Summary of Contents for Allied Vision MAKO U-029B
- Page 1 USB3 V ISION AMERAS Mako U Technical Manual V1.1.3 Allied Vision Technologies GmbH // Taschenweg 2a, 07646 Stadtroda / Germany 2018-Jan-16...
-
Page 2: Mako U At A Glance
Mako U at a glance Mako U at a glance Read this manual carefully Learn how to protect your camera from damage and fully understand its functions. Delivery contents Your Mako U delivery consists of the following items: • Shipping box •... -
Page 3: Contact Us
Contact us Contact us Connect with Allied Vision by function https://www.alliedvision.com/en/meta-header/contact Find an Allied Vision office or distributor https://www.alliedvision.com/en/about-us/where-we-are Email info@alliedvision.com support@alliedvision.com Telephone EMEA: +49 36428-677-0 The Americas: +1 978-225-2030 Asia-Pacific: +65 6634-9027 China: +86 (21) 64861133 Headquarters Allied Vision Technologies GmbH... -
Page 4: Table Of Contents
Contents Contents Mako U at a glance ..............2 Delivery contents. - Page 5 Mako U-029B absolute quantum efficiency ........
- Page 6 Contents Installing the camera driver ............. . 68 Installing the camera driver with Windows tools .
- Page 7 Contents Image data flow ..............94 Mako U cameras .
-
Page 8: Document History And Conventions
Document history and conventions This chapter includes: Document history ..............9 Conventions used in this manual.......... 10 Mako U Technical Manual V1.1.3... -
Page 9: Document History
Document history and conventions Document history Version Date Remarks V1.0.0 2015-Nov-13 New manual: Release status V1.1.0 2017-Jul-27 Added information that S-Mount is the same as M12-Mount in Applied standards and in Filters and M12-Mount adapter. Added information on EMVA1288 measurement uncertainty in Applied standards. -
Page 10: Conventions Used In This Manual
Document history and conventions Conventions used in this manual To give this manual an easily understood layout and to emphasize important information, the following typographical styles and symbols are used: Styles Style Function Emphasis Programs, or highlighting important things Publication titles Publication titles Weblinks and references Links to web pages and internal cross references... -
Page 11: Product Naming
Document history and conventions Product naming Names of third-party products in this document are shortened to ease reading. Nevertheless, we respect all manufacturer rights and trademarks. Official product name Naming in this document Manufacturer website Linux operating system Linux https://www.linux.com/ Microsoft Windows Operating System Windows https://www.microsoft.com... -
Page 12: Compliance, Safety, And Intended Use
Compliance, safety, and intended use This chapter includes: Compliance notifications ............. 13 Camera applications and intended use ....... 14 Safety..................15 Mako U Technical Manual V1.1.3... -
Page 13: Compliance Notifications
Compliance, safety, and intended use Compliance notifications For customers in Europe: Allied Vision has demonstrated the fulfillment of the requirements relating to the Mako U camera family: • Directive 2014/30/EU (Electromagnetic compatibility) • Directive 2011/65/EU (RoHS) For customers in the USA... -
Page 14: Camera Applications And Intended Use
• The camera-supporting software can be obtained and installed separately from the camera. Usage of the software is solely the responsibility of the user. • The camera must not be opened. For all repair tasks, contact Allied Vision or one of Allied Vision's authorized representatives. -
Page 15: Safety
Compliance, safety, and intended use Safety Handling and operating of Mako U cameras does not include risks of personal injury. To prevent material damage, read the following and understand how to safely handle and operate the camera. Get helpful details about USB 3.0 and learn how to optimize camera performance. - Page 16 Compliance, safety, and intended use Ground loops Unsuitable connection can lead to a short circuit caused by ground loops between USB GND, GPIO GND, and environmental setup GND. This short circuit can lead to malfunctions or destroy camera and connected devices. Mount the camera electrically isolated to avoid ground loops.
- Page 17 Compliance, safety, and intended use Ground loop explanation Ground loops can occur only for camera applications including both: • PELV-powered devices in the machine application • Use of camera GPIOs With the graphics on the following pages, you can easily recognize if ground loops may occur for your application.
- Page 18 Compliance, safety, and intended use Setup causing a ground loop Graphics legend Gray line Cable connection Blue line PE ground Red line Ground loop Ground loop: GPIOs and PELV devices Figure 2, a USB camera uses non-isolated GPIOs, while PELV-powered devices are resident in the environmental setup.
- Page 19 Compliance, safety, and intended use Setups to avoid ground loops Graphics legend Gray line Cable connection Blue line PE ground Green square Isolator avoiding ground loops No ground loop: GPIOs and barrier isolator Figure 3, a barrier isolator between camera GPIO and the environmental setup avoids ground loops.
- Page 20 USB cables Proper cable handling enables reliable performance: • Use only shielded cables to avoid electromagnetic interferences. • Please use cables recommended by Allied Vision. • Avoid unnecessary bending to prevent damaging the cables. • Avoid coiling to prevent electromagnetic interference.
