ITEM #0796787
40 V STRING TRIMMER
MODEL #KST 130X-06
Español p. 20
ATTACH YOUR RECEIPT HERE
Serial Number
Purchase Date
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-888-3KOBALT (1-888-356-2258), 8 a.m. - 8 p.m., EST,
Monday - Friday.
AB16499
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Kobalt KST 130X-06
Summary of Contents for Kobalt KST 130X-06
- Page 1 ITEM #0796787 40 V STRING TRIMMER MODEL #KST 130X-06 Español p. 20 ATTACH YOUR RECEIPT HERE Serial Number Purchase Date Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-888-3KOBALT (1-888-356-2258), 8 a.m. - 8 p.m., EST, Monday - Friday.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Package Contents......................... Hardware Contents....................... Symbols..........................Safety Information......................... Preparation ........................... Assembly Instructions ......................Operating Instructions ......................Care and Maintenance ......................Troubleshooting........................Warranty..........................Replacement Parts List ......................PRODUCT SPECIFICATIONS SPECIFICATIONS Type Cordless, battery-powered Speed 6,800 / 7,800 RPM Cutting Path 11 / 13 in. -
Page 3: Package Contents
PACKAGE CONTENTS PART DESCRIPTION QUANTITY PART DESCRIPTION QUANTITY Spool Trigger (preassembled to Spool Lock-off Lever Housing) Speed Switch Opening Front/Auxiliary Handle (preassembled to Spool Coupler Housing) Edge Guard Spool housing Guard (preassembled to Spool Upper Tube Housing) Lower Tube Bump Knob Spool Cover Battery (preassembled to Spool... -
Page 4: Hardware Contents
HARDWARE CONTENTS (not shown actual size) Fastening Knob Bolt Qty. 1 Qty. 1 Screw (preassembled to the Guard (H)) Qty. 2 Hex Wrench Qty. 1... -
Page 5: Symbols
SYMBOLS Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the product better and safer. SYMBOLS DESIGNATION EXPLANATION Volts Voltage Amperes Current Hertz Frequency (cycles per second) - Page 6 SYMBOLS Save these Instructions The following signal words and meanings are intended to explain the levels of risk associated with this product. SYMBOL SIGNAL MEANING Indicates an imminently hazardous situation, which, if not avoided, will DANGER result in death or serious injury. Indicates a potentially hazardous situation, which, if not avoided, could WARNING result in death or serious injury.
-
Page 7: Safety Information
• Remove or disconnect battery before servicing, cleaning or removing material from the gardening appliance. • Use only 40 V Kobalt batteries (KB 240-06, KB 440-06, KB 245-06, KB 540-06). • Store idle appliances - When not in use, the string trimmer should be stored indoors in a dry,... - Page 8 SAFETY INFORMATION • special disposal instructions. Do not open or mutilate the batteries. Released electrolyte is corrosive and may cause damage to the eyes or skin. It may be toxic if swallowed. Do not place injury. • Batteries can explode in the presence of a source of ignition, such as a pilot light. To reduce the •...
-
Page 9: Preparation
SAFETY INFORMATION Child safety Tragic accidents can occur if the operator is not aware of the presence of children. • Keep children out of the working area and under the watchful care of a responsible adult. • Do not allow children under the age of 14 to operate this trimmer. Children who are 14 years of age or older must read and understand the operating instructions and safety rules in this manual and must be trained and supervised by a parent. -
Page 10: Assembly Instructions
ASSEMBLY INSTRUCTIONS WARNING • Replace the battery or charger immediately if the battery case or charger cord is damaged. • Always make sure the string trimmer switch is OFF before inserting or removing the battery. • Always make sure the battery is removed and the switch turned OFF before inspecting, adjusting, or maintaining any other part of the string trimmer. - Page 11 ASSEMBLY INSTRUCTIONS WARNING To avoid injury, adjust the auxiliary handle for optimum control and balance. Do not overreach when operating grass trimmer/edger. Keep proper balance at all times for better control of the tool in unexpected situations. 2. Front handle a.
- Page 12 ASSEMBLY INSTRUCTIONS Cutting line on the grass trimmer/edger. When the cutting line needs replacing, insert a new spool (not included) or rewind new line onto existing spool. CAUTION: To avoid injury, always remove the battery before installing the guard, changing a cutting line, or making any adjustments.
