Dear Customers Thanks for purchasing this TFT-LCD TV/Monitor. We strongly recommend that you carefully read the safety and operation instructions before operating your TV/Monitor. FOLLOW INSTRUCTIONS AND HEED ALL WARNINGS on your TFT-LCD TV/Monitor and in this manual. Safety information __________________________________________________ Note: Before connecting the AC power cord to the DC adapter outlet, make sure...
To reduce the risk of fire or electric shock, and annoying interference, use the recommended accessories only. Precautions ________________________________________________________ Please read the below precautions carefully before operating the unit. Power cord protection: Never use your LCD TV/Monitor if the power cord has been damaged. Do not put anything on the power cord, and keep the power cord away from where people can easily trip over it.
Page 4
Keep away from water/magnetic fields: Do not expose the LCD TV/Monitor to rain or use it near water source. If the LCD TV/Monitor got wet, unplug it and contact an authorized dealer immediately. Do not clean the front panel with Ketone-type materials, ethyl alcohol, toluene, acid, methyl, or chloride since they may cause damage on panel.
Page 5
performs safety checks to certify that the TFT LCD TV/Monitor is in safe operating order. Unpacking ____________________________________________ Please make sure that the following items are included with your LCD TV/Monitor. If any item is missing, please contact your dealer. TFT LCD TV/ Monitor Remote control Operation manual DC adapter...
View of the monitor Side view Front view Back view Remote sensor 12. VGA jack Power indication light 13. SCART jack Headphone jack 14. S-video jack CH+/up direction button 15. Video in jack CH-/down direction button 16. Audio in (left) jack...
Page 7
VOL up/RIGHT direction button 17. Audio in (right) jack VOL down/LEFT direction button 18. TVRF jack Menu button 19. DVD Play/Pause button TV/AV button (Function switch button) 20. DVD Stop playing button 10. Power button 21. DVD open/close button 11. DC input jack/ Car Cord input jack 22.
Page 8
25. TITLE/PBC button 26. SLOW PLAY button 27. Direction button (Right) 28. REPEAT A-B button 29. REPEAT button 30. DVD skip backward 31. DVD skip forward 32. DVD PAUSE/STEP button ● TELETEXT BUTTONS (If TV has teletext function. You may enjoy it by using these buttons) Name Function Name...
Caution: 1. Keep the battery out of children’s reach. 2. Don’t attempt to recharge, short-circuit, disassemble, heat or throw the batteries into the fire. 3. Always replace both batteries at the same time. Never mix new and old batteries or batteries of a different type. 4.
Page 10
Connect the TVRF source with the antenna port. TVRF signal including: Receiving antenna /satellite TV/CATV net. You can use 75Ω coaxial cable to connect the outdoor antenna. Outdoor Antenna Connection: Use 75Ωcoaxial cable plug or 300-75Ωimpedance converter to plug in antenna input terminal on the rear of the cabinet. VHF antenna UHF antenna Input terminal of...
Page 11
IV. TV/Monitor screen operation (1) Basic operation Press the POWER button on the unit or the STANDBY button on the remote control to switch on the power, the indication light will be in blue color . Press the POWER or STANDBY button again to switch off the power, and the light will be in red color.
Page 12
Press the MUTE button to cut off the sound output, then the screen will show “ “ mark , press this button again to resume sound output.. Press the DISPLAY button to display the preset channel mode. (3) View the AV signal sources (DVD/VCR/CAMCORDER) Press the TV/AV button on the remote control, there will be a menu displayed on the screen as followed: Select the suitable input to pickup the AV signal.
page; use the 0-9 numerical buttons and the -/- - button to enter into a numerous page. Refer to the chapter of ‘Remote control reference guide’ to grasp other functions of the TELETEXT buttons. (5) PC screen Press the TV/AV button to select the VGA input (TV into PC) mode. The will be a ‘PC’...
Page 14
respectively from 0~100. Note: Only the the item of Brightness and Contrast could be operated in the PC signal source. After setting, press the MENU button to return to the root menu or exit the setting SOUND SETTING Press the MENU button on the remote control, and then press the P- button to select the Sound setting, the Menu will be shown as below: On this menu, the Audio setting icon of is in red frame.
Page 15
CHANNEL SETTING( FOR TV SIGNAL SOURCE ONLY) Press the MENU button on the remote control, and then press the P- button to select the Channel setting, the Menu will be shown as below: On this menu, the Channelsetting icon of is in red frame.
Page 16
Press the P+ or P- button to move cursor to Search, and press V- or V+ button to search TV signal .At last press the P+ or P- button to move cursor to store, and press MENU button to save your selected channel. (3) .Fine Tune Select the ‘Fine Tune’...