-
Page 21: Optical Components
Compliance, safety, and intended use Optical components Image sensor Image sensors are sensitive to excessive radiation: focused sunlight, lasers, and X-rays can damage the sensor. Mako U cameras are not fitted with filter or protection glass. Consider, when removing the lens or dust cap on these cameras, the sensor is not protected against dirt or scratches. - Page 22 Mount Figure 6: Mount and protrusion Cleaning optical components New Allied Vision cameras do not need additional cleaning. Cameras are cleaned before shipping. Reference images for each camera document cleaning quality. However, if cleaning is necessary: • Use only recommended cleaning material.
-
Page 23: Heat Dissipation
Compliance, safety, and intended use Compressed air We recommend wet cleaning, see Cleaning optical components on page 100. If wet cleaning does not succeed, we recommend you to contact support@alliedvision.com. In general, compressed air should be avoided. Wrong handling can damage optical components irreversibly, especially the sensitive sensor. -
Page 24: Specifications
Specifications This chapter includes: Applied standards ..............25 Notes on specifications............26 Mako U-029B/051B/130B characteristics ......29 Mako U-029B specifications ..........30 Mako U-051B specifications ..........32 Mako U-130B specifications ..........35 Mako U-503B characteristics ..........38 Mako U-503B specifications ..........41 Mechanical dimensions ............ -
Page 25: Applied Standards
Specifications Applied standards Mako U cameras have a USB 3.0 interface. They are USB3 Vision V1.0.1 compliant. GenICam GenICam is the programming interface for the USB3 Vision camera controls. GenICam is administered by the European Machine Vision Association (EMVA). GenICam establishes a common camera control interface allowing third-party software to communicate with cameras from various manufacturers without customization. -
Page 26: Notes On Specifications
• For USB 3.0 cards, hubs, and cables, see Accessories on page 57. Mako U-503B characteristics Mako U-503B differ in some characteristics from Mako U-029B, 051B, and 130B models. See Mako U-503B characteristics on page 38. Power consumption Values are given for “typical”... -
Page 27: Fixed Frame Rate Control
Mako U-029B / 051B / 130B models support Timed and TriggerWidth. Controlling exposure time using TriggerWidth For Mako U-029B / 051B / 130B cameras, to control exposure time by TriggerWidth, set TriggerActivation to LevelHigh or LevelLow. Absolute quantum efficiency (QE) plots All measurements were done without protection glass / IR cut filter. -
Page 28: Roi Frame Rates
Specifications ROI frame rates Calculation of Region of interest (ROI) frame rates for Mako U cameras does not allow to give a formula. Data was determined for Mono8 at shortest exposure time. Bandwidth can limit the available maximum. USB hardware and bandwidth Currently, USB hardware often limits the available bandwidth. -
Page 29: Mako U-029B/051B/130B Characteristics
PYTHON sensors have a typical black level value drift that depends on DeviceTemperature (measured at the mainboard) and ExposureTime. The Black Level Compensation for Mako U-029B / 051B / 130B models adjusts this effect as shown in the following table. -
Page 30: Mako U-029B Specifications
Typical 2.7 W @ 5 VDC, maximum frame rate, full resolution, 20 °C Operating temperature +5 °C to +45 °C housing temperature (without condensation) Storage temperature -10 °C to +70 °C ambient temperature (without condensation) Table 6: Specifications Mako U-029B Mako U Technical Manual V1.1.3... -
Page 31: Mako U-029B Absolute Quantum Efficiency
For this sensor, maximum frame rates are limited by minimal exposure times. Width Height ROI area Frame rate 307,200 20,480 3,097 10,240 3,710 5,120 4,118 76,800 1,350 4,971 Table 7: Frame rates for different ROIs with Mako U-029B Mako U Technical Manual V1.1.3... -
Page 32: Mako U-051B Specifications
Specifications Mako U-051B specifications Camera characteristics Mako U-029B/051B/130B characteristics on page 29. Feature Specification Sensor Sensor details 1/3.6” (diag. 4.8 mm) progressive scan CMOS ON Semiconductor PYTHON 500, global shutter Effective chip size 3.84 x 2.88 mm Cell size 4.8 x 4.8 µm... -
Page 33: Mako U-051B Absolute Quantum Efficiency
Specifications Mako U-051B absolute quantum efficiency Monochrome QE ON Semiconductor PYTHON 300, 500, 1300 absolute QE All meas The uncertainty of measurement of the QE is +/ 10.25%. With protection glass or filte The values are typical and are subject to minor variations. 1000 1050 1100... -
Page 34: Mako U-051B Roi Frame Rates
