Summary of Contents for Nextiva X885
- Page 1 SIP Color Deskset X885 Quick Start Guide NXT885 AW...
-
Page 2: Important Safety Information
Important Safety Information This symbol is to alert you to important operating or servicing instructions that may appear on the product or in this user’s manual. Always follow basic safety precautions when using this product to reduce the risk of injury, fire, or electric shock. WARNING: The product included (ITE) in this manual is to be connected only to PoE networks without routing to the outside plant. - Page 3 or create a short circuit. Never spill liquid of any kind on the product. 12. To reduce the risk of electric shock, do not disassemble this product, but take it to an authorized service facility. Opening or removing parts of the telephone base or handset other than specified access doors may expose you to dangerous voltages or other risks.
-
Page 4: Mesures De Sécurité Importantes
19. Use only the power cord indicated in this manual. Power adapter rating: 5 Vdc @ 2 A 20. For pluggable equipment, the socket-outlet shall be installed near the equipment and shall be easily accessible. 21. In wall mounting position, make sure to mount the telephone base on the wall by aligning the eyelets with the mounting studs of the wall plate. - Page 5 6. N’utilisez pas ce produit près de l’eau, tel que près d’un bain, d’un lavabo, d’un évier de cuisine, d’un bac de lavage ou d’une piscine, ou dans un sous-sol humide ou sous la douche. 7. Ne déposez pas ce téléphone sur un chariot, support ou table chancelants. L’appareil pourrait tomber et être sérieusement endommagé.
- Page 6 son état de fonctionnement normal. E. Si l’appareil a été échappé ou son boîtier, endommagé. Si le produit affiche une nette diminution de sa performance. 15. Évitez d’utiliser un téléphone (autre qu’un sans fil) pendant un orage. Les éclairs peuvent être à l’origine d’une électrocution. 16.
- Page 7 FCC part 15 This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 8 Industry Canada This Class A digital apparatus complies with Canadian requirements: CAN ICES-3 (A)/NMB-3(A). Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada. This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
-
Page 9: About This Guide
About this Guide This quick start guide provides a reference for the external features of the phone and basic installation instructions. Please refer to the X885 User Guide for complete installation and operation instructions. You can download the guide from nextiva.com/resources/guides.html nextiva.com/products.html... - Page 10 Quick Reference Guide External Features and Controls CALL LED SCREEN FUNCTION KEYS MWI KEY with LED NAVIGATION KEYS DEDICATED, CUSTOMIZABLE FUNCTION KEYS PROGRAMMABLE KEYS P1-P6 with FUNCTION KEY SCREEN CASING MICROPHONE PAGES KEY for ALPHANUMERIC AUDIO NXT885 AW FUNCTION KEY KEYPAD CONTROL SCREEN...
-
Page 11: Deskset Installation
For more information about installation options and phone setup, see the nextiva.com/resources/guides.html X885 User Guide, available at You can power the phone using a compatible AC power adapter or using Power over Ethernet (PoE) from your network. (The phone requires PoE Class 2.) If you are not using PoE, install the phone near a power outlet not controlled by a wall switch. -
Page 12: Attaching The Footstand
Attaching the Footstand... -
Page 13: Connecting The Phone
Connecting the phone (2, 3) (2, 3) (2, 3) (1, 2) (2, 3) If no PoE available Not included in delivery Optional... - Page 14 Connecting the phone The phone can be operated with Power over Ethernet (PoE) provided via the network cable or, if PoE is not available in your network, with the separately available 5V DC power adapter. • Plug the Ethernet (network) cable into the RJ45 connector labeled “NET”, and plug the other end into the network side to establish a data link.
- Page 15 7. Reboot the phone. 8. Enter the password received from your Internet service provider or administrator. Press to save. After successful registration, you will see the idle screen. For further information, please refer to the X885 User Guide.
-
Page 16: Maintenance
Maintenance Taking care of your telephone • Your telephone base contains sophisticated electronic parts, so you must treat it with care. • Avoid rough treatment. • Place the corded handset down gently. • Save the original packing materials to protect your telephone base if you ever need to ship it. -
Page 17: Technical Specifications
Technical Specifications Operating temperature 32–104 °F (0–40 °C) AC adapter output voltage 5.0 Vdc @ 2 A AC adapter model number Model #: VSP-PWR2000 SIL model #: SSA-050200US Ten Pao model # S018BAM0500200 Connectors 2 x RJ45 (1 x LAN, 1 x PC) 2 x 4P4C (handset, optional wired headset) 1 x USB 2.0 type A 1 x proprietary connector for Expansion module... - Page 20 NEXTIVA, INC. Distributed in the U.S.A. by VTech Communications Inc., Beaverton, Oregon 97008. VTech is a registered trademark of VTech Holdings Limited. Copyright © 2018 for VTECH COMMUNICATIONS LTD. All rights reserved. Printed in China. Version 1, 04/18...
- Page 21 Remarks • Use only Ethernet cable packed in the giftbox. • Ferrite Cores are incorporated with Ethernet cable.
