Page 1: User Manual
WLCB54GS 108M Wireless Cardbus Adapter User Manual... -
Page 3: Table Of Contents
6.2 Setting WEP 6.3 Setting WPA [WPA-PSK] [WPA-Enterprise] ... 28 7. Utility Introduction 7.1 Configuration 7.2 Status 7.3 Option 7.4 About ... 31 8. FAQ ... 33 9. Specification ... 34 10. About corega ... 6 ...12 ...14 ... 21 WLCB54GS Manual... -
Page 4: Features
Preface WLCB54GS Manual corega WLCB54GS gives you both freedom of movement and flexibility of access! Designed to the IEEE802.11g specification, this versatile PC card offers speeds up to nearly five times fast- er than widely deployed IEEE 802.11b wireless networks found in homes, businesses, and public wireless hotspots around the world. -
Page 5: Hardware Description
WLCB54GS Manual 1.3 Hardware description... -
Page 6: Wireless Lan Modes
WLCB54GS Manual 1.5 Wireless LAN Modes There are two basically modes of networking for setting: A. Infrastucture mode Infrastructure networking differs from ad-hoc networking in that it includes an access point. Unlike the ad-hoc struc- ture where users on the LAN contend the shared band- width, on an infrastructure network the access point can manage the bandwidth to maximize bandwidth utilization. -
Page 7: Ad-Hoc Mode
Connect to Internet Modem Notebook with installed WLCB54GS B. Ad-Hoc mode Also known as a peer-to-peer network, an ad-hoc network is one that allows all workstations and computers in the network to act as servers to all other users on the network. Users on the network can share files, print to a shared printer, and access the Internet with a shared modem. -
Page 8: Software Installation
Software Installation WLCB54GS Manual 2.1 Before You Start.. 1. Hardware Installation: please insert corega WLCB54GS into the carbus slot in your notebook first, and when it appears following screen please click [Cancel] to ignore it. 2. Please prepare OS installation driver CD (Windows 98/Me) before the installation. -
Page 9: Install Software
2. Please select [English]. 3. Please select [Install Software]. WLCB54GS Manual... - Page 10 WLCB54GS Manual 4. Click [Next]. 5. Please confirm the path, if no changes please click [Next].
- Page 11 6. Click [Next]. 7. Finished, please choose [Yes]=>computer restart. WLCB54GS Manual...
-
Page 12: Driver Installation
Driver Installation WLCB54GS Manual 1. After restarting the computer, it will show up [Found New Hardware] screen, if not, please re-insert corega WLCB54GS again 2. When it shows up below screen, please click [Continue Anyway] (or [Yes] in Windows 2000 OS) directly without worries. - Page 13 [In Windows 2000] 3. Now driver installation is completed, and icon appears on system tray. WLCB54GS Manual you will see 11 11...
-
Page 14: Setting Network Protocol
Setting Networking Protocol WLCB54GS Manual 1. From the [Start Menu], select [Settings] => select [Control Panel]=>select [Network]=> press right button of the mouse, and select [properties]. 2. In [General] tab, Please select [Internet Protocol (TCP/IP)]=> click [Properties]. 12 12 12... - Page 15 3. Please select [General] tab => select both [Obtain an IP address automatically] and [Obtain DNS server address automatically] (Recommended) => click [OK]. 4. Return back to [Local Area Connection Properties] screen => click [OK] to close it. WLCB54GS Manual 13 13...
-
Page 16: Wireless Configuration
5.1 Connect to AP (Infrastructure Mode) 1. Double click the utility screen. If there’s no tray, please press [Start] => [Programs]=>[corega CG- WLCB54GS]=> [Wireless LAN Utility]. 2.You will see available AP listing in [Availabe WLANs] from Configuration tab. If it displays nothing, please press [Re- fresh], else, please verify the AP setting. - Page 17 3. Please select one of available AP listing => then press [Add] button, or double click the selection, => it will show up [Wirless Newtork Properties] screen, if the selection has configured with WEP/WPA encryption, please make the same setting as its. (Regarding encryption configuration please refer Chapter 6) =>...
-
Page 18: Connect To Network Adapter (Ad-Hoc Mode)
5.2 Connect to network adapter (Ad-Hoc Mode) 1. Double click the Utility screen. If you can’t see tray, please press [Start] => [Programs] =>[corega CG- WLCB54GS] => [Wireless LAN Utility]. 2. Please select the ESSID with 16 16 icon on the left side of the device name... - Page 19 mode]) on the left side in [Available WLANs] of [Configura- tion] tab, => and press [Add] button or double click the selection. 3. Please select one of the listing, =>then press [Add] button, or double click the selection, => it will show up [Wireless Network Properties] screen, if the selection had configured with WEP/WPA encryption, please make the same setting as its.
- Page 20 WLCB54GS Manual 4. Please Press [Apply] to get ready to connect with the device (AP) 18 18...
