ITEM #0670250
80 V STRING TRIMMER
MODEL #KST 140XB
Español p. 22
ATTACH YOUR RECEIPT HERE
Serial Number
Purchase Date
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-888-3KOBALT (1-888-356-2258), 8 a.m. - 8 p.m., EST,
Monday - Friday.
AB15155
1
Advertisement
Table of Contents
Related Manuals for Kobalt KST 140XB
Summary of Contents for Kobalt KST 140XB
- Page 1 ITEM #0670250 80 V STRING TRIMMER MODEL #KST 140XB Español p. 22 ATTACH YOUR RECEIPT HERE Serial Number Purchase Date Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-888-3KOBALT (1-888-356-2258), 8 a.m. - 8 p.m., EST, Monday - Friday.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Package Contents......................... Hardware Contents....................... Symbols..........................Safety Information......................... Preparation ........................... Assembly Instructions ......................Operating Instructions ......................Care and Maintenance ......................Troubleshooting........................Warranty..........................Replacement Parts List ......................PRODUCT SPECIFICATIONS SPECIFICATIONS Type Cordless, battery-powered Battery 80 V Lithium-Ion Speed 5,000 RPM (low); 5,500 RPM (high) Cutting path 14 in. -
Page 3: Package Contents
PACKAGE CONTENTS PART DESCRIPTION QUANTITY PART DESCRIPTION QUANTITY Spool Trigger switch (preassembled to spool Side lock button housing) Power button Spool cap Front/Auxiliary handle (preassembled to spool Coupler housing) Cut-off blade Spool housing Guard Speed control button Tube Release button Lower tube Positioning hole Spool cover... -
Page 4: Hardware Contents
HARDWARE CONTENTS (not shown actual size) Fastening knob Bolt Screw (preassembled Qty. 1 Qty. 1 to the Guard (H)) Qty. 4... -
Page 5: Symbols
SYMBOLS Some of the following symbols may be used on this product. Please study them and learn their meaning. SYMBOLS DESIGNATION EXPLANATION Volts Voltage Amperes Current Hertz Frequency (cycles per second) Watts Power Minutes Time Alternating Current Type of current Direct Current Type or a characteristic of current Class II Construction... - Page 6 SYMBOLS Save these Instructions The following signal words and meanings are intended to explain the levels of risk associated with this product. SYMBOL SIGNAL MEANING Indicates an imminently hazardous situation, which, if not avoided, will DANGER result in death or serious injury. Indicates a potentially hazardous situation, which, if not avoided, could WARNING result in death or serious injury.
-
Page 7: Safety Information
• Battery tools do not have to be plugged into an electrical outlet; therefore, they are always in operating condition. Be aware of possible hazards when not using your battery tool or when personal injury. • Remove or disconnect battery before servicing, cleaning or removing material from the gardening appliance. batteries. • Use only 80-volt Kobalt ®... - Page 8 SAFETY INFORMATION • When not in use, the string trimmer should be stored indoors in a dry, locked place out of the reach of children. • special disposal instructions. Do not open or damage the batteries. Released electrolyte is corrosive and may cause damage to the eyes or skin.
-
Page 9: Preparation
SAFETY INFORMATION Child safety Tragic accidents can occur if the operator is not aware of the presence of children. • Keep children out of the working area and under the watchful care of a responsible adult. • Do not allow children under the age of 14 to operate this trimmer. Children who are 14 years of age or older must read and understand the operating instructions and safety rules in this manual and must be trained and supervised by a parent. -
Page 10: Assembly Instructions
ASSEMBLY INSTRUCTIONS WARNING • Replace the battery or charger immediately if the battery case or charger cord is damaged. • Always make sure the string trimmer switch is OFF before inserting or removing the battery. • Always make sure the battery is removed and the switch turned OFF before inspecting, adjusting, or maintaining any other part of the string trimmer. - Page 11 ASSEMBLY INSTRUCTIONS WARNING To avoid injury, adjust the auxiliary handle for optimum control and balance. Do not overreach when operating string trimmer. Keep proper balance at all times for better control of the tool in unexpected situations. 2. Front handle a.
- Page 12 Attachment compatibilities This 80-volt powerhead is compatible with universal gas attachments. WARNING This string trimmer is not meant to be used with brush cutter attachments. Use of a brush cutter attachment could cause serious personal injuries or property damage. Cutting line on the string trimmer.
- Page 13 ASSEMBLY INSTRUCTIONS Replacing the line If necessary, remove any old trimmer line from the cutting head. See the Removing old trimmer line section on Page 14. Turn the spool cap (N) until the slots on the spool cap and spool cover (L) are aligned. Slots line.
- Page 14 ASSEMBLY INSTRUCTIONS Removing old trimmer line Firmly press in the tabs on each side of the spool cover (L). Remove the spool cover from the spool housing (O). Tabs Remove any excess trimmer line (S) or obstructions from the spool (M). Use a clean cloth to wipe away any debris Tabs from the spool (M), spool cover (L), or...
- Page 15 ASSEMBLY INSTRUCTIONS Removing the spool from the trimmer Metal rod or Turn the spool head, while looking through the screwdriver hole next to the gear box. Line up the hole and Hole the slot inside the gear box. Gear box Insert a small screwdriver or metal rod (not included) into the hole next to the gear box.
-
Page 16: Operating Instructions
ASSEMBLY INSTRUCTIONS 9b. To remove: Press the battery release button (Q) on the string trimmer. This will cause the battery to raise out of the tool slightly. Note: WARNING: Follow these instructions in order to avoid injury and to reduce the risk of electric •... - Page 17 OPERATING INSTRUCTIONS 1. To turn on/off: a. Press the power button (D) located on the trimmer handle. b. Press the side lock button (C). This will make the trigger switch (B) operational. c. Press and hold the trigger switch (B) for continued operation.
-
Page 18: Care And Maintenance
OPERATING INSTRUCTIONS During use: • Trim only when the grass and weeds are dry. • Do not trim grass at night. Always make sure you have adequate lighting. • Hold the string trimmer by both the switch handle and the auxiliary handle for best control and balance. -
Page 19: Troubleshooting
If you still have questions or an unresolved issue after going through this troubleshooting guide, or just want to speak to a Kobalt product expert, please call our Kobalt customer service department at 1-888-3KOBALT (1-888-356-2258), 8 a.m. - 8 p.m., EST, Monday - Friday. -
Page 20: Warranty
WARRANTY 5-YEAR HASSLE-FREE WARRANTY This 80 V String Trimmer is warranted to the original purchaser from the original purchase date for This 80 V String Trimmer is warranted for the original user to be free from defects in material and workmanship. -
Page 21: Replacement Parts List
8 a.m. - 8 p.m., EST, Monday - Friday. PART DESCRIPTION PART # Fastening knob 34113877-1 Bolt 322051410 Auxiliary handle 341081410 Guard 341041410 Attachment knob 341061410 Printed in China KOBALT and the K Design are registered trademarks of LF, LLC. All Rights Reserved. ® ®...
