Summary of Contents for CablesPlus VH-001
- Page 1 VIDEO MOUNT PRODUCTS Instruction Sheet For: VH-001 & VH-001S...
- Page 2 VH-001. If you are trying to connect the VH-001 to a W-13 or a C-13 proceed to step 3. If you are trying to connect the VH-001 to a C-20, C-27, W-20, or W-27 proceed to step Step 3: Removing the platform from 6.
- Page 3 Step 6: Removing the platform Step 8 Connect the VH-001 force arm VH-001 by inserting the M6 screw VH-001 through the force arm and securing with a plug, washer, and nylon nut , and VH-001 and reattach the platform by reversing step 6. Once this is completed please skip to step 14.
- Page 4 VH-001 attach the force arm to the nut. Once the 3/8” screw VH-001 is securely tightened, use a brake screw VH-001 to secure the 3/8” screw in the nut. Once this is com- pleted please proceed to step 14. Step 11 : Removing the nylon nut...
- Page 5 Step 14 Now that the VH-001 force arm VH-001 is attached, it is time to assemble the rest of the VH-001. First attach the non-skid padding VH-001 to the adjustable stopper VH-001. Next attach the adjustable stoppers VH-001 to the extension holder VH-001 using the butterfl...