Specifications Mako U-051B ROI frame rates This section charts the resulting frame rates from changing image heights and widths. Available maximum frame rates For this sensor, maximum frame rates are limited by minimal exposure times. Width Height ROI area Frame rate 480,000 25,600 2,898... -
Page 35: Mako U-130B Specifications
Specifications Mako U-130B specifications Camera characteristics Mako U-029B/051B/130B characteristics on page 29. Feature Specification Sensor Sensor details 1/2” (diag. 7.9 mm) progressive scan CMOS ON Semiconductor PYTHON 1300, global shutter Effective chip size 6.32 x 4.74 mm Cell size 4.8 x 4.8 µm... -
Page 36: Mako U-130B Absolute Quantum Efficiency
Specifications Mako U-130B absolute quantum efficiency Monochrome QE ON Semiconductor PYTHON 300, 500, 1300 absolute QE All meas The uncertainty of measurement of the QE is +/ 10.25%. With protection glass or filte The values are typical and are subject to minor variations. 1000 1050 1100... -
Page 37: Mako U-130B Roi Frame Rates
Specifications Mako U-130B ROI frame rates This section charts the resulting frame rates from changing image heights and widths. Available maximum frame rates For this sensor, maximum frame rates are limited by minimal exposure times. Width Height ROI area Frame rate 1,280 1,024 1,310,720... -
Page 38: Mako U-503B Characteristics
Specifications Mako U-503B characteristics Mako U-503B is equipped with an ON Semiconductor MT9P031 sensor determining certain camera abilities. This section is about Mako U-503B characteristics: • ExposureMode and triggering on page 38 • Rolling shutter on page 39 • Gain on page 40 •... -
Page 39: Rolling Shutter
(right) of a rotating fan appears natural. Lines Time Figure 11: Global shutter effect with Mako U-029B / 051B / 130B Avoiding the rolling shutter effect with the Mako U-503B camera. Figure 12 shows how the rolling shutter effect can be avoided. With a strobe light fired while all sensor lines (left) are integrating, the image (right) of a rotating fan appears natural. -
Page 40: Gain
Specifications Gain The ON Semiconductor MT9P031 sensor provides analog gain for the following increments only: • 2.5 dB • 3.2 dB • 5.0 dB • 14.9 dB You can set gain for the Mako U-503B camera in 0.1 dB increments. To set increments in-between the analog increments listed above, the digital gain is used. -
Page 41: Mako U-503B Specifications
Specifications Mako U-503B specifications Camera characteristics Mako U-503B specifications on page 41. Feature Specification Sensor Sensor details 1/2.5” (diag. 7.13 mm) progressive scan CMOS ON Semiconductor MT9P031, rolling shutter Effective chip size 5.7 x 4.28 mm Cell size 2.2 x 2.2 µm Resolution (H x V) 2592 x 1944 12-bit... -
Page 42: Mako U-503B Absolute Quantum Efficiency
Specifications Mako U-503B absolute quantum efficiency Monochrome QE ON Semiconductor MT9P031 absolute QE All measurements were done without protec on glass or IR cut ter. With p glass or ers, quantum e (QE) decreases b approximatel 10%. The uncertaint in measurement of the QE is +/- 10.25%. The values are cal and are subject to minor va ons. -
Page 43: Mako U-503B Roi Frame Rates
Specifications Mako U-503B ROI frame rates This section charts the resulting frame rates from changing image heights and widths. Width Height ROI area Frame rate 2,592 1,944 5,038,848 2,592 77,760 2,592 25,920 1200 2,592 5,184 1,850 2,048 1,536 3,145,728 1,920 1,080 2,073,600 1,600... -
Page 44: Mechanical Dimensions
Specifications Mechanical dimensions Handling and attaching the camera To mount the camera properly, see Mounting the camera on page 72. Mako U housing 23.7 M3 - 4 M3 - 2.3 (3x) M2 - 3.6 (4x) 16.5 49.5 43.6 M2 - 4 (2x) C-Mount 31.5 12.2... -
Page 45: Lens Mounts
Specifications Lens mounts Maximum protrusion Filter diameter Mount Figure 16: Mount and protrusion Figure 16 shows maximum protrusion with a built-in filter. Mako U cameras come without filter or protection glass. Table 14 shows values for maximum protrusion for the standard version and for modular options. Modular options For Mako U modular options, see the Modular Concept at Additional Documents for the Mako U camera:... -
Page 46: Sensor Position Accuracy
Specifications Adjustment of mount dimensions If you want to adjust mount dimensions, contact support@alliedvision.com. CS- and M12-Mount option Mako U standard cameras are equipped with a C-Mount. For a CS-Mount or the M12-Mount adapter, or to individually choose a protection glass or filter, see Modular Concept, at Additional Documents for the Mako U camera: https://www.alliedvision.com/en/support/technical-documentation. -
Page 47: Camera Features Available With Vimba
