- Page 1 All manuals and user guides at all-guides.com Monogram.™ Use and Care & Installation Guide for ZGU660 ZGU661 Downdraft 36″ Gas Cooktop...
- Page 2 Whether you chose it for its purity of design or assiduous attention to detail, you’ll find that your Monogram cooktop’s superior blend of form and function will delight you for years to come. The ZGU660 and the ZGU661 Monogram cooktops were designed to provide the flexibility to blend in with your kitchen cabinetry.
- Page 3 All manuals and user guides at all-guides.com Before using your cooktop, read this guide carefully. It is intended to help you operate and maintain your new cooktop properly. Keep it handy for answers to your questions. If you don’t understand something or need more help, call: ®...
- Page 4 All manuals and user guides at all-guides.com IMPORTANT SAFETY INSTRUCTIONS Read all instructions before using this appliance. IMPORTANT SAFETY NOTICE WARNING—TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO • The California Safe Drinking Water and Toxic PERSONS, OBSERVE THE FOLLOWING: Enforcement Act requires the Governor of California to publish a list of substances known A.
- Page 5 All manuals and user guides at all-guides.com • Do not clean the cooktop with flammable or • To minimize the possibility of burns, ignition of volatile cleaning fluids. flammable materials and spillage, turn cookware handles toward the side or center of the cooktop •...
- Page 6 SAVE THESE INSTRUCTIONS FEATURES OF YOUR COOKTOP Models ZGU660 and ZGU661 1. Vent 6. Fan Speed Control 2. Vent Filters (behind the grille) 7. Vent Control 3.
- Page 7 All manuals and user guides at all-guides.com Electric Ignition Auto Relight All of the burners on this cooktop are equipped with The burners on this cooktop relight automatically electric igniters that eliminate the need for standing if the flame goes out. This helps prevent the pilot lights.
- Page 8 All manuals and user guides at all-guides.com USING YOUR COOKTOP Electric Ignition Your surface burners are lighted by electric ignition, Surface burners in use when an electrical power eliminating the need for standing pilot lights with failure occurs will continue to operate normally. constantly burning flames.
- Page 9 All manuals and user guides at all-guides.com Cookware Aluminum: Medium-weight cookware is Heatproof Glass Ceramic: Can be used for recommended because it heats quickly and evenly. either surface or oven cooking. It conducts heat Most foods brown evenly in an aluminum skillet. very slowly and cools very slowly.
- Page 10 All manuals and user guides at all-guides.com COOKTOP VENT SYSTEM The built-in vent system helps remove cooking vapors, odors and smoke from foods prepared on the cooktop. Continuous use of the vent system helps keep the kitchen comfortable and less humid, reducing cooking odors and soiling moisture that normally creates a frequent need for cleaning.
- Page 11 All manuals and user guides at all-guides.com CARE AND CLEANING Proper care and cleaning are important so your cooktop will give you efficient and satisfactory service. Follow these directions carefully in caring for it. Before cleaning any part of your cooktop, be sure all burners are off and DISCONNECT ELECTRICAL POWER TO THE COOKTOP at the fuse box or circuit breaker panel, or pull the cooktop power plug, located beneath the cooktop and inside the cabinets.
- Page 12 All manuals and user guides at all-guides.com CARE AND CLEANING (continued) Burner Assembly The burner assemblies should be wiped clean often. Turn all controls OFF before removing burner parts. The electrode of the spark igniter is exposed Burner Grate when the top of the burner is removed. Be careful not to push in any surface unit controls while the top of a burner is removed.
- Page 13 All manuals and user guides at all-guides.com INSTALLATION INSTRUCTIONS BEFORE YOU BEGIN IMPORTANT SAFETY INSTRUCTIONS The cooktop has been design certified by the Read these instructions completely and American Gas Association. As with any appliance carefully. using gas and generating heat, there are certain IMPORTANT–OBSERVE ALL GOVERNING safety precautions you should follow.
