In case the need for Servicing arises
Don't hesitate to call any nearby AS center
with your name, address and telephone number
when anything wrong with your product occurs.
ELECTRONICS
AH68-10334G

Advertisement

Table of Contents
loading

Related Manuals for Samsung Z-48Q

Summary of Contents for Samsung Z-48Q

  • Page 1 Z-48Q-1 5/13/03 13:44 Page 1-2 In case the need for Servicing arises Don't hesitate to call any nearby AS center with your name, address and telephone number when anything wrong with your product occurs. ELECTRONICS AH68-10334G...
  • Page 2 Z-48Q-1 5/13/03 13:44 Page 1-3 OWNER'S INSTRUCTIONS Z-48Q VIDEO-CD CD PLAYER Before operating the unit, please read this manual thoroughly, and retain for future reference. +10/0 COMPACT COMPACT DIGITAL VIDEO DIGITAL AUDIO This player does not apply to business use and CD-ROM/CD graphic discs cannot be played with this player.

  • Page 3: Safety Precautions

    Z-48Q-1 5/13/03 13:44 Page 2 SAFETY PRECAUTIONS SAFETY PRECAU- CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE TOP COVER, NO USER SERVICEABLE PARTS INSIDE, REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

  • Page 4: Table Of Contents

    Z-48Q-1 5/13/03 13:44 Page 3 SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS • Do not damage the power cord. Damage to the power cord may cause a fire or shock hazard. • When unplugging the power cord, please hold by the plug and remove it carefully in standby mode.
  • Page 5 Z-48Q-1 5/13/03 13:44 Page 4 SAFETY INSTRUCTIONS READ INSTRUCTIONS • All the safety and operating instructions should be read before the appliance is operated. RETAIN INSTRUCTIONS • The safety and operating instructions should be retained for future reference. HEED WARNINGS •...
  • Page 6 Z-48Q-1 5/13/03 13:44 Page 5 OUTDOOR ANTENNA GROUNDING • If an outside antenna is connected to the antenna terminal, be sure the antenna system is grounded so as to provide some protection against voltage surges and built-up static charges. •...

  • Page 7: Controls And Components

    Z-48Q-1 5/13/03 13:44 Page 6 CONTROLS AND COMPONENTS FRONT PANEL 1. DIGIT buttons 2. SELECT(PLAY/PAUSE) button 3. RETURN(STOP) button 4. OPEN/CLOSE button 5. POWER button 6. DIGITAL ECHO VOLUME knob +10/0 10 9 7. MIC jacks 8. MIC VOLUME knob 9.
  • Page 8 Z-48Q-1 5/13/03 13:44 Page 7 CONTROLS AND COMPONENTS REAR PANEL 1. VIDEO OUTPUT -Connect to the VIDEO IN of your TV set. 2. AUDIO OUTPUT (AMP) - Connect to the AUDIO IN of your STEREO AMPLIFIER. ACCESSORIES REMOTE CONTROL 3. AUDIO OUTPUT (TV) -Connect to the AUDIO IN of your TV set.

  • Page 9: Remote Control

    Z-48Q-1 5/13/03 13:44 Page 8 REMOTE CONTROL POWER PROGRAM SOUND REPEAT SLOW PAL/NTSC AI SLEEP DISC VIEW ZOOM SELECT PREV NEXT TIME SEARCH STOP TO INSERT BATTERIES Open the battery compartment cover. +10/0 Install two "AAA" batteries observing the correct polarity as shown in compartment.

  • Page 10: System Connections

    Z-48Q-1 5/13/03 13:44 Page 9 SYSTEM CONNECTIONS VCD AND CDP + TV 1. Connect AUDIO OUT jack of the VCD and CDP to AUDIO IN jack of the TV. 2. Connect VIDEO OUT jack of the VCD and CDP to VIDEO IN jack of the TV.