Camera features available with Vimba This chapter provides a list of camera features available for Mako U cameras. Mako U Technical Manual V1.1.3... -
Page 48: About Camera Features
Camera features available with Vimba About camera features This chapter lists available camera features for: • Software coding with the Allied Vision transport layer (TL) • Camera control with Vimba Viewer. Features and third-party TL Under a third-party TL, Vimba features may appear differently or disappear. -
Page 49: Features List Order
Camera features available with Vimba Features list order This section describes the camera features as displayed with Vimba Viewer, listed in categories in alphabetical order. Selectors Some features have multiple instances. For these features, Selector features define which instance of the feature is accessed. Example: the LineInverter feature, used to invert internal signal polarity, can be applied to all input and output lines of the camera. -
Page 50: Camera Features List
Camera features available with Vimba Camera features list Category Feature Type Value AcquisitionControl AcquisitionAbort Command AcquisitionFrameCount Integer AcquisitionFrameRate Float Enumeration AcquisitionFrameRateMode Basic AcquisitionMode Enumeration SingleFrame MultiFrame Continuous AcquisitionStart Command AcquisitionStatus Boolean [AcquisitionStatusSelector] False True AcquisitionStatusSelector Enumeration AcquisitionTriggerWait AcquisitionActive AcquisitionTransfer FrameTriggerWait FrameActive ExposureActive AcquisitionStop... - Page 51 Camera features available with Vimba Category Feature Type Value TriggerMode[TriggerSelector] Enumeration TriggerSelector Enumeration AcquisitionStart FrameStart TriggerSoftware[TriggerSelector] Command TriggerSource[TriggerSelector] Enumeration Software Line0 Line1 Line2 Line3 AnalogControl BlackLevel[BlackLevelSelector] Float BlackLevelSelector Enumeration Gain[GainSelector] Float GainSelector Enumeration Gamma Float BufferHandlingControl Integer MaxDriverBuffersCount StreamAnnounceBufferMinimum Integer StreamAnnouncedBufferCount Integer StreamBufferHandlingMode...
- Page 52 Camera features available with Vimba Category Feature Type Value Enumeration CorrectionSetSelector Factory User CorrectionControl CorrectionInfo Integer CorrectionDataSize [CorrectionSelecto r][CorrectionSetSelector] String CorrectionDescription [CorrectionSelector] Enumeration CorrectionEntryType [CorrectionSelector DeviceControl DeviceFamilyName String String DeviceFirmwareID [DeviceFirmwareIDSelector] Enumeration DeviceFirmwareIDSelector Current Supported DeviceFirmwareVersion String [DeviceFirmwareVersionSelector] Enumeration DeviceFirmwareVersionSelector Current Programmed DeviceGenCPVersionMajor...
- Page 53 Camera features available with Vimba Category Feature Type Value DeviceSFNCVersionMinor Integer DeviceSFNCVersionSubMinor Integer DeviceScanType Enumeration Areascan DeviceSerialNumber String DeviceTemperature Float DeviceTemperatureSelector Enumeration Mainboard DeviceUserID String DeviceVendorName String DeviceVersion String Timestamp Integer DigitalIOControl Enumeration InputDebounceMode [LineSelector] Float InputDebounceTime [LineSelector] LineInverter[LineSelector] Boolean False True LineMode[LineSelector]...
- Page 54 Camera features available with Vimba Category Feature Type Value UserOutput0 UserOutput1 UserOutput2 UserOutput3 LineStatus[LineSelector] Boolean True False Enumeration OutputDurationMode [LineSelector] Float OutputDurationTime [LineSelector] UserOutputSelector Enumeration UserOutput0 UserOutput1 UserOutput2 UserOutput3 UserOutputValue Boolean [UserOutputSelector] False True FileAccessControl FileAccessBuffer DataRaw FileAccessLength Integer [FileSelector][FileOperationSelector] FileAccessOffset Integer [FileSelector][FileOperationSelector]...
- Page 55 Camera features available with Vimba Category Feature Type Value FileOperationStatus Enumeration [FileSelector][FileOperationSelector] Success Failure Invalid Denied Error Enumeration FileProcessStatus [FileSelector][FileOperationSelector] UpdateNotRequired None FileSelector Enumeration Firmware UserData DefectPixelCorrection FixedPatternNoise Correction FileSize[FileSelector] Integer Enumeration FileStatus Open Closed ImageFormatControl Height Integer HeightMax Integer OffsetX Integer OffsetY...
- Page 56 Camera features available with Vimba Category Feature Type Value ReverseX Boolean false true SensorHeight Integer SensorWidth Integer Width Integer Width Max Integer StreamInformation StreamID String StreamIsGrabbing Boolean False True StreamType Enumeration USB3 TestControl TestPendingAck Integer TransportLayerControl PayloadSize Integer UserSetControl UserSetDefault Enumeration Default UserSet1...
