Whitehaus WH2070838 Installation Manual

Installation Guide
WH2070838
s are properly flushed and cleared to
avoid blockage.
WARNING: Assembly by a professional plumber is required.
2
Clean all dirt and debris
from supply valves before
proceeding with installation.
If you are replacing an
existing faucet, remove the
faucet from the sink and
clean the surface thoroughly.
4
Fix weight balance (11) on the
suitable position of sprayer flexible
required.
hose (10) to keep the pulling
smoothly. The distance from the
end of the outlet pipe connector to
the weight balance should be 24".
1. Always turn off water and relieve pressure before working on your faucet.
1. Clean the faucet with mild soap and water, then wipe the faucet dry with soft cloths.
2. Do not use cleaners which contain acids, harsh chemicals, or abrasives.
3. Repeat steps 1-2 whenever necessary.
3
5 6
Connect the hose (10) with Connect the flexible hoses to the
outlet pipe (4). water supply valves (left to hot
water and right to cold). Make
sure flexible hoses are securely
fastened before turning on valve.
10"
4.44"
8.58"
17.25"