Page 17
On this menu, the Channel setting icon of is in red frame. (1).Language Use the V+ button firstly, the cursor will be on the line of “Language English ”. And then, press the V+ or V - button repeatedly to select the language you need (2).Blue Back Move the cursor to the line of “Blue Back...
Page 18
Press the V+ or V - button repeatly, you could select User, Normal, Warm or Cool according to your request. Note: Only the item of User-R , User-G or User-B could be adjusted from 0 ~100 in the Color Temp User (5).DNR Press the V+ or V - button repeatly, you could select Strong, Normal or...
On this menu, the Channel setting icon of is in red frame. You can use the P- or P+ button to select the item of Clock, Phase,H- Position or V-Position. And then use the V- or V+ button to adjust the value of each item respectively from 0~100.
Page 20
Some slight picture noise and some sounds are produced when the disc is loading, unloading and during playback, this is normal and can be ignored. HOW TO SELECT THE TRACK If you want to play the second track or chapter, please press the number button “2”...
b. SLOW PLAY Press SLOW PLAY button when playing, you can play the disc at 1/2, 1/4, 1/8, 1/16 of the normal speed. If you want to stop it, you can press ENTER/PLAY button to play normally again. c. ZOOM PICTURE This DVD video player allows you to zoom in/ out a picture as well as shift the zoom point.
the picture will become still on the screen. By pressing this button again and again, the picture will advance picture by picture (frame by frame). To return to normal play, press the ENTER/PLAY button. Please note that the sound is cut off, and the picture becomes silent while playing in this mode. f.
Page 23
HOW TO SET TITLES, CHAPTERS, OR TRACKS IN A FAVORITE ORDER The program playback function will automatically playback titles, chapters or tracks in the order preprogrammed. Insert a disc, press the PROG button, and the menu will display on TV, as the following: Program : TT(- -)/CH(- -) 01 TT: CH: 06 TT: CH:...
The angle function will not work on DVD video discs that do not contain recorded multiple angles. During still playback, you are able to change the camera angle. However, when you resume to normal playback, the camera angle changes to the new settings. ...
Page 25
Press the ENTER/PLAY button to play the MP3 file. Press during playback to skip the tracks. If you need to return to the main directory (folder), press STOP. NOTE: The left column on the TV screen is a list showing the name of the folder.
Page 26
AUDIO SETUP You could choose AUDIO OUT mode as SPEAKER SETUP, AUDIO SETUP, could setup to get the best sound as followed: PREFERENCE PAGE SETUP You could choose PREFERENCE PAGE mode as followed menu. Note: Preference Page Setup fun. is only useful to set as followed status: a.
VII. Other Operation a. Earphone operation This unit possesses earphone jack. Connect the earphone with the socket and adjust the volume to what you want. Once plugged in, the speaker output will be cut off automatically. b. AUDIO effect Press the AUDIO/ST/D/I/II button on the remote control frequently to select Mono Left, Mono Right , Mix-Mono or Stereo effect.
Page 29
Symptom Remedy 1. Check whether the power plug is connected to the power supply. No power 2. Pull out the plug and wait for 60 seconds, and then insert the power plug again and switch on the TV/monitor. Check whether the antenna is connected properly. Adjust to another channel.
Page 30
IX. Notes Please read these operating instructions carefully before you operate this unit. When you want to cut off the electricity supply of the whole unit’s power, please press the POWER button on the unit. And take out the plug from wall outlet. Don’t press any button if you are not using the unit.
X. Maintenance 1). Cleaning the cabinet Use a soft cloth slightly moistened with a mild detergent solution. Do not use a solution containing alcohol, spirits, ammonia or abrasives. 2). Cleaning discs When a disc becomes dirty, clean it with a cleaning cloth. Wipe the disc from the centre outwards.
XI. Specifications Screen size, visible 19 inch Screen format 16:10 Resolution 1440 * 900 Minimum contrast ratio 850:1 Minimum brightness 300 cd/m² Display colors 16.2M Minimum viewing angle 170° (horizontal) / 160° (vertical) Maximum response Time 5 ms Minimum lifetime background 50,000 hours light Video color systems...
Page 33
800x600(SVGA) 47.2 800x600(SVGA) 46.9 1024x768(XGA) 48.4 1024x768(XGA) 56.5 1024x768(XGA) 60.0 1280x1024(SXGA) 63.5 1280x1024(SXGA) 80.0 Modes, which are not listed in the above table, may not be supported. For an optimal picture it is recommended to choose a mode listed in the table.
Page 34
dispose off these types of appliances by depositing in a “recycling plant” or at a collection point for the recycling plant so that its electrical and electronic parts can be recycled. The selective collection and recycling of the harmful residues of electric and electronic home appliances and parts at the time its disposal will contribute towards the conservation of our natural resources and will guarantee that it will be recycled in a manner most beneficial to the environment and public health.