-
Page 57: Accessories
Accessories This chapter includes: USB 3.0 cards, hubs, and cables ........... 58 6-pin Hirose I/O cables............59 Mako tripod adapters ............60 Filters and M12-Mount adapter ........... 62 Lenses: Focal length vs. field of view........63 Mako U Technical Manual V1.1.3... -
Page 58: Usb 3.0 Cards, Hubs, And Cables
USB 3.0 cards, hubs, and cables For proper function and maximum performance of Mako U cameras, we recom- mend USB 3.0 accessories tested by Allied Vision. The particular hardware combi- nation influences the result; therefore, the available bandwidth cannot be predicted.. -
Page 59: 6-Pin Hirose I/O Cables
The General Purpose I/O port uses a Hirose HR10A-7R-6PB(73) connector on the camera side. The mating cable connector is: • Hirose HR10A-7P-6S(73) for soldering • Hirose HR10A-7P-6SC(73) for crimping Hirose connector cables for purchase from Allied Vision: I/O cables Properties Product codes... -
Page 60: Mako Tripod Adapters
Accessories Mako tripod adapters Notice Avoid damage to the camera by using inappropriate accessories To avoid damage to Mako cameras, use suitable tripod adapters only. The rear through hole of the Mako U tripod adapter enables the bolt to dive in deeper. -
Page 61: Mako U Tripod Adapter Dimensions
Mako U tripod adapter dimensions 29.7 23.7 R2.5 (4x) 3.4 (3x) 10.9 R3 (4x) 0.2 x 45° 0.5 x 45° (2x) UNC 1/4"-20 Figure 18: Allied Vision Mako U tripod adapter dimensions (Allied Vision product code 9222) Mako U Technical Manual V1.1.3... -
Page 62: Filters And M12-Mount Adapter
Accessories Filters and M12-Mount adapter Mako U cameras have a C-Mount and no filter or protection glass. Among others, you can order the Mako U modular options: • IR-cut/IRC filters or protection glass • CS-Mount • M12-Mount adapter (with CS-Mount). Description of the M12-Mount adapter The M12-Mount adapter enables the use of M12-Mount lenses with a CS-Mount camera. -
Page 63: Lenses: Focal Length Vs. Field Of View
For demanding applications, we suggest testing camera and lens to find a suitable setup. In doubt, please contact Allied Vision. Allied Vision collaborates with leading lens manufacturers. We do extensive testing to recommend appropriate lenses for your cameras. The tables below list selected image formats in width x height depending on: •... - Page 64 119 x 89 mm 35 mm 40 x 30 mm 84 x 63 mm Table 23: Focal length vs. field of view (Mako U-029B) Focal length: Mako U-051B, Type 1/3.6 sensor Distance = 500 mm Distance = 1000 mm 4.8 mm...
-
Page 65: Installing The Camera
Installing the camera This chapter includes: Prerequisites ................. 66 Installing the camera using Vimba on a Windows system ... 67 Mounting the camera ............72 Mako U Technical Manual V1.1.3... -
Page 66: Prerequisites
Installing the camera Prerequisites More details on requirements and software installation This section lists general requirements to operate Allied Vision USB3 Vision cameras on your system. To download Vimba, including Vimba Viewer and Vimba Driver Installer for Windows, see https://www.alliedvision.com/software. -
Page 67: Installing The Camera Using Vimba On A Windows System
Using the camera with third-party software Allied Vision USB cameras comply with the USB3 Vision standard. They can be used with many non-vendor specific third-party software that complies with the USB3 Vision standard. Using the camera with third-party drivers Allied Vision USB cameras work properly with most third-party drivers. -
Page 68: Installing The Camera Driver
Installing the camera Installing the camera driver Connecting the camera to a USB 2.0 port If the Mako U camera is connected to a USB 2.0 port, the Vimba driver cannot be installed, as shown below. • Disconnect the camera and reconnect it to a USB 3.0 port. 1. - Page 69 Installing the camera 5. Click Apply to install the Vimba driver for the camera. Figure 20: Vimba Driver Installer, driver installation started The driver has been installed successfully. Figure 21: Vimba Driver Installer, driver installed successfully Manual Vimba Driver installation For manual Vimba Driver installation, see Installing the camera driver with Windows tools...
-
Page 70: Installing The Camera Driver With Windows Tools
Under Windows, the Device Manager provides an overview of USB 3.0 resources and connected devices. As long as the Allied Vision USB 3.0 device driver is not installed, the camera is not recognized. - Page 71 Installing the camera 2. Click: “Browse my computer for driver software”. 3. Select [Your local Vimba directory]\Allied Vision\Vimba_V.x.x\Vim- baUSBTL\Driver. 4. Follow the instructions. The camera driver is installed successfully. Figure 24: Windows Device Manager, USB3 Vision camera installed successfully Mako U Technical Manual V1.1.3...
