VIDEO MOUNT PRODUCTS
Instruction Sheet For:
SCM-1

Advertisement

loading
Need help?

Need help?

Do you have a question about the SCM-1 and is the answer not in the manual?

Questions and answers

Related Manuals for CablesPlus SCM-1

Summary of Contents for CablesPlus SCM-1

  • Page 1 VIDEO MOUNT PRODUCTS Instruction Sheet For: SCM-1...
  • Page 2 Step 1 Before starting, lay out all parts to your mount and match them to the parts list provided. Verify that you have all your parts before attempt- ing to assemble the mount. Step 2 Lay the ceiling plate onto the ceiling grid so the lips of the ceil- ing plate rest on top of the ceiling runners.
  • Page 3 Step 5 Insert the turnbuckles into the ceiling plate . Make sure to use the sets of four holes in each corner of the ceiling plate and not the center hole on each side. If necessary use the wood screw eyebolt or concrete anchor to provide tie wire anchor points.
  • Page 4 Step 8 Place the escutcheon ring adaptor on top of the ceiling tile and trace around the outside of the adaptor. Then proceed to cut just inside the circle drawn. Insert the adaptor into the hole making sure you have a tight fi t, and the wider top is on top of the ceiling tile. If necessary widen the hole slightly to fi...
