Air King Exhaust Fan AK110PN AK110PN Specifications

100 CFM/1.5 SONES @ 0.10" wg. • 90 CFM/1.5 SONES @ 0.25 wg.
• Grill
White, polymeric grill secured in place with torsion springs;
easily removed if necessary, dimensions - 11" x 13
• Blower Wheel
Balanced polymeric dual inlet blower wheel 5
depth, 30 paddles, secured in place using 8M hex nut.
• Motor
Enclosed 4 pole electronically balanced permanently split
capacitor motor (PSC); life time lubricated. Motor bearings -
ball. Suitable for continuous operation. Rated 115/120 volts, 60
Hz, 0.31 amps.
• Fan Housing
23 gauge galvanized steel housing, fully sealed.
Overall dimensions 10
• Duct Collar
4" round, zinc plated metal collar adapter. 4" spring loaded
aluminum backdraft damper.
• Ventilating Area
For bathrooms up to 100 sq. ft. For other rooms up to 125 sq. ft.
• Electrical Connections
1 / 2 " electrical knockouts provided. Easy wiring access via either
internal or external wiring compartment cover.
Air Flow - CFM 104
PROJECT
LOCATION
CONTRACTOR
FAN MODEL
CFM
NUMBER NUMBER
C US
Specifications subject to change without notice.
HVI CERTIFIED 120 Volts, 0.31 amps, 60 hz.
3 / 4
13 /32 " dia. x 4"
7 / 8 " x 9 3 / 8 " x 7 7 / 8 ".
Static Pressure (inches of w.g.)
0 0.05 0.1 0.125
102 100 99
IN
RPM WATTS
W.G.
".
7 7 / 8
Acceptable for use over tub or shower when
installed in a GFCI protected branch circuit.
• Unit Mounting
The housing will mount in ceilings with at least 8" of clearance
and through drywall thickness up to
of 11 1 / 8 " x 9 5 / 8
will mount either between 16" or 24" on center joists, using the
4 supplied housing mounting rails. The housing mounting rails
can be adapted for overhead mounting (hardware not provided).
• Single Pack Shipping Info
Box Dim: 14
UPC: 0-8316221012-7
Shipping Weight: 11.5 lbs.

PERFORMANCE

0.15 0.2 0.25
98 95 90
ARCHITECT
ENGINEER
SUBMITTED BY
AMPS SONES QTY
U.S.: 820 Lincoln Drive
West Chester, Pennsylvania 19380-4466
Tel: (877)-304-3785
Fax: (610) 696-8048

SPECIFICATIONS

AK110PN
EXHAUST FANS
9 "
3 / 8 10 7 / 8 "
"
13 3 / 4 " 11"
CUL/HVI
3 / 4 ", with a rough-in opening
". Rated for ceilings insulated to R-40. The housing
1 / 8 " x 11 5 / 8 " x 9 5 / 8 "
HVI Sones Fan Speed
@ .1 SP
0.3
71 1.5
DATE
OPTIONAL EQUIPMENT
& REMARKS
Canada: 110 Glidden Road
Brampton, Ontario L6T 2J3
Tel: (905) 456-2033
Fax: (905) 456-1015
4"
Power
RPM Watts
1106 29
Updated 6-06
