Introduction
This product manual contains the information
needed for the setup, installation, initial start up,
sanitation and maintenance of this ice machine.
Keep it for future reference.
This machine incorporates advanced technology,
including a scroll compressor.
Be certain that the information applies to the
model in question. If no model is listed, the
information applies to all models.
Introduction . . . . . . . . . . . . . . . . . . PAGE 1
Specifications . . . . . . . . . . . . . . . . . PAGE 2
Condenser and Ice Machine Layouts . . . . . PAGE 3
Pre-Installation . . . . . . . . . . . . . . . . . PAGE 4
Bin Control: Installation . . . . . . . . . . . . PAGE 6
Bin Control . . . . . . . . . . . . . . . . . . . PAGE 7
Stacking . . . . . . . . . . . . . . . . . . . . PAGE 8
Stacking . . . . . . . . . . . . . . . . . . . . PAGE 9
For The Installer: Remote Condenser . . . . . PAGE 10
Remote Condenser Location . . . . . . . . . PAGE 11
Coupling Instructions . . . . . . . . . . . . . PAGE 12
Electrical . . . . . . . . . . . . . . . . . . . . PAGE 13
Plumbing . . . . . . . . . . . . . . . . . . . . PAGE 14
After Utility Connections . . . . . . . . . . . . PAGE 15
Component Location and Function . . . . . . PAGE 16
System Controller . . . . . . . . . . . . . . . PAGE 17
Initial Start Up . . . . . . . . . . . . . . . . . PAGE 18
Startup: Three Phase Compressor . . . . . . PAGE 19
Adjustments . . . . . . . . . . . . . . . . . . PAGE 20
How The Electronic Cuber Works . . . . . . . PAGE 22
Printed on recycled paper.
This manual is organized in the same way as the
expected use of the machine, it begins with
specifications, goes thru unpacking and setup,
shows where everything is; continues with initial
start up, then describes how it works. After that is
the sanitation section, followed by service
diagnosis and repair.
All Scotsman CM
Scotsman's AutoIQ™ control system and
ReliaClean™ water system cleaning process.
TABLE OF CONTENTS
How The Electronic Cuber Works . . . . . .
Sanitation and Cleaning . . . . . . . . . . .
Additional Maintenance . . . . . . . . . . .
Service Diagnosis . . . . . . . . . . . . . .
Service Diagnosis: Components . . . . . . .
Service Diagnosis . . . . . . . . . . . . . .
Suction Pressure . . . . . . . . . . . . . . .
Removal and Replacement . . . . . . . . .
Removal and Replacement . . . . . . . . .
Removal and Replacement: . . . . . . . . .
Removal and Replacement . . . . . . . . .
Refrigerant . . . . . . . . . . . . . . . . . .
Before Calling for Service . . . . . . . . . .
July 1998
Page 1
3
models, like this one, feature
. . . . . . . . . . . . . . .
Service parts list & wiring diagrams located
in the middle of this manual.
CME2006R
PAGE 23
PAGE 24
PAGE 25
PAGE 26
PAGE 27
PAGE 28
PAGE 29
PAGE 30
. . . .
PAGE 31
PAGE 32
PAGE 33
PAGE 34
PAGE 35
PAGE 36
PAGE 37
PAGE 38
PAGE 39
PAGE 40
PAGE 41
PAGE 42
PAGE 43
PAGE 44
