global_main.book.book Page 1 Tuesday, July 18, 2023 11:53 AM
OWNER'S MANUAL
WASHING MACHINE
Before beginning installation, read these instructions
carefully. This will simplify installation and ensure that the
product is installed correctly and safely. Leave these
instructions near the product after installation for future
reference.
ENGLISH
T1685NEHTE / T1785NEHTEE / T1885NEHTE / T1785NEHT / T1885NEHT2
MFL71799911
Rev.01_071923
Copyright © 2021-2023 LG Electronics Inc. All Rights Reserved.
www.lg.com
Advertisement
Table of Contents
Related Manuals for LG T1785NEHT
Summary of Contents for LG T1785NEHT
- Page 1 This will simplify installation and ensure that the product is installed correctly and safely. Leave these instructions near the product after installation for future reference. ENGLISH T1685NEHTE / T1785NEHTEE / T1885NEHTE / T1785NEHT / T1885NEHT2 www.lg.com MFL71799911 Rev.01_071923 Copyright © 2021-2023 LG Electronics Inc. All Rights Reserved.
-
Page 2: Table Of Contents
Preparing the Wash Load ................14 Adding Detergents, Softeners and Bleaches..........16 Control Panel ....................18 Programme Table ....................19 Extra Options and Functions ................22 SMART FUNCTIONS LG ThinQ Application ..................25 Smart Diagnosis ....................25 MAINTENANCE Cleaning after Every Wash................26 Cleaning the Appliance Periodically ..............26 TROUBLESHOOTING... -
Page 3: Safety Instructions
global_main.book.book Page 3 Tuesday, July 18, 2023 11:53 AM SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below. - Page 4 • The inlet water pressure must be between 50 and 800 kPa. Maximum Capacity The maximum capacity in some cycles for dry clothes to be washed is: T1785NEHTEE / T1885NEHTE / T1685NEHTE T1785NEHT T1885NEHT2 16 kg 17 kg 18 kg Installation •...
- Page 5 global_main.book.book Page 5 Tuesday, July 18, 2023 11:53 AM SAFETY INSTRUCTIONS • Do not plug the appliance into multiple outlet sockets or an extension power cable. • Do not modify the power plug provided with the appliance. If it does not fit the power outlet, have a proper outlet installed by a qualified electrician.
- Page 6 • In case of a water leak from the appliance, disconnect the power plug and contact the LG Electronics customer information centre. • Turn off water taps to relieve pressure on hoses and valves and to minimize leakage if a break or rupture should occur.
- Page 7 • Only qualified service personnel from LG Electronics service centre should disassemble, repair, or modify the appliance. Contact an LG Electronics customer information centre if you move and install the appliance in a different location.
-
Page 8: Installation Parts And Specifications
*1 The included accessories vary depending on the model you purchased. *2 This accessory is not included in the product, but you can purchase it from the LG service centre. Cold and Hot Water Inlet Hoses Drain Hose Anti-Rat Cover... - Page 9 Page 9 Tuesday, July 18, 2023 11:53 AM INSTALLATION Specifications T1685NEHTE / T1785NEHTEE / T1785NEHT / Model T1885NEHTE / T1885NEHT2 Power Supply 230 V~, 50 Hz Product Weight Approx. 42.5 kg Dimension(mm) D’ H’ 1020 1390...
-
Page 10: Installation Place Requirements
Contact your local 2 cm 2 cm 10 cm authorised LG repairer. • The power plug must be plugged into an WARNING appropriate outlet socket that is installed and • This appliance must only be used for domestic... -
Page 11: Connecting The Water Inlet Hoses
global_main.book.book Page 11 Tuesday, July 18, 2023 11:53 AM INSTALLATION Connecting the Water Inlet Connecting the Hose to the Water Tap Hoses Connecting Screw-Type Hose to Tap with Thread Before connecting the water inlet hose to the water Screw the hose connector onto the water supply tap, check the hose fitting type and follow the tap. -
Page 12: Installing The Drain Hose
global_main.book.book Page 12 Tuesday, July 18, 2023 11:53 AM INSTALLATION Installing the Drain Hose Levelling the Appliance Before connecting the drain hose, check your drain Checking the Level hose model and follow the instructions for that model. Levelling the appliance prevents unnecessary noise and vibration. - Page 13 global_main.book.book Page 13 Tuesday, July 18, 2023 11:53 AM INSTALLATION Assembling the Anti-Rat Cover You can insert the anti-rat cover according to the type to protect the appliance from the rat. Lay the appliance backwards. CAUTION • Be careful your feet or hands when you lay or raise the appliance.
-
Page 14: Operation Operation Overview
global_main.book.book Page 14 Tuesday, July 18, 2023 11:53 AM OPERATION OPERATION Operation Overview • If the START/PAUSE button is not pressed within a certain time, the appliance will shut off and all settings will be lost. Using the Appliance Before the first wash, select the Normal End of cycle. - Page 15 global_main.book.book Page 15 Tuesday, July 18, 2023 11:53 AM OPERATION Checking the Fabric Care Label cause irreparable damage to both your appliance and clothes. This will tell you about the fabric content of your clothes and how it should be washed. Symbols on the Care Labels Symbol Wash / Fabric type...
-
Page 16: Adding Detergents, Softeners And Bleaches
global_main.book.book Page 16 Tuesday, July 18, 2023 11:53 AM OPERATION Adding Detergents, CAUTION Softeners and Bleaches • Using liquid detergent without diluting, or leaving laundry for a long time after pouring Detergent Dosage diluted liquid detergent into the drum might cause the clothes to be damaged, bleached, •... - Page 17 global_main.book.book Page 17 Tuesday, July 18, 2023 11:53 AM OPERATION Adding Fabric Softeners bleach dispenser . Avoid splashing or overfilling. Add a fabric softener to the maximum fill line. • If the softener is concentrated, then it should be diluted. •...
