Sanyo PDP-42H2A Specifications

4 2 V H I G H D E F I N I T I O N M U L T I M E D I A P L A S M A D I S P L A Y
PDP-42H2A
Multimedia Plasma Display
EXCEPTIONALLY BRIGHT, RICHLY DETAILED IMAGES
This HDTV-compatible 42" plasma monitor offers a typical
contrast ratio of 1000:1 as well as overall brightness rated at
1100 cd/m 2 . It displays a full 1024 x 1024 image (up to 1080
lines interlaced or 720 lines progressive. 3D chrominance-
luminance separation and digital progressive scanning further
enhance its extraordinary picture performance.
TRUE XGA DISPLAY CAPABILITY (OVER 1,000,000 PIXELS)
The PDP-42H2A is ideal for any type of multimedia presentation.
In addition to component and composite video options, it has
been engineered to function as a computer display monitor
meeting XGA display specifications.
EXCELLENT OFF-AXIS VIEWING
The PDP-42H2A performs well in a wide range of room settings.
Its unusually broad viewing angle–more than 175° vertical &
horizontal–ensures that audience members at the extreme right
and left will see a clear, undistorted image without straining.
DYNAMIC AUTOMATIC IMAGE CONTROL
An innovative Dynamic AI circuit constantly monitors different
picture performance parameters (ambient lighting, white balance,
etc.) and automatically makes any adjustments necessary to
maintain optimum image quality. There's even a built-in screen
saver to reduce the possibility of burn-in.
EXTENSIVE INPUT & OUTPUT OPTIONS
Versatility has been designed into the PDP-42H2A. Select from
three S-Video or composite video inputs (3 RCA and 2 BNC),
two component video inputs (RCA and BNC), two computer
inputs (a D-Sub 15 RGB terminal and a DVI-D input with HDCP
for an HD set top box) and an RS-232 control port (serial D-Sub
9). There are also jacks for an external monitor (BNC and RCA)
and optional speakers
OPTIONAL PD-NET ORGANIZER
An optional network card makes it possible to use the PDP-
42H2A as a network monitor, using your internet browser to
monitor and control the display's properties. Additional software
is not required.
PRESENTATION TECHNOLOGIES
Issued 1/05
Type
Screen Size
Display Area
Aspect Ratio
Resolution
Colors
Brightness
Contrast Ratio
Viewing Angle
Computer Compatibility
Plug & Play
Power Management
Audio Amp
Speaker (optional)
Input Terminals
Output Terminals
Power Supply
Power Consumption
Dimensions (WxHxD)
Net Weight
Included Accessories
Optional Accessories
FCC Rating
21605 Plummer Street
Chatsworth, CA 91311
Ph: 818.998.7322 ext. 288
Fax 818.717.2719
www.sanyolcd.com
S p e c i f i c a t i o n s
AV1
AV2
AV3
Component 1
Component 2
Computer 1
Computer 2
RS-232
Monitor
External Speaker
40.8" x 25.2" x 4.6" (w/o Optional Speakers)
Owner's Manual; Remote Control w/Batteries;
AC Power Cord; BNC-RCA Converter Jacks (3);
Because its products are subject to continuous improvement, SANYO reserves the right to
modify product design and specifications without notice and without incurring any obligations.
Plasma Display w/Optional
Table Top Stand and Speakers
Optional Table Top Stand
(KA-TD-H2S)
Plasma Display Panel
42V
36.3" (W) x 20.6" (H) (41.7" diag.)
16:9
1024 (horizontal) x 1024 (vertical) pixels
16 million
1100 (cd/m for panel)
2
1000:1 (typical)
175° (Vertical/Horizontal)
Up to XGA
VESA DDC2B
VESA DPMS Energy Star
10w + 10w (8Ω)
ø
8 x 2 pcs.
Video (RCA/BNC) / S-Video
Audio (RCA X 2)
Video (RCA/BNC) / S-Video
Audio (RCA x 2)
Video (RCA) / S-Video
Audio (RCA x 2)
Y, Pb/Cb, Pr/Cr (BNC)
Audio (RCA x 2)
Y, Pb/Cb, Pr/Cr (RCA)
Audio (RCA x 2)
RGB (D-Sub 15)
Audio (Stereo Mini-Jack)
DVI-D w/HDCP
Audio (Stereo Mini-Jack)
Serial (D-Sub 9)
Video (BNC/RCA)
Audio (RCA x 2)
Optional; Push-type connector
AC 120V 60Hz
440W (max.)
48.3" x 25.2" x 4.6" (w/ Optional Speakers)
78.8 lbs. (w/o Option)
Ferrite Core (2)
Table Top Stand (KA-TD-H2S)
PD-Net Organizer (KA-PN04)
Speakers (KA-SX42H2)
Class B, UL Listed
Optional Speakers
(KA-SX42H2)
Optional PD-Net Organizer
(KA-PN04)
©2005 SANYO
