- Page 1 Automatic Pet Feeder User Manual Model：A303D/A305D Before using this product, please read this manual carefully and keep it for future reference.
-
Page 2: Table Of Contents
Contents SAFETY PRECAUTIONS - 1 WARRANTY-3 IN THE BOX-3 PRODUCT DIAGRAM-4 BUTTONS AND DISPLAY OVERVIEW - 5 HOW TO USE-6 ASSEMBLY AND PREPARE FOR SETTING - 6 PROGRAM SETTING - 9 CLEAN AND CARE - 14 TROUBLESHOOTING - 16... -
Page 3: Safety Precautions
SAFETY PRECAUTIONS ! WARNING Dispose of all packaging materials properly. Some items may be packed in polybags；these bags could cause suffocation；keep away from children and pets. To reduce the risk of injury, please keep close supervision when an appliance is used near children. Do NOT immerse the base part in water at anytime as it may damage electronic components like the control panel. - Page 4 CAUTION Do NOT allow pets to chew on or swallow any parts. If you are concerned about the power cord, purchase a cord conduit (a hard plastic protector) at any hardware store to protect the power cord. Do NOT install or store the pet feeder where it will be exposed to weather or temperatures below 4°C / 39°F.
-
Page 5: In The Box-3
2 x Stainless Steel 2 x Slow Feeder Bowls Bowls 1×Automatic Pet Feeder 2×Bowl Holders Automatic Pet Feeder User Manual Model：A303D/A305D Before using this product, please read this manual carefully and keep it for future reference. 1×Power Adapter 1×Desiccant 1×User Manual... -
Page 6: Product Diagram-4
PRODUCT DIAGRAM Front View Bottom View 1) Desiccant Box 8 ) Control Panel 2) Lid 9 ) LCD 3) Lid Lock Button 10) Food Tank 11) Battery Cover 4) Food Tank Buckle 5) Base 12) Speaker 6) Food Outlet 13) Power Socket 7) Bowl Holder... -
Page 7: Buttons And Display Overview
BUTTONS AND DISPLAY OVERVIEW MEAL Meal Button: MEAL •Long Press and hold the button for 3s to turn on/off the feeder. •Press for choosing the meal number (1-6 meals). Portion Button: Program the meals portion size ( 0-24 portions). Manual Feeding Button: Dispense one portion food in each bowl by pressing this button. -
Page 8: How To Use-6
1. Press the lid release button to take out the Accessories from the food tank. Automatic Pet Feeder User Manual Model：A303D/A305D Before using this product, please read this manual carefully and keep it for future reference. 2. Put the desiccant into the box under the Lid. - Page 9 4. Add dry pet food to the food tank. Notes： • Do NOT use canned, wet or moist pet food. • Recommend kibble size ranging from 2-15mm / 0.07-0.6in in diameter. 5. Put the lid back on. Press down to make sure it snaps into place.
- Page 10 6. Connect power The feeder supports dual power modes. • Plug the power cable into the power jack under the feeder and the 5V power adapter into a power socket. • Open the battery cover at the bottom of the unit, and install three D alkaline batteries (not included) in case of power outage.
-
Page 11: Program Setting
PROGRAM SETTING 1. Set the Current Time 1) Press and hold the Time setting button for 3s, The hour and minute digit flash. MEAL MEAL 2)Press Hour button to adjust hour, press one time the hour add 1, press Minute button to adjust the minute, press one time the minute add 1. - Page 12 Note: You can change the 12/24 hour format by pressing the Hour button and Minute button together for 3s. When the 12H format is selected, the AM/PM icon will appear on the screen. MEAL MEAL 2. Set the Feeding Time& Portions of Meals 1)Set the first meal feeding time MEAL After the current time setting.
- Page 13 2)Set the portions of the first meal Press Portion button to adjust the meal 1 portions. Press one time the portion add 1. Note: Up to 24 Portions for each meal. MEAL MEAL 3) After you finish the meal 1 setting, you can press the Meal button to select meal 2.
- Page 14 1/2 Cup 2 2 2 2 1/3 Cup 2 2 1 1 1 1 2 2/3 Cup 3 3 4 2 2 3 3 A303D/ 15ml 3/4 Cup 4 4 4 A305D 3 3 3 3 5 5 6 1 Cup...
- Page 15 4.Recording setup • Press and keep holding the Recording button ，the recording indicator light up then you can record for Max 10s sound. If you stop pressing the button when record- ing, the system will recognize you finish the recording. After finishing the recording, you can press Recording button one time to play your recording.
-
Page 16: Clean And Care
6.Low battery reminder • When the batteries are low, the on the LCD screen will turn on. After new batteries are installed, the the LCD screen will be turned off. MEAL CLEAN AND CARE • It's recommended to clean the feeder regularly for the health of your pet. - Page 17 4. To remove the food tank, 3. To remove the holder use your thumbs to press bowl, press down the bowl the buckles on both sides with holder. while pushing upwards at the same time. 6. When install the food 5.
-
Page 18: Troubleshooting
TROUBLESHOOTING Problems Solutions How to delete the press two times quickly until the voice recording. recording indicator light blinking 3 times, then the recording message delete. No display on the 1) Check whether the power adapter is screen. connected to the socket. If properly connected but the problem still exists, you can install three batteries to see if the problem is solved. - Page 19 SPECIFICATIONS Model A303D Food Tank Capacity 3.5 L DC 5V power adapter； 3 x alkaline D Power batteries(not included) Power Adapter AC110-240V input, DC 5V output Working Current Izmax 0.8A Operating Temperature -30°C-50°C/-22°F-122°F External Socket Type-C power socket Net Weight 1.8kg/4lbs...
- Page 20 HoneyGuardian Automatic Pet Feeder Model: A303D/A305D Web：www.honeyguardian.com HoneyGuardian All Rights Reserved. Designet by honeyguardian Made in China...
