HI LO PULLEY STATION,150 LBS
NLHILO150
OVERALL DIMENSIONS: 42"L X 42.5"W X 78.85"H
12 JULY 2023
HI LO PULLEY STATION,150 LBS
ASSEMBLY INSTRUCTIONS
Keep This For Warranty
NLHILO150
LOT:
1-866-420-4560
Northern Lights Fitness
Products Inc.
MADE IN CANADA
Specification
Weight=243.3 lbs
Packed in 4 Boxes
:74.375"x11.125"x7.5"
Box 1
:3.6 ft³
:93.3 Lbs
:12.5"x5"x6.25"
Box 2,3&4
:0.266 ft³
:(Each)50 Lbs
Advertisement
Related Manuals for Northern Lights Fitness NLHILO150
Summary of Contents for Northern Lights Fitness NLHILO150
- Page 1 HI LO PULLEY STATION,150 LBS ASSEMBLY INSTRUCTIONS Keep This For Warranty NLHILO150 LOT: 1-866-420-4560 Northern Lights Fitness Products Inc. MADE IN CANADA Specification Weight=243.3 lbs HI LO PULLEY STATION,150 LBS Packed in 4 Boxes :74.375"x11.125"x7.5" NLHILO150 Box 1 :3.6 ft³...
- Page 2 Item Part QTY. Box/Bag# Item Part QTY. Box/Bag# 3/8"x1 1/2" Bolt Bag 1 Front Leg Box 1 3/8"x1 3/4" Bolt Bag 1 Base Assembly Box 1 3/8"x2" Bolt Bag 1 Back Leg Box 1 3/8"x2 1/2" Bolt Bag 1 Front Upright Box 1 3/8"x2 3/4"...
- Page 3 * Optional Page:-3 of 7...
- Page 4 Typical Typical 1.Bolt Bottom Shroud Holder (15) on Base Assembly (2) and then bolt Front Leg (1) & Back Leg (3) to Base Assembly(2)using bolting shown. 2. Insert Front Upright (4) on the Base Assembly (2), hold the Double Pulley Bracket (11) in place while bolting Front Upright (4) to Base Assembly (2) using bolting shown and bolt Back Upright (5) to Base Assembly (2).
- Page 5 P 12 PLACES 10 4 PLACES 10 PLACES 4. Install Dual Swuivel Pulley Bracket (9) on Adjustable Pulley Assembly (8), using bolting shown. 5. The Pulleys (R) , Single Pulley Cable Retainer (10),Double Pulley Cable Retainer (17) and Nylon Spacers (P) to be installed at the time of Cable (AC) routing Page:-5 of 7...
- Page 6 Guide Rod Retainer Assembly Details Tighten by hand 3/8" x 2" Bolt (C)until Shroud Mesh (19) is installed, then tighten to remove slack in mesh. START FINISH 6. Place 4x Rubber Bumpers (L) over the holes on Bottom Shroud Holder (15) and slide Guide Rods(16) into them.
-
Page 7: Warranty
WARRANTY Garantie à Vie Limitée du Fabricant Manufacturer’s Limited Lifetime Warranty Northern Lights Fitness Products Inc. offre à ses Northern Lights Fitness Products Inc. offers its clients une garantie à vie contre toutes soudures customers a lifetime warranty against broken casées et contre tout défaut de matériau et de...
