- Page 1 FR Description du produit IT Descrizione del prodotto EN Product description NL Productomschrijving ES Descripción del producto PT Descrição do produto DE Produktbeschreibung SMOOZ Toboggan...
- Page 2 Meuble à usage domestique / Domestic furniture / Meuble a uso domestico / Möbel für den häuslichen Wohngebrauch/ Mobili per la casa/ Huishoudmeubilair / Mobiliário doméstico 158184VERT GREEN/ VERT/ GROEN/ VERDE 3517920743537 GREEN/ VERT/ GROEN/ VERDE 1. Reperez les pieces constituant votre meuble. 2.
- Page 3 1. Bitte überprüfen Sie, ob alle Einzelteile lhres Möbelstücks vorhanden sind. 2. Bitte überprüfen Sie, ob alle Schrauben und Verbindungsteile für die Montage vorhanden sind. 3. Halten sie alle notwendigen Montage-Werkzeuge für ihren Einsatz gebrauchsbereit. 4. Bereiten Sie einen passen Ort für die Montage vor. Ein Teppichboden oder ähnliches schützt vor Kratzern. 5.
- Page 4 IMPORTANT, A CONSERVEZ-LES POUR UNE REFERENCE ULTERIEURE: LIRE ATTENTIVEMENT IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY IMPORTANTE, CONSERVAR PARA FUTURAS CONSULTAS: LEER ATENTAMENTE WICHTIG, FÜR SPÄTERES NACHSCHLAGEN AUFBEWAHREN: SORGFÄLTIG LESEN IMPORTANTE, CONSERVARE PER RIFERIMENTO FUTURO, LEGGERE CON ATTENZIONE BELANGRIJK, BEWAARALS EVENTUEEL NASLAGWERK, ZORGVULDIG LEZEN IMPORTANTE, GUARDAR PARA REFERÊNCIA...
-
Page 5: Safety Notes
SAFETY NOTES To prevent damage and accidents to persons and/or property, the following instructions and advice must be followed: 1. Thoroughly read all parts of this manual and strictly follow the instructions before using. 2. Do not use any accessories other than those provided and /or specified by the manufacturer. 3. -
Page 6: Component List
COMPONENT LIST Description Q'ty M6 30mm bolt M6 35mm bolt M6 25mm bolt M6 washer Spring washer Domenut Tie bar Ladder step Ladder stabilizar bar Wavy slide chute Tie bar Handrail tube Spanner Ground anchor Chute bottom support tube Plastic cap 15mm bolt 40mm bolt M6 square washer... -
Page 7: Assembly Steps
Assembly Steps: Step 1 Assembling the Ladder 1.-1 Fix step H to handrail tube L using bolt set (bolt S x 1 + square washer U x 1 ). Insert plastic cap R x 2 into upper handrail tube L 1.-2 Attach the handrail tube L to ladder stabilizer bar I using bolt set (bolt B x 1 + washer D x 1 + spring washer E x 1 + domenut F x 1). - Page 8 Step 2 Combine the Chute and the Ladder 2.-1 Attach the slide chute J with handrail, handrail L go through top hole of chute 2.-2 By using bolt set ( bolt B x 1 + washer D x 1 + spring washer E x 1 + domenut F x 1) to make slide chute and handrail L tie together.
- Page 9 Step 4 Assembling the Bottom Chute Support Tube 4.-1 Attach the bottom chute support tube P with tie bar K using bolt set (bolt A x 1 + washer D x 1 + spring washer E x 1 + domenut F x 1). 4.-2 Fix slide chute to the bottom chute support tube P, through bottom sided holes on slide chute using bolt set (bolt T x 1 ).
- Page 10 Step 5 Assembling the Ground Anchors 5.-1 Fix each side of ladder stabilizer bar on ground using ground anchor O. 5.-2 When selecting a place to install the equipment, take into account the space required for the training activity. Allowing a margin of at least 1.5 m on all sides.
-
Page 11: Care And Maintenance
Care and maintenance This equipment must be assembled and checked by an adult. Regularly check all nuts and bolts for tightness before use and replace any worn, defective or missing parts. DO NOT try to repaire broken parts. Regularly check wavy slide, steel tube, step, ground anchor and other parts are tightened completely and replace worn &... -
Page 12: Explosive Drawing
Explosive Drawing... - Page 13 VS-Jul-2017 Imported by - Importé par CAFOM DISTRIBUTION 9 Rue Jacquart 93310 Le Pré-Saint-Gervais Made in China/ Fabriqué en Chine...