- Page 14 All manuals and user guides at all-guides.com INSTALLATION INSTRUCTIONS (continued) STEP 1 STEP 2 PREPARING FOR INSTALLATION PREPARING THE COUNTERTOP 36″ min ″ Not less than 1 ⁄ ″ 13″ 25″ ⁄ ″ ⁄ 30″ 18″ 8″ min ″ min. ″...
- Page 15 All manuals and user guides at all-guides.com STEP 4 Cut hole in the cabinet wall or floor as appropriate for your installation. Make sure PROVIDE ADEQUATE GAS SUPPLY the exhaust duct is located between wall studs or This cooktop is designed to operate on the floor joists.
- Page 16 All manuals and user guides at all-guides.com INSTALLATION INSTRUCTIONS (continued) STEP 6 STEP 7 INSTALL THE DOWNDRAFT UNIT INSTALLING THE COOKTOP Remove the Remove all packaging material from the cooktop. downdraft unit Position the cooktop over the cut-out opening and carefully lower it into place, making sure from the that the power cord is dropped into the cabinet.
- Page 17 All manuals and user guides at all-guides.com STEP 7 (continued) Appropriate flare union adapters are required at each end of the flexible connector. INSTALLING THE COOKTOP Turn on the gas; check for leaks using a NOTE: If the cooktop is installed in a 36 inch liquid leak detector at all joints in the system base cabinet, the mounting brackets cannot be (the pressure test nipple is adjacent to the gas...
- Page 18 All manuals and user guides at all-guides.com INSTALLATION INSTRUCTIONS (continued) Total STEP 10 Equivalent Number Equivalent Duct Pieces Length* Used Length ELECTRICAL CONNECTION 1 ft. Electrical requirements: 6″ round, (per foot 120 volt, 60 Hertz, individual, properly grounded straight length) feet branch circuit protected by a 15 amp circuit 1 ft.
- Page 19 All manuals and user guides at all-guides.com STEP 12 CHECK OPERATION OF DOWNDRAFT To raise the vent, turn the VENT knob to RAISE. Hold the knob at the RAISE position until the vent is fully extended. The vent will automatically stop when it is fully extended or when the VENT knob is released.
- Page 20 All manuals and user guides at all-guides.com CONVERTING TO LP GAS or Converting Back to Natural Gas from LP This cooktop leaves the factory set for use with natural gas. If you convert to LP gas, keep these CONVERT THE SURFACE KNOBS instructions and orifices in case you want to convert 1.
- Page 21 All manuals and user guides at all-guides.com CONVERTING TO LP GAS or Converting Back to Natural Gas from LP CONVERT THE SURFACE BURNERS CONVERT THE PRESSURE REGULATOR WARNING: Do not remove the pressure Top Grate regulator from the cooktop. 1. Locate the pressure regulator under the rear of the cooktop.
- Page 22 All manuals and user guides at all-guides.com CONVERTING TO LP GAS or Converting Back to Natural Gas from LP CHECK FOR LEAKS CHECK QUALITY OF FLAMES The combustion quality of burner flames needs When all connections have been made, make to be determined visually.
- Page 23 All manuals and user guides at all-guides.com QUESTIONS? USE THIS PROBLEM SOLVER PROBLEM POSSIBLE CAUSE BURNERS DO NOT • Make sure electrical plug is plugged into a live power outlet. LIGHT • Slot in burner base may be clogged. Remove the obstruction. •...
- Page 24 All manuals and user guides at all-guides.com NOTES...
- Page 25 All manuals and user guides at all-guides.com NOTES...
- Page 26 All manuals and user guides at all-guides.com We’ll Be There With the purchase of your new Monogram appliance, receive the assurance that if you ever need information or assistance from GE, we’ll be there. All you have to do is call—toll-free! GE Answer Center®...
- Page 27 All manuals and user guides at all-guides.com Staple sales slip or cancelled check YOUR MONOGRAM COOKTOP here. Proof of original purchase date WARRANTY is needed to obtain service under warranty. WHAT IS COVERED FULL ONE-YEAR WARRANTY This warranty is extended to...
- Page 28 All manuals and user guides at all-guides.com Pub. No. 49-8715 Part No. 183D5580P003 10-95 CG Monogram. Printed in Mexico General Electric Company Louisville, KY 40225...
