Summary of Contents for Logitech MeetUp CC4000e

  • Page 1 MeetUp CC4000e Setup Guide · 设置指南...
  • Page 2 English 简体中文...
  • Page 3: What's In The Box

    FCC. Changes or modifications to product not expressly approved Ingestion Hotline at (3333-625 (202. It is available 24 hours a day. by Logitech, Inc could void your right to use or operate your by the FCC. POWER SUPPLY WARNING! The power supply is for indoor...
  • Page 4 WHAT’S WHAT CAMERA SPEAKERPHONE 1. Security slot 2. Remote control pairing 3. USB 4. Power 5. Optional expansion microphone English...
  • Page 5 REMOTE 1. Microphone mute 7. Camera pan/tilt 2. Call answer 8. Camera home 3. Call end 9. Camera preset 4. Bluetooth pairing * Please note that not all ® applications support call 5. Volume up/down answer and end buttons 6. Zoom in/out English...
  • Page 6 2. Connect the cables 3. Mount on the wall: a. Attach bracket to the wall Please use the appropriate type of screws for your wall type 4. Mount to the TV: An optional TV mount bracket is available on Logitech com English...
  • Page 7 CONNECTION 3. Connect the TV to the computer Connecting MeetUp is the same whether you plan on using a dedicated computer in the room, or your team members bring a laptop to the room to run the meeting 1. Plug MeetUp into power 2.
  • Page 8 The USB 2 0 cable included with Bluetooth pairing mode and select MeetUp supports FullHD video “Logitech MeetUp” (up to 1080p) If you plan on using 4k video, please use a USB 3 0 cable You are now ready to use MeetUp...
  • Page 9 – How to order replacement parts 1. Press and hold button on – And more at the back of the camera until LED www.Logitech.com/MeetUp flashes blue 2. Press and hold the Bluetooth button on the remote for 10 seconds to place it in pairing mode 3.
  • Page 10 FCC. Changes or modifications to product not expressly approved Ingestion Hotline at (3333-625 (202. It is available 24 hours a day. by Logitech, Inc could void your right to use or operate your by the FCC. POWER SUPPLY WARNING! The power supply is for indoor...
  • Page 11 硬件说明 摄像头扬声器电话 1. 安全槽 2. 远程控制配对 3. USB 4. 电源 5. 可选扩展麦克风 简体中文...
  • Page 12 遥控器 1. 麦克风静音 6. 放大/缩小 2. 接听电话 7. 摄像头平移/倾斜 3. 挂断电话 8. 摄像头主页 4. 蓝牙 ™ 配对 9. 摄像头预设 5. 音量增大/减小 * 请注意, 并不是所有应用都支持 接听和挂断电话按钮。 简体中文...
  • Page 13 感谢购买 CC4000e! 期待更宽的视野能让与会者都感觉到自己已加入会 议之中, 让沟通更进一步。 b. 将摄像头固定到支架上。 放置 建议尽可能地将摄像头放在齐眼 高度。 效果较好的安装位置通常是 显示器下方。 1. 置于靠近显示器的台面或架子上。 2. 连接接线。 3. 安装到墙上: a. 将支架安装到墙上。 请根据墙壁 类型使用适当的螺丝。 4. 安装到电视上: 可供选配的电视 安装支架, 请访问 Logitech com 选购。 简体中文...
  • Page 14 3. 将电视连接到电脑。 连接 无论是在会议室中使用专用电脑, 还是由团队成员带笔记本来召开 会议, CC4000e 的连接方式都是一 样的。 1. 为 CC4000e 插上电源。 2. 用 USB 线连将 CC4000e 连接到 电脑。 全部连接示意图: HDMI 简体中文...
  • Page 15 就可轻松完成: 1. 按住遥控器上的 蓝牙 按钮, 直到看 有关 4K 高清视频的说明 到摄像头镜头附件闪烁蓝色。 2. 将移动设备置于 蓝牙 配对模式, CC4000e 随附的 USB 2 0 接线支持全 并选择“Logitech MeetUp”。 高清视频 (不超过 1080p)。 如果您要 使用 4k 超高清, 请使用 USB 3 0 接线 至此, 您就可使用 CC4000e 进行视频 (未提供)。 呼叫了。...
  • Page 16 – 常见问题解答 器进行配对 (例如, 更换丢失的遥控 – 支持不同应用程序功能的软件 器时), 请按以下步骤操作: – 如何订购替换件 1. 按住摄像头后面的按钮, 直至 LED 闪烁蓝色。 – 以及更多, 请访问 www.Logitech.com/MeetUp 2. 按住遥控器上的 蓝牙 按钮并保持 10 秒, 借此将遥控器置于配对模式。 3. 在遥控器和摄像头已配对后, LED 将停止闪烁。 4. 如果配对失败, 则 LED 将保持 闪烁。 从第 2 步开始重新执行。 简体中文...
  • Page 17 产品中有害物质的名称及含量 根据中国<<电子电气产品有害物质限制使用标识要求>> 有害物质 Hazardous Substances 部件名称 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 Parts Name (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) 电缆线/电源 Cable/Adaptor 电路板组件 PWAs 塑料/其它部件 Plastic/Others parts 玻璃部件 Glass parts 金属部件 Metal parts 电池 Battery 本表格依据 SJ/T 11364 的规定编制。 O =表示该有害物质在该部件均质材料中的含量均在 GB/T 26572 规定的限量要求以下。 X =表示该有害物质至少在该部件的某一均质材料中的含量超出...
  • Page 20 © 2017 Logitech Logitech, 罗技, Logi and other Logitech marks are owned by Logitech and may be registered All other trademarks are the property of their respective owners Logitech assumes no responsibility for any errors that may appear in this manual Information contained herein is subject to change without notice 版权所有...