- Page 13 ASSEMBLY INSTRUCTIONS 5. Battery IMPORTANT: The battery is not charged when it is purchased. Before using the trimmer for Battery release button and charge. 5a. To install: Align the battery with the cavity in the string trimmer housing. Insert the battery into the handle until the battery release button locks into place.
-
Page 14: Operating Instructions
OPERATING INSTRUCTIONS WARNING To avoid injury: • Do not squeeze the trigger while the grass trimmer/edger is inverted. • 1. To turn on/off: a. Slide the speed switch (D) to the desired operating speed. Slide the speed switch to position 1 for low speed or position 2 for high speed. - Page 15 OPERATING INSTRUCTIONS During use: • Trim only when the grass and weeds are dry. • Do not trim grass at night. Always make sure you have adequate lighting. • Hold the grass trimmer/edger by both the switch handle and the auxiliary handle for best control and balance. •...
-
Page 16: Care And Maintenance
CARE AND MAINTENANCE Trimmer Guard and Motor Maintenance Note: Before performing maintenance, remove battery from the tool. 1. Remove dirt and debris from guard using a paint brush (not included). 2. Clean dirt and debris off of motor cover and connection joints. -
Page 17: Troubleshooting
If you still have questions or an unresolved issue after going through this troubleshooting guide, or just want to speak to a Kobalt product expert, please call our customer service department at 1-888-3KOBALT (1-888-356-2258), 8 a.m. - 8 p.m., EST, Monday – Friday. -
Page 18: Warranty
5-YEAR LIMITED WARRANTY This Kobalt 40 V String Trimmer is warranted to the original purchaser from the original purchase date This Kobalt 40 V String Trimmer is warranted for the original user to be free from defects in material and workmanship. -
Page 19: Replacement Parts List
8 a.m. - 8 p.m., EST, Monday - Friday. PART DESCRIPTION PART # 341111437AB Fastening knob Bolt 322041444 Hex wrench 329011444 Front/auxiliary handle 341131444 311141444 Guard Spool cover 311091429 Printed in China Kobalt is a registered trademark of LF, LLC. All Rights Reserved. ®...
Need help?
Do you have a question about the KST 130X-06 and is the answer not in the manual?
Questions and answers
À quel endroit je peux me procurer des bobines ce recharges
Replacement spools for the Kobalt KST 130X-06 can be found on Amazon. Look for compatible items such as "Eyoloty KST 130X-06 KST-130X Replacement Trimmer Spool Line 0.080" 17Ft" designed for the Kobalt 40-Volt String Trimmer.
This answer is automatically generated
how do I replace the bump knob?
To replace the bump knob on a Kobalt KST 130X-06:
1. Remove the old bump knob from the trimmer head. This may require pulling or unscrewing, depending on wear.
2. Align the new bump knob with the trimmer head.
3. Press it into place. No tools are required for installation.
4. Ensure it is securely attached and spins freely.
The replacement bump knob is designed for tool-free installation and fits the Kobalt KST 130X-06 and KST 130X 40-Volt string trimmers.
This answer is automatically generated
I see nothing about how to refill the line
The document does not provide specific instructions on how to refill the line on a Kobalt KST 130X-06. However, based on general trimmer spool replacement practices, you can follow these steps:
1. Turn Off the Trimmer – Ensure the trimmer is powered off and remove the battery for safety.
2. Remove the Spool Cover – Press the tabs or unscrew the cap holding the spool in place.
3. Take Out the Empty Spool – Carefully remove the old spool.
4. Insert the New Line – If refilling manually, cut a length of 0.080-inch trimmer line (17 feet recommended). Insert one end into the spool’s anchor hole and wind it evenly in the direction indicated on the spool.
5. Reinstall the Spool – Place the refilled or replacement spool back into the trimmer head.
6. Secure the Spool Cover – Snap or screw the cover back into place.
7. Test the Trimmer – Reinsert the battery and test the trimmer to ensure proper feeding of the line.
For exact instructions, refer to the trimmer’s user manual.
This answer is automatically generated
Can the KST130X-06 be changed from a string to plastic or metal blades? Is there an adapter to change it from string to another type??
my kolbat trimmer trigger is not working there is no trouble shooting to say way it wont pull
Do you need to lube the trimmer shaft?
Need schematic or parts for motor at end of shaft