-
Page 72: Mounting The Camera
Installing the camera Mounting the camera Notice Avoid damage to the camera by high voltage • Mount the camera electrically isolated to avoid ground loops. • For more information on ground loops, see Ground loops on page 16. Mount the camera using suitable bolts. •... -
Page 73: Camera Interfaces
Camera interfaces This chapter includes: Back panel ................74 I/O connector pin assignment ..........75 Opto-isolated I/Os..............76 Non-isolated, programmable GPIOs........80 Status LEDs ................84 Mako U Technical Manual V1.1.3... -
Page 74: Back Panel
Camera interfaces Back panel Connectors naming For control, the camera has in and outputs named as follows: I/Os Opto-isolated in and outputs GPIOs Non-isolated general purpose in and outputs Back panel 6-pin I/O connector Status LED (red) Status LED (green) Fallback switch USB 3.0 Micro-B connector Figure 26: Mako U back panel view... -
Page 75: I/O Connector Pin Assignment
Camera interfaces I/O connector pin assignment The Mako U camera has a 6-pin Hirose input and output (I/O) connector. I/O cable Line Signal <-> Level Description color code GPIO 1 (low) = 0 to 0.8 VDC Non-isolated, White programmable GPIO (high) = 2 to 24 VDC (low) = 0 to 1.0 VDC (high) = 3.3 to 24 VDC @ max. -
Page 76: Opto-Isolated I/Os
Camera interfaces Opto-isolated I/Os The Mako U camera has opto-isolated I/Os: • In 1 • Out 1 Input description External Internal In 1 Pin 3 Isolated GND Pin 5 Figure 27: Opto-isolated input, block diagram The input can be connected directly to the system for voltages up to 24 VDC. An external resistor is not necessary. -
Page 77: Output Description
Camera interfaces Output description Internal External External supply voltage Out 1 Pin 4 Isolated GND Pin 5 Figure 29: Opto-isolated output, block diagram Physical and logical lines A logical high in Vimba is a physical low level due to the open collector output circuit. -
Page 78: Output Levels
Camera interfaces Output levels Parameter Value (low) 0.3 to 2 VDC (high) 3 to 24 VDC Undefined levels 2 to 3 VDC Maximum external output voltage 25 VDC Maximum output current 25 mA Table 31: Opto-isolated output, parameters Output voltage in the On state Output voltage in the On state is 0.3 to 2 VDC @ housing temperature +25 °C. -
Page 79: Output Switching Times
Camera interfaces Output switching times High Opto-isolator signal for output (internal) 100% high ext. supply Opto-isolator output (external) Figure 30: Opto-isolated output, switching times Symbol Description Delay time Fall time Turn-on time Turn-off time Rise time Fall time Table 32: Opto-isolated output, legend for switching times Output timing examples supply 5 VDC... -
Page 80: Non-Isolated, Programmable Gpios
Camera interfaces Non-isolated, programmable GPIOs Notice Avoid damage to the camera, PC, or peripherals by ground loops • Mount the camera electrically isolated to avoid ground loops. • See Ground loops on page 16. GPIOs description The camera has two non-isolated GPIOs that can be configured by software to act as inputs or outputs. -
Page 81: Input Levels
Camera interfaces Logical output signal Vimba output value Voltage level Active High No signal High Table 35: GPIOs as output, physical and logical lines Input levels The GPIOs can be connected directly to the system for voltages up to 24 VDC. An external resistor is not necessary. -
Page 82: Output Levels
Camera interfaces Output levels Parameter Value External output voltage U (low) 0 to 1.0 VDC External output voltage U (high) 3.3 to 24 VDC Undefined levels 1.0 to 3.3 VDC Maximum external output voltage 30 VDC Maximum output current 25 mA Table 37: GPIOs as output, parameters Output voltage in the On state Output voltage in the On state is 0.0 to 1.0 VDC @ housing temperature +25 °C. - Page 83 Camera interfaces Output timing examples supply 5 VDC 1.0 kΩ 0.03 0.03 0.06 0.24 0.54 12 VDC 2.4 kΩ 0.03 0.05 0.08 0.33 0.52 0.85 24 VDC 4.8 kΩ 0.07 0.08 0.15 0.36 0.96 1.32 Table 39: GPIOs as output, timing [µs] For values with other current draw than 5 mA, contact customer support.
