WatchNet WAB P FCKS User Manual

Biometric standalone controller
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
WatchNET Access Integrated Security Management Software
WAB P FCKS User Manual
Page 1 of 36
351 Ferrier Street • Markham, ON • L3R 5Z2
PHONE: 416-410-6865 TOLL FREE: 1-866-331-3341 • FAX: 905-752-0186
www.watchnetaccess.com / info@watchnetinc.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WAB P FCKS and is the answer not in the manual?

Questions and answers

Related Manuals for WatchNet WAB P FCKS

Summary of Contents for WatchNet WAB P FCKS

  • Page 1 WatchNET Access Integrated Security Management Software WAB P FCKS User Manual Page 1 of 36 351 Ferrier Street • Markham, ON • L3R 5Z2 PHONE: 416-410-6865 TOLL FREE: 1-866-331-3341 • FAX: 905-752-0186 www.watchnetaccess.com / info@watchnetinc.com...
  • Page 2 User Manual WAB P FCKS Biometric Standalone Controller Page 2 of 36 351 Ferrier Street • Markham, ON • L3R 5Z2 PHONE: 416-410-6865 TOLL FREE: 1-866-331-3341 • FAX: 905-752-0186 www.watchnetaccess.com / info@watchnetinc.com...

  • Page 3: Table Of Contents

    Index ....................................Revision History ..............................4 Chapter 1 Introduction ............................4 1.1 Summary ..............................4 1.2 Features ..............................5 1.3 Application Mode ........................... 6 Chapter2 Wiring Diagram ............................. 6 2.1 WAB BEM FCK-S Appearance ........................6 2.2 Wiring Diagram ............................7 2.3 Lock Wiring Diagram ..........................

  • Page 4: Revision History

    WAB BEM FCK-S is a new outstanding biometric standalone controller with TFT color display developed by WATCHNET. When WAB BEM FCK-S is used as a T&A controller the employees need to press their finger on the reader sensor to complete attendance. The TFT screen will display time and staff ID information.

  • Page 5: Features

    Model Definition: WAB BEM FCK-S/E------ Built in EM Card Reader WAB BEM FCK-S/H----- Built in HID Card Reader WAB BEM FCK-S/U------ Built in Mifare\CPU Card Reader Supported Card Type: E：EM Card； Exp EM4100， TK4100 Series. H：HID Card； Exp: 1326、1386 Series. U：FM1208 CPU Card，Philips S50，...

  • Page 6: Application Mode

    1.3 Application Mode 3 Application Modes：  Standalone  Outdoor external reader, indoor WAB BEM FCK-S  Indoor external reader, outdoor WAB BEM FCK-S Chapter2 Wiring Diagram 2.1 WAB BEM FCK-S Appearance LED:  Blue LED：Power indicator  Green LED：Sensor indicator（Relay on indicator） Keypad: Description Description...

  • Page 7: Wiring Diagram

    2.2 Wiring Diagram J1：Power、Door contact、Switch J3：Reader signal output/input inputs J4：TCP/IP Interface J2：Relay Output Figure 2-2 Wiring Sketch Connect Connecti Icon Definition Icon Definition D1_Out Power supply +12V D0_ Out Door contact, +12V Reader signal Rex Button, input/output Auxiliary D1_In output D0_In RJ45 TCP/IP interface...

  • Page 8: Lock Wiring Diagram

    Wiring Description： J1: Power supply, Magnetic door contact, Rex Button, Auxiliary input  12V：DC 12V Positive  GND：Ground  SEN：Door contact  BUT：Rex Button,  GND：Ground  IN1：Auxiliary input J2: Relay output  Based on customized lock model and power requirement. J3 Reader signal input/output ...
  • Page 9 Figure 2-6 lock Fail secure Page 9 of 36 351 Ferrier Street • Markham, ON • L3R 5Z2 PHONE: 416-410-6865 TOLL FREE: 1-866-331-3341 • FAX: 905-752-0186 www.watchnetaccess.com / info@watchnetinc.com...

  • Page 10: Chapter3 Instructions

    Chapter3 Instructions User Management、PIN management、Work mode and Time set are configured in the manage menu. Menu structure is shown below. Page 10 of 36 351 Ferrier Street • Markham, ON • L3R 5Z2 PHONE: 416-410-6865 TOLL FREE: 1-866-331-3341 • FAX: 905-752-0186 www.watchnetaccess.com / info@watchnetinc.com...