-
Page 18: Control Panel
global_main.book.book Page 18 Tuesday, July 18, 2023 11:53 AM OPERATION Control Panel Control Panel Features POWER Button • Press the POWER button to turn on or off the appliance. • The appliance automatically turns off once a certain time has passed after the wash has completed. START/PAUSE Button •... -
Page 19: Programme Table
global_main.book.book Page 19 Tuesday, July 18, 2023 11:53 AM OPERATION - If the display shows , then the time will be displayed after the load sensing has detected the -:-- laundry size. - The time shown is only an estimate. Several external factors (laundry size, room temperature, incoming water temperature, etc.) can affect the actual time. - Page 20 global_main.book.book Page 20 Tuesday, July 18, 2023 11:53 AM OPERATION Duvet Description Use this programme to wash a blanket or bedclothes that have the hand wash sign on the care label. • Cashmere bedclothes, acrylic blanket, mixed spinning blanket, woollen blanket, infilling (polyester 101), and bed sheets might be damaged if they are allowed to float.
- Page 21 global_main.book.book Page 21 Tuesday, July 18, 2023 11:53 AM OPERATION Quick Wash Description Use this programme to wash lightly soiled clothes for a short time. • This programme's recommended laundry amount is under 3 kg. Extra Clean Description Use this programme to increase rinsing performance. •...
-
Page 22: Extra Options And Functions
global_main.book.book Page 22 Tuesday, July 18, 2023 11:53 AM OPERATION Extra Options and Water This appliance detects the amount of laundry Functions automatically, then sets the water level. However, manually increasing the water level may be You can use the extra options and functions on required and recommended to avoid linting and some programmes to customize the cycle. - Page 23 global_main.book.book Page 23 Tuesday, July 18, 2023 11:53 AM OPERATION • Turning off the power will not reset this function. Select a washing programme. You must deactivate this function before you can access any other options and functions. Press the Delay button to set the required delay ending time.
- Page 24 global_main.book.book Page 24 Tuesday, July 18, 2023 11:53 AM OPERATION Manual Washing When you need a rinse and spin, spin only, rinse only or wash only cycle, these can be set manually. Rinse and Spin Spin only Rinse only Wash only Press the POWER button.
-
Page 25: Smart Functions
Using Audible Diagnosis to Diagnose Issues Follow the instructions below to use the audible diagnosis method. • Launch the LG ThinQ application and select the Smart Diagnosis feature in the menu. Follow the instructions for audible diagnosis provided in the LG ThinQ application. -
Page 26: Maintenance
global_main.book.book Page 26 Tuesday, July 18, 2023 11:53 AM MAINTENANCE MAINTENANCE WARNING • Unplug the appliance before cleaning to avoid the risk of electric shock. Failure to follow this warning may result in serious injury, fire, electric shock, or death. •... - Page 27 global_main.book.book Page 27 Tuesday, July 18, 2023 11:53 AM MAINTENANCE Cleaning the Water Inlet Filter • For models without a lint filter, the lint is discharged when the water drains during washing. Water inlet filter collects lime or any small objects that may be in water supplied to the appliance.
- Page 28 global_main.book.book Page 28 Tuesday, July 18, 2023 11:53 AM MAINTENANCE Wash the filter. CAUTION • Do not drop the filter on the floor. • Be careful not to get your fingernails caught in the filter when you handle the filter. •...
- Page 29 global_main.book.book Page 29 Tuesday, July 18, 2023 11:53 AM MAINTENANCE Turn the cap on the rear of the appliance counter-clockwise and pull it out. Remove any foreign objects and fluff inside pump casing and from the filter. Insert the filter along the guide ribs inside the pump casing and turn the cap clockwise to refit the cap.
-
Page 30: Troubleshooting
You can remedy most of the problems by yourself, consequently save time and money, since you do not need to call LG Electronics service centre. The following table should assist you by troubleshooting. - Page 31 global_main.book.book Page 31 Tuesday, July 18, 2023 11:53 AM TROUBLESHOOTING Symptoms Possible Cause & Solution Foreign objects, such as coins, pins, clips, etc.,are caught between the pulsator and the inner drum. FOREIGN OBJECTS ERROR • Turn off the appliance and then press the POWER button. Press the Spin button without selecting a cycle to drain and spin the laundry.
- Page 32 global_main.book.book Page 32 Tuesday, July 18, 2023 11:53 AM TROUBLESHOOTING Symptoms Possible Cause & Solution A motor error has occurred. DRAIN MOTOR ERROR • Unplug the appliance and call for service. is not an error. This prevents children from changing cycles or operating the appliance.
- Page 33 global_main.book.book Page 33 Tuesday, July 18, 2023 11:53 AM TROUBLESHOOTING Symptoms Possible Cause & Solution Appliance will not Water supply is turned off. operate. • Turn on the water supply tap completely. Controls are not set properly. • Make sure the cycle is correctly set. Close the door and press the START/ PAUSE button.
- Page 34 global_main.book.book Page 34 Tuesday, July 18, 2023 11:53 AM TROUBLESHOOTING Symptoms Possible Cause & Solution Water leaking Drain hose has come out of drain or is not inserted far enough. • Tie drain hose to supply hose or standpipe to prevent it from coming out during drain.
- Page 35 global_main.book.book Page 35 Tuesday, July 18, 2023 11:53 AM TROUBLESHOOTING Symptoms Possible Cause & Solution Poor stain removal Previously set stains. • Items that have previously been washed may have stains that have been set. These stains may be difficult to remove and may require hand washing or pretreating to aid in stain removal.
- Page 36 global_main.book.book Page 36 Tuesday, July 18, 2023 11:53 AM...
