Model: 308-146v2
Instruction Manual
DC: 112618
WIRELESS ATOMIC COLOR FORECAST STATION
Table of Contents
Initial Setup ............................................................................................ 2
Atomic Time Search .............................................................................. 3
LCD Features .......................................................................................... 3
Buttons (back view) .............................................................................. 4
Set Time, Date, etc. .............................................................................. 4
Fahrenheit/Celsius Temperature Display .......................................... 5
Time Alarm .............................................................................................. 5
Activate/Deactivate the Alarm ............................................................ 5
Snooze ..................................................................................................... 6
Weather Forecast Icons ........................................................................ 6
Backlight .................................................................................................. 6
Heat Index | Dew Point ........................................................................ 7
pg. 1
308-146
www.lacrossetechnology.com/support
Advertisement
Table of Contents
Related Manuals for La Crosse Technology 308-146v2
Summary of Contents for La Crosse Technology 308-146v2
-
Page 1: Table Of Contents
Model: 308-146v2 Instruction Manual DC: 112618 WIRELESS ATOMIC COLOR FORECAST STATION Table of Contents Initial Setup .................... 2 Atomic Time Search ................3 LCD Features ..................3 Buttons (back view) ................4 Set Time, Date, etc................4 Fahrenheit/Celsius Temperature Display .......... 5 Time Alarm .................... -
Page 2: Initial Setup
MIN/MAX Values ..................7 Multiple Sensors ..................7 Channel Scroll ..................8 USB Charge Port ..................8 Restart ..................... 8 Specifications ..................9 Position Station ..................10 Position Outdoor Sensor..............10 Care and Maintenance ................ 10 Warranty and Support ................ 11 FCC Statement .................. -
Page 3: Atomic Time Search
Atomic Time Search The LCD backlight and USB charging port will momentarily turn off while the station searches for the atomic signal. After the initial search, this station will only search for the atomic signal after midnight. Press the +/RCC button to start or stop a manual signal search. •... -
Page 4: Buttons (Back View)
Buttons (back view) Set Time, Date, etc. 1. Hold the SET button to enter time set mode. 2. Press the +/RCC or -/ºC/ºF buttons to adjust values. 3. Press the SET button to confirm and move to the next item. Settings order: 1. -
Page 5: Fahrenheit/Celsius Temperature Display
7. Year 8. Month 9. Date Press the -/ºC/ºF button to exit or wait 20 seconds to exit. Fahrenheit/Celsius Temperature Display From the normal time display, press the -/ºC/ºF button to select Fahrenheit or Celsius temperature display. Time Alarm 1. Hold the ALARM button 3 seconds to enter alarm time set mode. -
Page 6: Snooze
Snooze When alarm sounds, press the LIGHT/SNOOZE button to • silence the alarm for 10 minutes. The alarm icon will flash. • In snooze mode, press any button to stop alarm for one • day. Note: The alarm is crescendo sound. The alarm will sound for 2 minutes and then shut off completely. -
Page 7: Heat Index | Dew Point
Heat Index | Dew Point Press the HEAT/DEW button once to view Heat Index. • Press the HEAT/DEW button twice to view Dew Point. • MIN/MAX Values The station automatically resets minimum and maximum values daily at midnight (12:00 AM). Press the MIN/MAX button to view maximum values. -
Page 8: Channel Scroll
Press and release the CH button to view channel 1, 2 or 3 on the forecast station Channel Scroll The word AUTO will appear when the forecast station is set to scroll through the channels automatically. Press the CH button repeatedly until AUTO is displayed. The •... -
Page 9: Specifications
Specifications Indoor: Temperature Range: +32°F to +122°F (0°C to 50°C) Humidity Range: 10%-99% (RH) Interval: About every 30 seconds Outdoor: Temperature Range: -40°F to 140°F (-40°C to 60°C) Alkaline Batteries: -20°F to 140°F (-28.8°C to 60°C) Lithium Batteries: -40°F to 140°F (-40°C to 60°C) Temperatures below - 20°F (-28.8°C) require NOTE: Lithium batteries in the outdoor sensor. -
Page 10: Position Station
Position Station The station is designed to sit on a desk or table. For best WWVB reception orientate the station with the • front of the back facing Ft. Collins, Colorado. Choose a location 6 feet or more from electronics such as •... -
Page 11: Warranty And Support
Warranty and Support La Crosse Technology, Ltd. provides a 1-year limited time warranty (from date of purchase) on this product relating to manufacturing defects in materials & workmanship. Before returning a product, please contact our friendly customer support with questions or visit our online help (manuals and FAQS): Phone: 1-608-782-1610 Online Product Support: www.lacrossetechnology.com/support... -
Page 12: Fcc Statement
FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