  • Page 11: Personnel Management

    3.1 Personnel Management 3.1.1 Add Personnel 1． Press the Menu button to enter manage menu when WAB BEM FCK-S is idle. In the following steps the Esc works as cancel while Enter works as confirm. WatchNET 1. User 2. Network 3. Option 4.
  • Page 12 3.1.1.1 FP 1. Press 1 to enter Add FP interface. (As shown below) WatchNET Level 1:1 （0~9）:0 2. Select a level according to customer’s requirement (High level for high matching accuracy, but will slow down responding time), press Enter to enter the next interface.
  • Page 13 WatchNET Add card Place your card 2．Place the card in the sensor area and the system will enter the next interface after a beeping sound. WatchNET Level 1:1 （0~9）:0 3. Select a level according to customer’s requirement (High level for high matching accuracy, but will slow down responding time), press Enter to enter the next interface.
  • Page 14 WatchNET 1． FP 2． FP/Card 3． FP+CARD 4． User ID+FP 5． User ID+ card 1. Press 3 to enter add FP + Card interface. (As shown below) WatchNET Add Card Place your card 2. Place the card in the sensor area. The system will enter the next interface after a beeping sound.
  • Page 15 WatchNET 1． FP 2． FP/Card 3． FP+CARD 4． User ID+FP 5． User ID + card 1. Press 4 to enter add User ID + FP interface. (As shown below) WatchNET Level 1:1 （0~9）:0 2. Select a level according to customer’s requirement (High level for high matching accuracy, but will slow down responding time), press Enter to enter the next interface.

  • Page 16: Delete Personnel

    WatchNET Add Card Place your card 2. Place the card in the sensor area. The system will enter the next interface after a beeping sound. 3.1. 2 Delete Personnel Press the Menu button to enter the manage menu when WAB BEM FCK-S is idle. In the following steps, Esc works as cancel while Enter works as confirm.

  • Page 17: Modify

    3.1.3 Modify 1. Press the Menu button to enter manage menu when WAB BEM FCK-S is idle. In the following steps, Esc works as cancel while Enter works as confirm. WatchNET 1. User 2. Network 3. Option 4. Device 5. Terminal Info 2.

  • Page 18: Delete All

    WatchNET 1． Add 2． Delete 3． Modify 4． Add Admin 5． Delete All 3. Press 4 to enter Add Admin interface. WatchNET Admin ID (NEW) -------------- 4. Input new Admin ID and press Enter for the next interface. Refer to section 3.1.1.

  • Page 19: Network Configuration

    WatchNET Delete all？ [Y=1/N=2]： 4. Press the corresponding number to select Yes or No and press Enter to confirm deletion. 3.2 Network Configuration 3.2. 1 Terminal ID 1. Press the Menu button to enter the manage menu WAB BEM FCK-S is idle. In the following steps, Esc works as cancel while Enter works as confirm.

  • Page 20: Net Configure

    4. Input the Terminal ID by using the keypad and press Enter to confirm. 3.2.2 Net Configure 1. Press Menu button to enter the manage menu WAB BEM FCK-S is idle. In the following steps, Esc works as cancel while Enter works as confirm. WatchNET 1. User 2. Network 3. Option 4.

  • Page 21: Subnet Mask

    WatchNET 1. User 2. Network 3. Option 4. Device 5. Terminal Info 2. Press 2 to enter the Network interface. (As shown below) WatchNET 1． Terminal ID 2． Net Configure 3． IP Address 4． Subnet Mask 5． Gateway 6. Host IP 7.

  • Page 22: Gateway

    4. Input your Subnet Mask and press Enter to confirm. 3.2.5 Gateway 1. Press the Menu button to enter the manage menu WAB BEM FCK-S is idle. In the following steps, Esc works as cancel while Enter works as confirm. WatchNET FPC2000 1. User 2. Network 3. Option 4.

  • Page 23: Host Ip

    3. Press 5 to enter the Gateway interface. ( stands for the delete button, stands for the symbolic button) WatchNET Gateway： 192.168.X.X 4. Input the Gateway and press Enter to confirm. 3.2.6 Host IP 1. Press the Menu button to enter the manage menu WAB BEM FCK-S is idle. In the following steps, Esc works as cancel while Enter works as confirm.