  • Page 11: Video-Cd Playback

    Z-48Q-1 5/13/03 13:44 Page 10 VIDEO-CD PLAYBACK HOW TO PLAYBACK VIDEO-CD version 2.0 • Turn on the POWER button. Press the OPEN/CLOSE button. • The tray is ejected. Insert a VIDEO-CD disc and press the OPEN/CLOSE button. Press the SELECT (PLAY/PAUSE) button.
  • Page 12 Z-48Q-1 5/13/03 13:44 Page 11 SLOW MOTION Press the SLOW button on the remote control when the play function is on -Voices do not come out when the SLOW MOTION button is pressed -Slow playing is 1/2 of the normal playing speed at 1st press.

  • Page 13: Disc View Function

    Z-48Q-2 5/13/03 13:42 Page 12 DISC VIEW FUNCTION • Desired music or video display can be used directly without by menu functions (VER 2.0 Mode). This function is possible in Ver 1.1 and Ver 2.0 menu off mode. TRACK VIEW •...

  • Page 14: Repeat Function

    Z-48Q-2 5/13/03 13:42 Page 13 INDEX VIEW • This function acts as displaying the track in playing sequently by time and so it's convenient for searching desired video. Press the PLAY button to playback. SELECT Press the DISC VIEW button.

  • Page 15: Program Function

    Z-48Q-2 5/13/03 13:42 Page 14 PROGRAM FUNCTION This function can program up to 30 tracks during STOP mode. • ex) To program No.4 track of No.2 disc Press the PROGRAM button. PROGRAM PROGRAM P : 01 00 PROGRAM Press the track number to be programmed.

  • Page 16: Zoom Function

    Z-48Q-2 5/13/03 13:42 Page 15 ZOOM FUNCTION This function works only in the VCD play mode. • Press the DISC VIEW/ZOOM key for 1 sec or longer to change the screen to 2 x ZOOM. While in the 2 x ZOOM screen, press the DISC VIEW/ZOOM key for 1 sec or longer again to change the screen to 4 x ZOOM.

  • Page 17: Searching Functions

    Z-48Q-2 5/13/03 13:42 Page 16 SEARCHING FUNCTIONS Turn on the TV. • Load and play the disc. • HIGH SPEED SEARCH • This function is used to searching disc for desired location. Press and hold down the Search button during the play.
  • Page 18 Z-48Q-2 5/13/03 13:42 Page 17 TIME SEARCH Press the TIME button. Time 02 : 23 TIME 00 : 00 SEARCH Enter the time by pressing the DIGIT button. Time 02 : 23 12 : 34 Press the SELECT SELECT NOTE 1.

  • Page 19: Karaoke Function

    Z-48Q-2 5/13/03 13:42 Page 18 KARAOKE FUNCTION • Turn on the TV. • Load and play a disc. Connect the MIC. • The key control will be displayed on the screen. KEY # Load a disc and select a desired track.
  • Page 20 Z-48Q-2 5/13/03 13:42 Page 19 Adjust the DIGITAL ECHO. - This will add an echo to your voice, giving you the feeling of singing on stage, Adjust it as desired. DIGITAL ECHO To decrease echo effect (SET) To decrease or increase the volume of the Microphone: •...

  • Page 21: Trouble Shooting

    Z-48Q-2 5/13/03 13:42 Page 20 TROUBLE SHOOTING SYMPTOM Tray is not ejected. The unit does not play Tray is ejected. Video or audio is muted, or tray is ejected after 2-5 seconds. Picture appears late when SELECT(PLAY/PAUSE) button is pressed.

  • Page 22: When Video Is Displayed Through Set

    Z-48Q-2 5/13/03 13:42 Page 21 WHEN VIDEO IS DISPLAYED THROUGH SET -Source : VIDEO-CD DISC -Display :TV monitor * Color or sync is in trouble according to TV set. GENERAL INFORMATION ABOUT THE DISC GENERAL INFORMATION ABOUT THE DISC Compact Disc Digital Audio (Max.

  • Page 23: Specifications

    Z-48Q-2 5/13/03 13:42 Page 22 CARE OF PLAYER AND DISCS Cleaning the Player - Use soft cloth or the dusting attachment of your vacuum cleaner to dust the exposed surface of the player. Use the vacuum cleaner attachment to remove dust from the ventilation holes on the top, back, sides, and bottom of the cabinet.
