  • Page 1 CORDLESS ANGLE GRINDER HM20V ORIGINAL INSTRUCTIONS...
  • Page 2 Warning: Please read the manual carefully before using the unit! INSTRUCTIONS OF SECURITY WARNING Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term "power tool" in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
  • Page 3 4) Power tool use and care a) Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed. b) Do not use the power tool if the switch does not turn it on and off.
  • Page 4 e) The outside diameter and the thickness of your accessory must be within the capacity rating of your power tool. Incorrectly sized accessories cannot be adequately guarded or controlled. Threaded mounting of accessories must match the grinder spindle thread. For accessories mounted by flanges, the arbour hole of the accessory must fit the locating diameter of the flange.
  • Page 5 a) Maintain a firm grip on the power tool and position your body and arm to allow you to resist kickback forces. Always use auxiliary handle, if provided, for maximum control over kickback or torque reaction during start-up. The operator can control torque reactions or kickback forces, if proper precautions are taken.
  • Page 6 Use extra caution when making a “pocket cut” into existing walls or other blind areas. The protruding wheel may cut gas or water pipes, electrical wiring or objects that can cause kickback. Additional safety warnings: a) Check that the maximum speed indicated on the grinding disc corresponds to the maximum speed of the machine.
  • Page 7 2. THE PRODUCT a. Description 1. Hand grip 2. Li-on Battery 3. wrench for disk installation 4. Side handle 5. Guard 6. Backing washer 7. Disc clamping nut 8. guard clamp lever 9. ON/OFF trigger with safety latch 10. Spindle lock 11.
  • Page 8 Technical data Model HM20V Voltage 20V dc. Rated speed in revolution per 10000/min minute Rated capacity in mm Ø125mm Spindle thread size Sound pressure level Lpa 88 dB(A), K=3 dB(A) Sound power level Lwa 99 dB(A) , K=3 dB(A) Vibration value 4.9 m/s...

  • Page 9: Operation

    3. OPERATION NOTE: Supplied without battery or charger...
  • Page 10 a. Charging (Attention: Charger and battery not included in this model) 1) Take the battery pack out of the equipment. Do this by pressing the push lock button. 2) Check that your mains voltage is the same as that marked on the rating plate of the battery charger.
  • Page 11 Charger indicator Indicator status Explanations and actions Ready for use The charger is connected to the mains and is ready for use; there is no battery pack in the charger. Charging The charger is charging the battery pack in charge mode. Battery pack is full of charge.
  • Page 12 Removing the disc clamping nut Depress the spindle lock button (fig 10). Use a wrench, insert the pins into the holes on the disc clamping nut. Turn the wrench anticlockwise to release the disc clamping nut. If the disc backing washer is removed it must be replaced the correct way round. The correct way to fit this onto the shaft can be seen in Fig 11.

  • Page 13: Maintenance And Storage

    e. Grinding Secure all work before beginning any operation. Secure small workpiece in a vise or clamp to a workbench. They key to efficient operation is controlling the pressure and surface contact between the grinding wheel and workpiece. Always hold the tool firmly with one hand on housing and the other on the side handle. Turn the tool on and then apply the disc to the workpiece.
  • Page 14 ZI, 32 RUE ARISTIDE BERGES – 312070 CUGNAUX – FRANCE Declares that the machinery designated below: CORDLESS ANGLE GRINDER Model: HM20V Serial number: 20200816205-20200816504 Is in conformity with the requirements of the Directive Machine 2006/42/EC and to the followings Europeans Directives:...

  • Page 15: Warranty

    7. WARRANTY WARRANTY The manufacturer guarantees the product against defects in material and workmanship for a period of 2 years from the date of the original purchase. The warranty only applies if the product is for household use. The warranty does not cover breakdowns due to normal wear and tear. The manufacturer agrees to replace parts identified as defective by the designated distributor.

  • Page 16: Product Failure

    8. PRODUCT FAILURE WHAT TO DO IF MY MACHINE BREAKS DOWN? If you bought your product in a store: a) Empty the fuel tank. b) Make sure that your machine is complete with all accessories supplied, and clean! If this is not the case, the repairer will refuse the machine.

  • Page 17: Warranty Exclusions

    9. WARRANTY EXCLUSIONS THE WARRANTY DOES NOT COVER: • Start-up and setting up of the product. • Damage resulting from normal wear and tear of the product. • Damage resulting from improper use of the product. • Damage resulting from assembly or start-up not in accordance with the user manual. •...