  • Page 24: Host Port

    WatchNET Host IP： 192.168.X.X 4. Input the Host IP and press Enter to confirm. 3.2.7 Host Port 1. Press the Menu button to enter the manage menu WAB BEM FCK-S is idle. In the following steps, Esc works as cancel while Enter works as confirm.

  • Page 25: Language

    3.3 Option 3.3.1 Language 1. Press the Menu button to enter the manage menu WAB BEM FCK-S is idle. In the following steps, Esc works as cancel while Enter works as confirm. WatchNET 1. User 2. Network 3. Option 4. Device 5.

  • Page 26: Screensaver

    WatchNET 1． Language 2． Clock Setting 3． Screen Saver 4． Door Relay 5． Multi FP Verify 6. Tamper Alarm 2. Press 2 to enter the Clock Setting interface.(As shown below) WatchNET Clock Setting 20130815095430 3. Input the accurate time and press Enter to confirm.

  • Page 27: Door Relay

    3.3.4 Door Relay 1. To enter the following interfaces refer to section 3.3.1. WatchNET 1． Language 2． Clock Setting 3． Screen Saver 4． Door Relay 5． Multi FP Verify 6. Tamper Alarm 2. Press 4 to enter the Screensaver interface. (As shown below) WatchNET 1.

  • Page 28: Tamper Alarm

    2. Press 5 to enter the Multi FP Verify interface. (As shown below) WatchNET （N=0/Y=1）:1 3. 0 stands for not enabling Multi FP Verification while 1 stands for affirmative. Press Enter to confirm. 3.3.6 Tamper Alarm 1. To enter the following interfaces refer to section 3.3.1.
  • Page 29 WatchNET 1. User 2. Network 3. Option 4. Device 5. Terminal Info 2. Press 4 to enter the Device interface. (As shown below) WatchNET 1． FP-Module 2． WG Setting 3． Card Number Mode 4． Display Mode 5． Terminal Init 3. Press 1 to enter the FP-Module interface. (As shown below) WatchNET 1．...

  • Page 30: Wg Setting

    I-Capture：Press 1 to enable I-Capture, 0 to disable I-Capture. Auto Detect：Press 1 to enable I-Capture, 0 to disable I-Capture. 3.4.2 WG Setting 1. To enter the following interfaces refer to section 3.4.1. WatchNET 1． FP-Module 2． WG Setting 3． Card Number Mode 4．...

  • Page 31: Display Mode

    WatchNET 1． FP-Module 2． WG Setting 3． Card Number Mode 4． Display Mode 5． Terminal Init 2. Press 3 to enter the Card Number Mode interface. (As shown below) WatchNET Card Number Mode：2 0=Dec 1=Hex 2=Wiegand 3. Card number is displayed on the screen, Press Enter to confirm your choice after finishing selecting Card Number Mode.

  • Page 32: Terminal Initialize

    3. There are 7 options to choose from, input the corresponding number and press Enter to confirm. 3.4.5 Terminal Initialize 1. To enter the following interfaces refer to section 3.4.1. WatchNET 1． FP-Module 2． WG Setting 3． Card Number Mode 4．...

  • Page 33: Door Open Mode

    WatchNET 1. User 2. Network 3. Option 4. Device 5. Terminal Info 2. Press 5 to enter the Terminal Info interface. (As shown below) WatchNET Device ID=0001 Version：1.00 Language=English MAC=00-10-F0-00-43-1D IP =192.168.4.207 The screen will show the basic information of the device, such as Device ID, Version, Language, Mac Address and IP Address.

  • Page 34: Chapter 4 Installation

    Chapter 4 Installation 4.1 In the Wall Use the installation box: Drill a hole on the wall (size: 86 x 86mm) where you want to install your reader. Then install the installation box in the hole. Installation box (Standard 86 box, single) 2.

  • Page 35: Without Installation Box

    4.2 Without Installation Box 6. Cut a square hole in the wall. Width 70mm Height 60mm. 7. Wiring: Pull the wire between reader and controller. 8. Connection: Please refer to chapter 2 of the connections. Fix base plate: First drill 3 ф6, deep 40mm holes and put rubber plugs in. then place the reader in a vertical position and use a M3*4 screws to fix it.

  • Page 36: Chapter 5 Faq

    Chapter 5 FAQ Descriptions Solution No response on flashing a card（indicator  Power problem（check power supply）  off，buzzer no beeping） Invalid card type（use supported card）  Door stays opened Set short relay time in manage menu  Register FP/Card in PC.(Connect to PC FP or card information missing first) ...