-
Page 84: Status Leds
Camera interfaces Status LEDs The Mako U camera has a green and a red status LED. The following tables describe the flashing pattern indicating different events. For some events, only one LED is active at a time, for others, both LEDs are active simultaneously. -
Page 85: Error Conditions
Camera interfaces Error conditions In rare cases the camera may crash and not respond anymore. The LEDs signal another code than described in Table 40 on page 84. Try the following to get the camera back to normal operation: • Restart the camera. •... -
Page 86: Triggering
Triggering This chapter includes: Trigger Control features ............87 Trigger path ................88 Digital I/O Control ..............88 TriggerMode and TriggerActivation ........89 TriggerDelay ................89 Digital I/O lines ..............90 Trigger signal flow ..............92 Best practice rules for triggering .......... 93 Mako U Technical Manual V1.1.3... -
Page 87: Trigger Control Features
With the trigger signal, you can start and control image acquisition. Mako U cameras comply with GenICam Standard Features Naming Convention (SFNC) Version 2.2, including triggering features. This section introduces SFNC trigger features and additional custom Allied Vision features. TriggerSelector The TriggerSelector selects the type of trigger to configure: •... -
Page 88: Trigger Path
Triggering Trigger path External input signal Internal Valid Digital I/O Digital I/O Digital I/O Digital I/O Digital I/O Digital I/O Digital I/O Digital I/O Digital I/O Digital I/O Digital I/O Digital I/O Digital I/O Digital I/O Digital I/O TriggerMode/ TriggerMode/ TriggerMode/ TriggerMode/ TriggerMode/... -
Page 89: Triggermode And Triggeractivation
Triggering TriggerMode and TriggerActivation External input signal Internal Valid Digital I/O Digital I/O Digital I/O Digital I/O Digital I/O Digital I/O Digital I/O Digital I/O Digital I/O Digital I/O Digital I/O Digital I/O Digital I/O Digital I/O Digital I/O TriggerMode/ TriggerMode/ TriggerMode/ TriggerMode/... -
Page 90: Digital I/O Lines
Triggering Digital I/O lines Input path and TriggerSource LineStatus TriggerSource Polarity Selectable via software CounterEventSource Strobe light TimerTrigger Camera Debouncer EncoderSourceA Machine EncoderSourceB Figure 38: Input block diagram TriggerSource[TriggerSelector] specifies the internal signal or physical input line to use as trigger source. To enable a trigger, its TriggerMode[TriggerSelector] must be set to On. -
Page 91: Output Path And Linesource
Triggering Output path and LineSource Output features are configured by software. Any signal can be placed on any output. The main features of the output signals are described below. LineSource Polarity Selectable via Selectable via software software LineStatus ExposureActive TimerActive Strobe light „Output Camera... -
Page 92: Trigger Signal Flow
Triggering Trigger signal flow The following diagram shows the exposure of a frame started by an external signal. High levels show the active state of a signal. Proportions and dependencies are simplified to show the basic signal flow. Signal 1 starts Cycle 1. External signal Cycle 1 Frame 1... -
Page 93: Best Practice Rules For Triggering
Triggering Best practice rules for triggering • Set the trigger to RisingEdge for fastest possible reaction time. • Set the trigger pulse width in the supported range, see Input timing delay and minimum pulse width on page 76. • Consider that the end of exposure triggers the next readout. •... -
Page 94: Image Data Flow
Image data flow This chapter includes the image data flow for Mako U cameras. Mako U Technical Manual V1.1.3... -
Page 95: Mako U Cameras
Image data flow Mako U cameras Camera feature descriptions For a features description, see USB Features Reference at Additional Documents for the Mako U camera: https://www.alliedvision.com/en/support/technical-documentation The following flow chart shows image data processing for Mako U cameras in general. The legend below informs about image processing details for the (numbers) in the flow chart. -
Page 96: Image Corrections For Mako U Cameras
Image corrections for Mako U cameras These image corrections are available for the different Mako U camera models: Camera model ADC bit depth Defect Pixel Correction Fixed Pattern Noise Correction (FPNC) Mako U-029B ✓ ✓ Mako U-051B ✓ ✓ Mako U-130B ✓... -
Page 97: Firmware Recovery
Firmware recovery This chapter includes: Recovering the firmware............98 LED codes for a firmware recovery........99 Mako U Technical Manual V1.1.3... -
Page 98: Recovering The Firmware
Firmware recovery Recovering the firmware You should recover firmware only when the camera cannot be operated properly, even after several restarts. Precautions Keep the camera connected Keep the camera connected while you are executing a firmware recovery. If you disconnect the camera from USB during firmware recovery, the camera firmware may get into a non-functional state. -
Page 99: Led Codes For A Firmware Recovery
Firmware recovery LED codes for a firmware recovery The Mako U camera has a green and a red status LED. The following tables describe the flashing pattern indicating different events. For some events, only one LED is active at a time, for others, both LEDs are active simultaneously. -
Page 100: Cleaning Optical Components
Cleaning optical components This chapter includes: Keep optical components clean.......... 101 Dirt..................102 Examining optical components for dirt ......103 Materials for cleaning optical components ......103 Cleaning instructions ............104 Mako U Technical Manual V1.1.3... -
Page 101: Keep Optical Components Clean
Cleaning optical components Keep optical components clean The best way to ensure the camera remains clean is to avoid penetration of foreign substances into the camera. Always store cameras and lenses with dust caps on. When mounting or dismounting a camera lens or dust cap, always hold the camera with the mount opening pointing downwards. -
Page 102: Dirt
Cleaning optical components Dirt Dirt vs. pixel defects Do not confuse dirt with a pixel defect, which appears as a distinct point. Particles can either rest loosely or can be more or less stuck to the optical surface. Dirt not affecting the image If small visible dust or dirt particles on glass surfaces can be observed from the outside, this does not necessarily mean that these particles affect image quality. -
Page 103: Examining Optical Components For Dirt
Cleaning optical components Examining optical components for dirt Before dismounting the lens, determine whether the dirt is situated on the filter, lens, or sensor. Examination instructions 1. Acquire a uniform image, such as a white sheet of paper. 2. Rotate the optical component. If the dirt spots follows rotation, they are on this component‘s optical surface. -
Page 104: Cleaning Instructions
Cleaning optical components Cleaning instructions Workplace conditions • Carry out all cleaning operations (on lenses, filter or protection glass, and sensor) in a clean dust-free room. • Avoid touching optical components with your fingers or any hard material. Otherwise, they may be damaged. 1. - Page 105 Cleaning optical components 4. If dust spots remain, repeat this procedure once, using new clean lens tissue (as described above). If dust spots remain despite cleaning twice: Contact support@alliedvision.com. Mako U Technical Manual V1.1.3...
