Owner's Manual &
Safety Instructions
22i
Model
HCB91B
20  V Brushless 1/2" Drill  /   D river
WARNING: To prevent serious injury, User must read and
understand Owner's Manual. SAVE THIS MANUAL.
When unpacking, make sure that the product is intact and undamaged.
If any parts are missing or broken, please call 1-888-866-5797
as soon as possible. Reference 70067.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HCB91B and is the answer not in the manual?

Questions and answers

jim tolonen
June 10, 2025

what settings are best for driving deck screws (10 x 3") into pressure treated boards

0

Subscribe to Our Youtube Channel

Related Manuals for Hercules HCB91B

Summary of Contents for Hercules HCB91B

  • Page 1 Owner’s Manual & Safety Instructions Model HCB91B 20  V Brushless 1/2" Drill  /   D river WARNING: To prevent serious injury, User must read and understand Owner’s Manual. SAVE THIS MANUAL. When unpacking, make sure that the product is intact and undamaged.
