OWNER'S MANUAL
OUTDOOR GAS FIRE PIT
(
)
BATTERY NOT INCLUDED
Model: PAG-1106FI
IMPORTANT，RETAIN FOR FUTURE REFERENCE:READ CAREFULLY
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
FOR OUTDOOR USE ONLY.NOT FOR COMMERICAL USE
WARNING: If the information in this manual is not
followed exactly,a fire or explosion may result causing
property damage,personal injury,or loss of life.
Follow all warnings and instructions when using the appliance.
If instructions or parts are missing,contact 86-757-23272866

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PAG-1106FI and is the answer not in the manual?

Questions and answers

Related Manuals for Bluegrass Living PAG-1106FI

Summary of Contents for Bluegrass Living PAG-1106FI

  • Page 1 OWNER’S MANUAL OUTDOOR GAS FIRE PIT BATTERY NOT INCLUDED Model: PAG-1106FI IMPORTANT，RETAIN FOR FUTURE REFERENCE:READ CAREFULLY INSTALLER: Leave this manual with the appliance. CONSUMER: Retain this manual for future reference. FOR OUTDOOR USE ONLY.NOT FOR COMMERICAL USE WARNING: If the information in this manual is not followed exactly,a fire or explosion may result causing property damage,personal injury,or loss of life.

  • Page 2: Safety Information

    SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate or install the product. This appliance has been tested to and complies with the ANSI Z21.97-2017, Outdoor Decorative Gas Appliances. When connecting to a fixed piping system, the installation must conform to local codes or the absence of local codes to the National Fuel Gas Code.
  • Page 3 SAFETY INFORMATION WARNING DANGER Certain materials or items, when stored under the fire DANGER indicates an imminently pit, will be subjected to radiant heat and could be hazardous situation which, if not avoided, will result in death or serious seriously damaged. injury.
  • Page 4 SAFETY INFORMATION WARNING WARNING We cannot foresee every use which may be made of Improper installation, adjustment, our fire pit. alteration, service, or maintenance can Check with your local fire safety authority if you have cause property damage, injury, or questions about fire pit use.
  • Page 5 OPERATION CHECKLIST Operation Checklist For a safe and pleasurable heating experience, perform this check before each use. Before Operating: 1. Become familiar with entire owner’s manual and understand all precautions noted. 2. All components are properly assembled, intact and operable. 3.

  • Page 6: Exploded View

    EXPLODED VIEW...

  • Page 7: Part List

    PART LIST PART NO. DESCRIPTION Table top Table base left side panel Table base back panel Table base right side panel Beam Tank shelf and LPG hose fixed ring Door support Door Glass beads 4 kgs Burning system Ice box SCREW PACKAGE PART NO.
  • Page 8 ASSEMBLY INSTRUCTIONS Step 1 ⑤x2 ① ⑤ Step 2 ④x1 ⑤x2 ① ④ ⑤...
  • Page 9 Step 3 ④ x 1 ⑤ x 4 ① ④ ⑤ Step 4 ⑥x2 ① ⑥...
  • Page 10 Step 5 ④x2 ⑤x2 ① ④ ⑤ Step 6 ⑤x3 ① ⑤...
  • Page 11 Step 7 ⑤ x3 ① ⑤ Step 8...
  • Page 12 Step 9 ②x4 ③x4 ② ③ Step 10...
  • Page 13 Step 11 Put the glass beads onto the burner. DO NOT COVER THE WINDGUARD WITH THE BEADS. × √ Step 12 WARNING! The regulator and hose must go through the safety ring when install the gas tank...
  • Page 14 Step 13 Step 14...
  • Page 15 Step 15 Step 16...

  • Page 16: Installing Lp Gas Tank

    INSTALLING LP GAS TANK Connect LP Gas Tank Before connecting, be sure that there is no debris caught in the head of the LP gas tank, head of the regulator valve or in the head of the burner and burner ports. LP GAS Connect regulator/hose assembly to tank by turning knob clockwise stops.

  • Page 17: Leak Testing

    LEAK TESTING WARNING: Before using this outdoor fire pit, make sure you have read, understand, and follow all information provided in the Dangers and Warnings. Failure to follow those instructions can cause death, serious injury or property damage. WARNING Never use your fire pit without leak testing all gas connections, hoses and propane tank. DANGER To prevent fire or explosion hazard: ♦...

  • Page 18: Battery Installation

    BATTERY INSTALLATION 1xAAA Battery (Battery not included) Put correct Battery in before use. STORAGE FOR TABLE COVER Step 1...
  • Page 19 Step2 Step3...

  • Page 20: Lighting Instructions

    LIGHTING INSTRUCTIONS Caution: Keep outdoor gas cooking appliance area clear and free from combustible materials, gasoline and other flammable vapors and liquids. Caution: Do not obstruct the flow of combustion and ventilation air. Caution: Check and clean burner/venturi tubes for insects and insect nests. A clogged tube can lead to a fire beneath the grill.

  • Page 21: Troubleshooting

    TROUBLESHOOTING PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION Propane cylinder is empty Replace propane cylinder Burner will not light Blockage in orifice Clear blockage Control knob is not in ON position Turn control knob to ON Turn cylinder valve OFF and fill the Gas pressure is low cylinder Outdoor temperature is less than 40ºF and...

  • Page 22: Care And Maintenance

    CARE AND MAINTENANCE CAUTION: All cleaning and maintenance should be done when fire pit is cool and with the fuel supply disconnected. 1. DO NOT clean any outdoor fire pit part in a self-cleaning oven. The extreme heat will damage the finish. 2.