-
Page 106: Troubleshooting
Troubleshooting This chapter includes: Questions and answers ............107 Optimizing performance............. 112 Setting the camera to fallback mode........114 Mako U Technical Manual V1.1.3... -
Page 107: Questions And Answers
Troubleshooting Questions and answers This section is about unexpected events with the operation of the Mako U camera. The events are ordered from general to detail: • Camera recognition • Unexpected events • Performance • Radio signal interference Each entry consists of: •... - Page 108 Troubleshooting Check if the USB3 Vision device driver is properly installed and assigned to the Windows camera. Follow the instructions in Instructions in this chapter describe camera installation using Vimba on a Windows system. Vimba supports various Linux distributions, including Vimba for ARM. However, it is impossible to give instructions suitable for Linux systems in this manual.
-
Page 109: Unexpected Events
The camera is intact, but your previous PC and/or cable have/has a defect. Continue with 2. The camera does not work properly. Then: Most likely, the camera has a defect. Please contact Allied Vision support. Connect the camera with the previous cable to the different PC. The camera works properly. Then: Replace the cable. -
Page 110: Performance
Troubleshooting What can I do if the camera crashes when using a third-party camera driver? Check if the camera is operated with a third-party driver causing the crash, the camera cannot be controlled nor stream images. This behavior may happen if: •... -
Page 111: Radio Signal Interference
Troubleshooting Check if all your USB accessories support USB 3.0. USB 3.0 cards, hubs, and cables on page 58 for recommended USB 3.0 accessories. Radio signal interference How can I avoid radio signal interference from wireless devices? Ensure camera installation complies with Electromagnetic Compatibility. Wireless devices and USB 3.0 commonly use 2.4 GHz frequency (WLAN uses 2.4, 3.6, and 4.9 GHz). -
Page 112: Optimizing Performance
Troubleshooting Optimizing performance Dividing bandwidth between devices on a common USB 3.0 bus Increase bandwidth • To obtain maximum bandwidth, attach the camera to a separate bus. Sharing bandwidth with other devices decreases maximum bandwidth for the Mako U camera. •... -
Page 113: Assigning Maximum Bandwidth To A Camera
Troubleshooting Assigning maximum bandwidth to a camera To assign maximum bandwidth to a camera, make sure your camera is the only device on the bus. Consider devices, such as a monitor or a mouse, sharing bandwidth with the USB3 Vision camera connected to the same bus. Delayed data transfer For more demanding applications, using the camera‘s image memory allows high performance acquisition with delayed data transfer to the PC for a limited period... -
Page 114: Setting The Camera To Fallback Mode
Troubleshooting Setting the camera to fallback mode If a firmware recovery fails for any reason (for example, when disconnected during a recovery), the camera firmware may get into a non-functional state. To ensure a successful firmware recovery, follow the instructions below. Notice Use the fallback switch cautiously Slightly press a paper clip into the hole with the fallback switch. -
Page 115: Index
Vimba ..........2 drawings of the camera body ......44 accessories ............57 AcquisitionActive ..........92 electromagnetic interference ......13 Allied Vision contact ..........3 electrostatic discharge (ESD) ......15 exposing (trigger) ..........92 exposure start delay ........92 bandwidth exposure start jitter ........92 cascading hubs ........ - Page 116 S-Mount ............ 62 quantum efficiency ........42 reconfiguration delay .......40 ROI frame rates .........43 quantum efficiency rolling shutter ...........39 Mako U-029B ..........31 specifications ..........41 Mako U-051B ..........33 manual conventions ........10 Mako U-130B ..........36 mechanical dimensions ........44 Mako U-503B ..........42 medical devices ..........14...
- Page 117 Index Mako U-029B ..........31 trigger signal flow ........... 92 Mako U-051B ..........34 TriggerActivation ..........89 Mako U-130B ..........37 TriggerDelay ............ 89 Mako U-503B ..........43 triggering ............86 rolling shutter ..........39 best practice ..........93 delay ............92 Digital I/O Control ........88 safety ...............15...
