-006 Stiffening bracket 1068-05-007 Bracket fixing 1068-05-008 Strip chipper...
