Thank you for purchasing the E-flite Park 180 Brushless Outrunner motor. This motor is ideal for 3D models 2-3 oz
(55-85g), and sport and scale models 3-6 oz (85-170g) or models requiring up to 30 watts of power.
Park 180 Brushless Outrunner Features:
• Ideal for 3D models 2-3 oz (55-85g) and sport and scale models 3-6 oz (85-170g)
• Ideal for up to 30 watts
• Designed for firewall mount or carbon tube mount
• Includes mount, mounting hardware, and 2mm gold BL connectors
• Extremely quiet and lightweight - just .3 ounces (8.5 grams)
• Upgraded performance motor for indoor motors
• High quality construction with ball bearings and hardened steel shaft
• Slotted 12-pole outrunner design
Park 180 Specifications
Diameter: 16mm (.63 in)
Case Length: 20mm (.80 in)
Weight: 8.5 g (.30 oz)
EFLM1120
Kv: 2200 (rpms per volt)
Io: .30A @ 8V (no load current)
Ri: .91 ohms (resistance)
Continuous Current: 2.6A*
Max Burst Current: 3.2A*
Cells: 2-3S Li-Po or 4-8 Ni-MH/Ni-Cd
Recommended Props: 3x3 to 6x3 'Slow Flyer' for 2S or 4x4 to 4.5x3 for 3S
Brushless ESC: 4A – 6A
* Maximum Operating Temperature: 220 degrees Fahrenheit
* Adequate cooling is required for all motor operation at maximum current levels.
* Maximum Burst Current duration is 15 seconds. Adequate time between maximum burst intervals is required for
proper cooling and to avoid overheating the motor.
* Maximum Burst Current rating is for 3D and limited motor run flights. Lack of proper throttle management may result
in damage to the motor since excessive use of burst current may overheat the motor.
Battery Choices:
There are many Li-Po battery brands on the market with several choices for consumers. We recommend either E-flite
or Thunder Power batteries and list some possible choices for the Park 180 Brushless Outrunner motor, depending on
the airplane application.
THP4802SJPL
THP48023JPL
Examples of Airplane Setups:
Semi-Scale Aerobatic Biplane
Weight w/Battery: 4.2 oz
Prop 6 x 3 Slow Flyer
Battery: 480mAh 2-Cell 7.4V Li-Po (THP4802SJPL)
ESC: 4A-5A Brushless
Comments – Great aerobatic performance with plenty of flight time.
Park 180 Brushless Outrunner Instructions
480mAh 2-Cell 7.4V LIPO, JST
480mAh 3-Cell 11.1V LIPO, JST
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for E-FLITE Park 180
Summary of Contents for E-FLITE Park 180
- Page 1 Park 180 Brushless Outrunner Instructions Thank you for purchasing the E-flite Park 180 Brushless Outrunner motor. This motor is ideal for 3D models 2-3 oz (55-85g), and sport and scale models 3-6 oz (85-170g) or models requiring up to 30 watts of power.
- Page 2 EFLM1933 Prop Adapter with Setscrew, 1.5mm EFLM1962 Carbon Fiber Tube, 6”, 7mm OD, 5mm ID: Park 180 Operating Instructions: 1. This brushless motor requires the use of a sensorless brushless speed control. Failure to use the correct speed control may result in damage to the motor and/or speed control.
- Page 3 1. Attach the aluminum x-mount to the fixed outer main shaft housing and tighten the set screw to secure the mount to the motor. 2. Attached the aluminum x-mount and motor to the outside of the firewall using the two wood screws. NOTE: Photo shows installation using a carbon fiber tube, with 7mm OD, 5mm ID (EFLM1963 available separately).
- Page 4 Motors requiring inspection or repair should be shipped to the following address (freight prepaid): Horizon Service Center 4105 Fieldstone Road Champaign, Illinois 61822 E-flite is an exclusive brand of Horizon Hobby, Inc. (877) 504-0233 www.E-fliteRC.com / www.horizonhobby.com © 2007 Horizon Hobby, Inc...