-
Page 21: If No Available Ap For Connecting
*Note: 1.You will see a WLCB54GS has connected with the device. 2.You may press [Preferred WLANs], and you may click of them, =>then press [Apply] to save the changes. 3. Please verify it can connect to internet successful or not. 5.3 If no available AP for connecting.. - Page 22 WLCB54GS Manual 3.The device (AP) had added in the listing of [Preferred WLANs], =>press [Apply] 20 20 20...
-
Page 23: Security Configuration
Security Configuration There are 4 security setting ways for preventing intruders from Wireless LAN. • ESSID (Extended Service Set IDentifier) ESSID (or SSID) is the name of a wireless local area network (WLAN). All wireless devices on a WLAN must employ the same ESSID in order to communicate with each other.You may set either manually, by entering the SSID into the cli- ent network settings, or automatically, by leaving the SSID... -
Page 24: Setting Essid
6.1 Setting ESSID 6.1.1 Double click up the Utility screen. If you can’t see tray, please press [Start] => [Programs]=>[corega CG- WLCB54GS]=> [Wireless LAN Utility]. 6.1.2 Press [New] button. 3. It will show up [Wireless Network Properties] screen, key in the same ESSID name as the AP which will be connected to, =>... -
Page 25: Setting Wep
6.2 Setting WEP 6.2.1 Double click up the Utility screen. If you can’t see tray, please press [Start] => [Programs]=>[corega CG- WLCB54GS]=> [Wireless LAN Utility]. 6.2.2 Select one of available ESSIDs in [Availabe WLANs]. icon on system tray, and it will show... - Page 26 WLCB54GS Manual 6.2.3 Shows up [Wireless Network Properties] screen, => fill in below items: (a) [Authentication Mode]: Please select [Open System] (Recommended) or [Shared Key]. (b) [Data Encryption]: select [WEP]. (c) [Key length]: select [64 bits or 128 bits] (d) [Key1]~[Key 4]: enter the same passwords as AP (e) [Default Key]: select the default key.
-
Page 27: Setting Wpa
(c) Press [Authentication Config], it will shows following screen, please enter the password which you first get connected in [WPA Passphrase], and then press [OK] button. (d) When return back to [corega Wireless LAN Utility] screen, press [Apply] to save the changes. WLCB54GS Manual... -
Page 28: [Wpa-Enterprise]
WLCB54GS Manual [WPA-Enterprise] 26 26... - Page 29 (b) Data Encryption: select [TKIP] or [AES]. (c) Press [Authentication Config] button, it will show up fol- lowing screen, => select [EAP Type], => press [OK]. (d) When return back to [corega Wireless LAN Utility] screen, press [Apply] to save the changes. WLCB54GS Manual...
-
Page 30: Utility Introduction
Utility Introduction WLCB54GS Manual 7.1 Configuration This tab is for setting communication mode, ESSID, channel, and WEP encryption function. (1) Refresh: rescan available wireless devices. (2) Add:press this button will add the device which has been selected from [Available WLANs] to [Preferred WLANs], and in the meanwhile it will show up the prop- erties setting screen. -
Page 31: Status
(6) New: add a new available device in [Preferred WLANs]. (7) Remove: select one of devices from [Preferred WLANs], => then press [remove], it will be removed. (8) Properties: select one of devices from [Preferred WLANs], => press this button, then it will show up a [Wireless Network Properties] screen for you to modify. -
Page 32: Option
WLCB54GS Manual 7.3 Option This tab is for advanced setting. 7.4 About “About” tab shows you copyright, and utility and driver ver- sion information. 30 30 30... -
Page 33: Faq
(1) First, please see following “FAQ” to check your problem. (2) Please go to http://www.corega-asia.com, then click “Supports”=>select “Online Customer Support” , => fill in the form, =>click “submit” . We’ll reply you as soon as possible. - Page 34 WLCB54GS Manual supports=>download =>select “driver” , =>select and click the model which you want to upgrade. Q4. Windows can’t recognize WLCB54GS. (1) Please make sure that WLCB54GS is inserted into the Cardbus slot of your notebook properly (check this when the notebook is powered off ). (2) Please check if PC Card support is installed.
-
Page 35: Specification
Specification Compliance Standard LAN Interface Protocol Transmission Method Network Type Frequency Band Transmission Rate Transmitter Output Power Coverage Area Roaming Security Antenna Type Power Specifications Support OS Environmental Requirements Operating Storage Physical Specifications Dimension Weight Certification IEEE802.11/IEEE802.11b/IEEE802.11g 32 bit CardBus (Type II PC Card) CSMA/CA DS-SS, OFDM Infrastructure/802.11 Ad-Hoc... -
Page 36: About Corega
Established in 1986, corega 100% founded by Allied Tel- esis Group in Yokohama, Japan. corega’s core products consists of 10/100/1000 Ethernet products, Wireless Networking Products(802.11 a/b/g series), broadband... - Page 38 Taiwan Inc. 7F., No. 10, Lane 345,YangGuang St. Nei-Hu Chiu, Taipei City 114, Taiwan R.O.C. TEL: +886-2-8751-9164 FAX: +886-2-8751-9174 PN: S30-UM8308-00 Rev.A...
