- Page 1 ASSEMBLY INSTRUCTIONS COASTER FINE FURNITURE Fine Furniture for every stage of life 601712 GLIDER LOVESEAT WITH CONSOLE REVISION 0: 12/12/2019 05/07/2020 COASTERFURNITURE.COM PAGE 1 OF 4...
- Page 2 601712 ITEM : ASSEMBLY INSTRUCTIONS ASSEMBLY TIPS: 1.Remove hardware from box and sort by size. 2.Please check to see that all hardware and parts are present prior to start of assembly. 3.Please follow attached instruction in the same sequence as numbered to assure fast & easy assembly.
- Page 3 601712 ITEM : ASSEMBLY INSTRUCTIONS STEP 1 STEP 2 STEP 3 PAGE 3 OF 4...
- Page 4 STEP 4 AW:254mm(10") BH:559mm(22") SW:1422mm(56") H:1067mm(42") AH:660mm(26") SH:508mm(20") SD:533mm(21") W:1981mm(78") D:1016mm(40") D:1715mm(67.5") 140° H:432mm(17") H:813mm(32") NOTE:Dimension tolerance ± 5% PAGE 4 OF 4 COASTERFURNITURE.COM...
