Summary of Contents for Allied Vision FPD-LINK III
- Page 1 FPD-L III C LVIUM AMERAS Deserializer Board FPD-Link III Coax to CSI-2 User Guide V1.0.0 Allied Vision Technologies GmbH // Taschenweg 2a, 07646 Stadtroda / Germany 2023-Apr-27...
-
Page 2: Read Before Use
The product in operation can reach temperature levels which could cause burns. Intended use Intended use of Allied Vision product is the integration into vision systems by professionals. All Allied Vision product is sold in a B2B setting. DA - Dansk Sikkerhed Læs sikkerhedsanvisningerne, før produkt bruges. - Page 3 El producto en funcionamiento puede alcanzar temperaturas que podrían provocar quemaduras. Uso previsto El uso previsto del producto Allied Vision es la integración en el sistema de visión por parte de profesionales. Todos los productos Allied Vision se venden dentro de una relación B2B.
- Page 4 Utilisation prévue L’utilisation prévue du produit Allied Vision est son intégration dans des systèmes de vision par le soin de professionnels. Tout produit Allied Vision est vendu dans un cadre B2B. Deserializer Board FPD-Link III Coax to CSI-2 User Guide V1.0.0...
- Page 5 Durante il funzionamento, il prodotto può raggiungere temperature elevate che possono essere causa di ustioni. Uso previsto Il prodotto Allied Vision è concepito per essere integrato in sistemi di monitoraggio in campo professionale. Tutti i prodotti Allied Vision sono venduti in uno scenario B2B.
- Page 6 Het gebruikte product, kan temperatuurwaarden bereiken die brandwonden kunnen veroorzaken. Beoogd gebruik Het beoogde gebruik van het Allied Vision-product is de integratie in optische systemen door professionals. Alle Allied Vision-producten worden verkocht in de B2B-markt. Deserializer Board FPD-Link III Coax to CSI-2 User Guide V1.0.0...
- Page 7 FORSIKTIG Risiko for brannskader Produktet i bruk kan nå temperaturnivåer som kan forårsake brannskader. Tiltenkt bruk Den tiltenkte bruken av Allied Vision-produktet er integrering i visjonssystemer av profesjonelle. Alle Allied Vision-produkter selges i en forretning til forretning-situasjon. SV - Svenska Säkerhet...
- Page 8 Read before use ZH - 简体中文版 安全需知 在使用产品之前，请阅读这些安全说明。请务必遵守相关警告 和 Intended 于第 18 页 . 注意事项 烫伤风险 在产品运行过程中，温度可能会上升，导致烧伤的危险。 预期用途 Allied Vision 产品的预期用途是由专业人士整合到视觉系统中。所有 Allied Vision 的产品均通过 B2B 渠道销售。 Deserializer Board FPD-Link III Coax to CSI-2 User Guide V1.0.0...
-
Page 9: This Document At A Glance
This document at a glance Get an overview of documentation for the Deserializer Board FPD-Link III Coax to CSI-2: Note..................10 Shipping contents..............10 What else do you need? ............10 Deserializer Board FPD-Link III Coax to CSI-2 User Guide V1.0.0... -
Page 10: Note
FPC cables, I/O cables, lenses, www.alliedvision.com/en/products/accessories and tripod adapters SerDes Configurator: Please contact www.alliedvision.com/en/about-us/contact-us/ the Allied Vision Support team at... technical-support-repair-/-rma Table 1: Downloads for Deserializer Board FPD-Link III Coax to CSI-2 Deserializer Board FPD-Link III Coax to CSI-2 User Guide V1.0.0... -
Page 11: Contact Us
102 Pickering Way - Suite 502 Allied Vision Technologies Asia Pte. Ltd Exton, PA 19341, USA 82 Playfair Rd, #07-01 D'Lithium Toll-free// +1-877-USA-1394 Singapore 368001 T// +1 978 225 2030 T// +65 6634 9027 Deserializer Board FPD-Link III Coax to CSI-2 User Guide V1.0.0... -
Page 12: Table Of Contents
Connecting FPC cables ..............31 Deserializer Board FPD-Link III Coax to CSI-2 User Guide V1.0.0... - Page 13 Connecting power ............... . . 34 Deserializer Board FPD-Link III Coax to CSI-2 User Guide V1.0.0...
-
Page 14: Document History And Conventions
Document history and conventions This chapter includes: Document history ..............15 Conventions used in this user guide........15 Component naming .............. 16 Deserializer Board FPD-Link III Coax to CSI-2 User Guide V1.0.0... -
Page 15: Document History
Precautions are described. Practical tip Additional information helps to understand or ease handling the camera and components. Additional information Web link or reference to an external source with more information is shown. Deserializer Board FPD-Link III Coax to CSI-2 User Guide V1.0.0... -
Page 16: Component Naming
Deserializer Board FPD-Link III Coax to CSI-2 Example: Embedded board NVIDIA Jetson Xavier NX DevKit Hirose FH55-22S-0.55SH FPC (flexible printed circuit) FPC connector connector FPC cable MIPI CSI-2 FPC cable Table 4: Component naming Deserializer Board FPD-Link III Coax to CSI-2 User Guide V1.0.0... -
Page 17: Compliance, Safety, And Intended Use
Compliance, safety, and intended use This chapter includes: Compliance notifications ............18 Intended use ................. 18 Copyright and trademarks ............ 18 Your safety................19 Product safety ............... 19 Deserializer Board FPD-Link III Coax to CSI-2 User Guide V1.0.0... -
Page 18: Compliance Notifications
We are offering standard products as well as customized solutions. Intended use of Allied Vision product is the integration into Vision systems by professionals. All Allied Vision product is sold in a B2B setting. -
Page 19: Your Safety
Even if you are wearing a wrist strap, your body is grounded but your clothes are not. Electrical connections The standard for FPD-Link III does not specify electrical connections as extensively as the USB or GigE standard. Plug and play is not supported. Read specifications carefully. - Page 20 Figure 2: FAKRA coaxial connectors on cameras (left) and on cables (right) Additional information For technical data and more instructions on the FAKRA coxial connector Code Z (water blue), see the manufacturer data sheet at www.rosenberger.com. Deserializer Board FPD-Link III Coax to CSI-2 User Guide V1.0.0...
