- Page 1 Lumos Glow panel 400 Series Lumos Glow panel 400F User manual Ver. 2.5...
-
Page 2: Product Overview
Lumos Glow panel 400 Series Product Overview Optical Characteristics High CRI : 96Ra(Max)@3200K, 95Ra(Max)@5600K Correlated Color Temperature(CCT) : 3200K or 5600K Features Flicker Free Flicker-free lighting DMX 512 channel module control for all functions remotely Dimming Control Smooth digital dimming technology from 100% to 0%... -
Page 3: Proper Usage
Slot for the barn-door Firmware update Lumos Glow panel 400’s new firmware can be updated using USB 2.0 flash drive. (USB format FAT32 type) Copy firmware HEX file (image.hex) to USB flash drive. ( Do not change the file name. And do not put in any folder. If do, the system will not recognize the file.) Turn off the Glow panel 400 and connect the USB flash drive to the USB port on the back of the light. - Page 4 Lumos Glow panel 400 Series Control ① ⑫ ⑩ ⑪ ⑤ ⑥ ⑦ ⑧ ④ ② ③ ⑨ Key functions Print Part names Function names ① USB port Firmware update ② DMX Input DMX IN Input for DMX signal ③...
- Page 5 Lumos Glow panel 400 Series Mode Mode Function Dimming 0~100% control (adjust by 1 / 25%) • Save and load 10 presets • Press the preset button brings up the list of loaded preset and select preset Preset Press and hold down the preset button brings up the list of Saved presets and save...
- Page 6 Lumos Glow panel 400 Series Menu table [1/2] Mode Explanation Dimming knob rotation 1% Dimming (0~100%) ⑨ Dimming knob push 25% Dimming (0~100%) ⑤ Mode button Select mode ⑥ Up button DMX address DMX adress setting (1~512) ⑦ Down button Setting ⑥...
- Page 7 Lumos Glow panel 400 Series Menu table [2/2] Mode Explanation ⑥ Up and Down button both push and hold 3 Scroll to Low dimming setting seconds ⑦ Low dimming setting ⑨ Dimming knob rotation LED index control ⑤ Mode button...
- Page 8 Lumos Glow panel 400 Series Protocol Mode 1 : CCT mode 8 bit (3 Channels per function) Channel Value Percent Function 0~255 0~100 Dimming 0~100% Fan control 0~65 0~25 Fan auto on (LED PCB Temp. 0~39℃ fan off, 40~44℃ fan half on, 45℃~ Fan all on) ...
- Page 9 Lumos Glow panel 400 Series Memo...
- Page 10 Lumos Glow panel 400 Series Memo...
- Page 11 Lumos Glow panel 400 Series Memo...
- Page 12 Lumos Glow panel 400 Series DMLite Co., Ltd. #501, 26, Yangcheon-ro 57-gil, Gangseo-gu, Seoul 07526, Korea Tel +82 2 540 0984 / Fax +82 2 6003 0094 Sales@dmlite.co.kr...
