OPERATION
Please read these instructions
carefully before using the Power
Adapter/Battery Charger.
Warning
To avoid electrical shock, connect the
PM8907 Power Adapter to the AC
outlet before connection to the
®
ScopeMeter
test tool.
The Power Adapter/Battery Charger
operates the ScopeMeter
from the local line.
The Power Adapter/Battery Charger
charges the internal Ni-Cd Battery
Pack of the test tool.
Observe the polarity 5-mm power
jack; the outer contact is plus (+)
polarity.
Do not open the PM8907, it is not
serviceable.
SYMBOLS
International electrical symbols used are
explained below.
See explanation on
Instruction Sheet
DOUBLE INSULATION
(Protection Class)
Conformité Européenne
UL Listed
®
test tool
Figure 2. PM8907/803 and PM8907/806
Figure 1. PM8907/801
Figure 3. PM8907/804
Figure 4. PM8907/807
Figure 5. PM8907/808
Caution
Before you connect the PM8907/808 to
the local line, first check the
preselected voltage setting on this
unit. You can find the voltage selector
switch on the bottom of the
PM8907/808. If necessary, select the
corresponding line voltage with the
slide switch and ensure that the
proper voltage is visible in the
window of the slide selector. (see
Figure 5.)
For connection to the mains outlet,
use a power cord that complies with
national standards.
