Owner's Manual &
Safety Instructions
22i
Model
HCB96B
Battery and Charger Sold Separately
20V Brushless 1/2" Heavy Duty Variable
Speed Right Angle Drill
WARNING: To prevent serious injury, User must read and
understand Owner's Manual. SAVE THIS MANUAL.
When unpacking, make sure that the product is intact and undamaged.
If any parts are missing or broken, please call 1-888-866-5797
as soon as possible. Reference 59178.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HCB96B and is the answer not in the manual?

Questions and answers

Related Manuals for Hercules HCB96B

Summary of Contents for Hercules HCB96B

  • Page 1 Owner’s Manual & Safety Instructions Model HCB96B Battery and Charger Sold Separately 20V Brushless 1/2″ Heavy Duty Variable Speed Right Angle Drill WARNING: To prevent serious injury, User must read and understand Owner’s Manual. SAVE THIS MANUAL. When unpacking, make sure that the product is intact and undamaged.

  • Page 2: Important Safety Information

    IMPORTANT SAFETY INFORMATION General Power Tool Safety Warnings Personal Safety Read all safety warnings, instructions, illustrations a. Stay alert, watch what you are doing and and specifications provided with this power tool. use common sense when operating a Failure to follow all instructions listed below may power tool.
  • Page 3 k. When using a handheld power tool, g. Use the power tool, accessories and tool bits maintain a firm grip on the tool with both etc. in accordance with these instructions, hands to resist starting torque. taking into account the working conditions and the work to be performed.
  • Page 4 The battery Charger gets hot during c. Charge Battery Pack only according use. The Charger’s heat can build up to its Charger’s instructions. to unsafe levels and create a fire d. Inspect Battery Pack before every use; hazard if it does not receive adequate do not use or charge if damaged.

  • Page 5: Vibration Safety

    Vibration Safety GROUNDING This tool vibrates during use. Repeated or long-term exposure to vibration may cause temporary or permanent physical injury, TO PREVENT ELECTRIC SHOCK AND particularly to the hands, arms and shoulders. DEATH FROM INCORRECT GROUNDING: To reduce the risk of vibration-related injury: Check with a qualified electrician if you are in doubt as to whether the outlet is a.
  • Page 6 Warning Symbols and Definitions Symbology This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Volts Obey all safety messages that follow this symbol to avoid possible injury or death. Direct Current Indicates a hazardous situation which, if not Amperes avoided, will result in death or serious injury.

  • Page 7: Specifications

    Functions Specifications Hercules 20V Li-Ion 57373 Battery Type (sold separately) Hercules 20V Li-Ion 56559 Charger Type (sold separately) No Load Speed : 0-1000/min Chuck Capacity 1/2″ (13mm) Setup - Before Use: Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the...

  • Page 8: Setting And Testing

    2. Open chuck jaws wide enough to insert the bit. Be OPERATING INSTRUCTIONS sure the chuck jaws are clean and free of debris. Dirt may prevent the bit from lining up properly. Read the ENTIRE IMPORTANT 3. Use a drill bit designed for the workpiece type. SAFETY INFORMATION section at the Insert bit into the chuck.
  • Page 9 5. Touch Drill bit lightly against the workpiece and General Instructions for Use squeeze the Trigger. The deeper the Trigger is pressed the faster the rotation speed. 6. While the Drill is running, apply light pressure to the Drill. Allow the tool to work at its own pace. TO PREVENT SERIOUS INJURY: Wear ANSI approved safety glasses with side 7.

  • Page 10: Maintenance And Servicing Instructions

    Cleaning, Maintenance, Maintenance and Servicing and Lubrication Instructions 1. BEFORE EACH USE, inspect the general Procedures not specifically explained condition of the tool. Check for: in this manual must be performed • leaking, swollen, or cracked battery pack, only by a qualified technician. •...

  • Page 11: Troubleshooting

    Troubleshooting Problem Possible Causes Likely Solutions Tool will not start. 1. Battery Pack not properly 1. Remove Battery Pack, make sure there are no connected. obstructions, reinsert the Battery Pack according to its shape (it should only fit one way), and press firmly until the Battery Pack locks in place.

  • Page 12: Year Limited Warranty

    5-YEAR LIMITED WARRANTY This Hercules tool is warranted to the original purchaser to be free from defects in materials and workmanship for a period of five (5) years beginning on the date of purchase. This warranty does not cover battery packs and battery chargers, which are covered under separate warranties. To obtain warranty service, visit your local Harbor Freight retail store.