- Page 21 • Allow only slight bending of the FPC cable (minimum bending radius: 10 mm). • For strain relief, see Strain relief for all cable connections on page 20. Deserializer Board FPD-Link III Coax to CSI-2 User Guide V1.0.0...
- Page 22 • You may mount the camera electrically isolated. • Read the Avoiding Ground Loops in Vision Systems application note. More information See the Avoiding Ground Loops in Vision Systems application note at www.alliedvision.com/en/support/technical-documentation/ alvium-csi-2-documentation. Deserializer Board FPD-Link III Coax to CSI-2 User Guide V1.0.0...
-
Page 23: Specifications
Specifications This chapter includes: Specifications overview............24 PCB and PCBA number............25 Technical drawing..............25 Electronic schematics ............26 Deserializer Board FPD-Link III Coax to CSI-2 User Guide V1.0.0... -
Page 24: Specifications Overview
If enclosed in a housing, ensure that the component temperatures of U4 and L3 do not exceed 105 °C. Figure 5 on page 25. Table 5: Deserializer Board FPD-Link III Coax to CSI-2 specifications overview Specifications of the deserializer chip This deserializer board incorporates the FPD-Link III deserializer chip Texas Instruments DS90UB954-Q1. -
Page 25: Pcb And Pcba Number
Figure 4: PCB and PCBA number on deserializer boards Technical drawing 2.6 (4x) FAKRA Plug Z 11.9 Max. 105 °C Figure 5: Deserializer Board FPD-Link III Coax to CSI-2 dimensions and PCB layout Deserializer Board FPD-Link III Coax to CSI-2 User Guide V1.0.0... -
Page 26: Electronic Schematics
STM8S001J3M3 100n XIN / REFCLK VDD_SEL BISTEN VCC3V3D MODE EN-I2C-HOST EXT-GPIO0-I2C-SCL EXT-GPIO0-I2C-SCL_DESER EXT-GPIO1-I2C-SDA EXT-GPIO1-I2C-SDA_DESER VCC3V3D 74LVC2G66GT,115 100n Figure 6: Deserializer Board FPD-Link III Coax to CSI-2 electronic schematics, part 1 Deserializer Board FPD-Link III Coax to CSI-2 User Guide V1.0.0... - Page 27 V_FB = 0.6V +/- 2% 100n TLV62568ADRL Vout: 0.6V - Vin 100k Vin : 2.5V-5.5V Iout : 1A Figure 7: Deserializer Board FPD-Link III Coax to CSI-2 electronic schematics, part 2 Deserializer Board FPD-Link III Coax to CSI-2 User Guide V1.0.0...
-
Page 28: Setting Up Deserializer Boards
This chapter includes basic instructions on cable connectors: Connecting FAKRA coaxial cables.......... 29 Connecting FPC cables ............31 Followed by instructions for: Mounting deserializer boards..........33 Connecting components to each other........ 33 Connecting power..............34 Deserializer Board FPD-Link III Coax to CSI-2 User Guide V1.0.0... -
Page 29: Connecting Fakra Coaxial Cables
To unplug the cable-side connector, the lever must be pressed all the time while the cable is pulled off the camera connector. Otherwise, the camera-side connector can be torn off the camera. Deserializer Board FPD-Link III Coax to CSI-2 User Guide V1.0.0... -
Page 30: Instructions For Connecting
You may slightly rotate and tilt the cable-side connector against the device to reduce friction. The camera is disconnected. Figure 10: Pressing down the latch (c) of the FAKRA coaxial connector Deserializer Board FPD-Link III Coax to CSI-2 User Guide V1.0.0... -
Page 31: Connecting Fpc Cables
Figure 13: FPC cable and data flow direction 2. Ensuring proper cable orientation between devices to be connected, take the FPC cable with conductors facing the FPC connector conductors (see Figure 14 on page 32). Deserializer Board FPD-Link III Coax to CSI-2 User Guide V1.0.0... - Page 32 Actuator 12° 5. Holding the FPC cable in position, flap down the actuator to closed Figure 15: Engaging the FPC cable in the FPC connector position (see Figure 15). Deserializer Board FPD-Link III Coax to CSI-2 User Guide V1.0.0...
-
Page 33: Mounting Deserializer Boards
For connecting cameras to deserializer boards, follow the instructions in Connecting FAKRA coaxial cables on page 29. For connecting deserializer boards to the host, follow the instructions in Connecting FPC cables on page 31. Deserializer Board FPD-Link III Coax to CSI-2 User Guide V1.0.0... -
Page 34: Connecting Power
Figure 16: Connections and jumper settings for power supply 4. Connect the power supplies to the mains power. 5. Power and boot the embedded system. Your vision application is ready for first operation. Deserializer Board FPD-Link III Coax to CSI-2 User Guide V1.0.0...
