- Page 1 P1210 Pellet stoves UseR MANUAl MADE IN ITALY design & production eNGlIsH/INGlese...
-
Page 3: Table Of Contents
PeLLets and feeding ................................14 instaLLation With side exhaust PiPe ..........................15 ducting ....................................17 identification of the coMPonents in the 1210 ducted stove................18 technical data p1210 ......................................19 oPerator interface ................................20 command console seGment ....................................21 user Menu....................................22 menu 01 - adjust blowers ....................................22 menu 02 - set clock ........................................22... -
Page 4: Warnings
Warnings This instructions manual is an integral part of the product: make sure that it always accompanies the appliance, even if transferred to another owner or user, or if transferred to another place. If it is damaged or lost, request another copy from the area technician. -
Page 5: Safety Devices
| eNgliSH Safety deviceS teRMS aNd defiNitiONS aeration: Air renewal is required both for the disposal of Safety deviceS the combustion products, and to prevent mixtures with a hazardous content of non-combusted gases. Key: * = present, - = not present closed hearth appliance: Appliance designed for operation with closed combustion chamber. -
Page 6: General
| eNgliSH fUNctiONal OPeRatiONS diagRaM state of the art installation and proper system operation include a series of activities: 1. Preliminary activities: Š verification of the suitability of the installation site, Š verification of the suitability of the fumes exhaust system, Š... -
Page 7: Installation
| eNgliSH iNStallatiON Installation in premises with fire hazards is forbidden. Installation in residential premises (except for sealed operation appliances) is also forbidden: Š in which there are liquid fuel-operated appliances with continuous or intermittent operation, which draw the combustion air in the room in which they are installed, or Š... -
Page 8: Fumes Exhaust System
| eNgliSH veNtilatiON aNd aeRatiON Of tHe iNStallatiON PReMiSeS Ventilation is deemed sufficient when the room is equipped with air inlets according to the table: air inlet see figure 2 Percentage of the net opening section with Minimum net opening value of Appliance categories Reference standard respect to the appliance fumes... -
Page 9: Smoke Duct
| eNgliSH Š nominal diameter; Š distance from combustible materials, indicated in millimetres, followed by the arrow and flame symbol; Š installer data and date of installation. every time one must cross combustible materials, the following indications must be complied with: SyMbOl deScRiPtiON qUOta[MM]... - Page 10 | eNgliSH Š counter-slope sections are not allowed; Š the smoke ducts must have, along their entire length, a diameter that is no less than that of the attachment of the appliance exhaust pipe; any section changes are allowed only on the inlet to the chimney; Š...
-
Page 11: Chimney
| eNgliSH exaMPleS Of cORRect cONNectiON tO tHe cHiMNey protection from rain protection from rain and wind and wind steel plate, airtight Max 3 mt 3 - 5% Insulated "t" fitting with inspection plug "t" fitting with "t" fitting with inspection plug inspection plug... -
Page 12: Fumes Exhaust System Product Requirements
| eNgliSH cOMbUStiON PROdUctS OUtlet qUOta the outlet quota is determined by measuring the minimum height between the roof covering and the lower point of the fumes expulsion section into the atmosphere; this quota must be outside the reflux area and at an adequate distance from obstacles which hinder or make the expulsion of the combustion products difficult or from openings or accessible areas. -
Page 13: Technical Installation Documentation
| eNgliSH coverings and finishings the coverings and finishings must only be applied after having verified the proper operation of the appliance according to the indicated modalities tecHNical iNStallatiON dOcUMeNtatiON When installation is complete, the installer must provide the owner or person acting for him, according to the legislation in force, with the declaration of conformity, supplied with: 1) the use and maintenance manual of the appliance and of the system components (such as for example, the smoke ducts, chimney, etc.);... -
Page 14: Pellets And Feeding
Š en Plus - uni en 16961 - 2 class a1 or a2 Š Ö-norm m 7135 Š din Plus 51731 Opera recommends using pellets with a diameter of 6mm with its products. Pellet storage To guarantee combustion without problems, the pellets must be kept in a dry place. -
Page 15: Installation With Side Exhaust Pipe
InstallatIon wIth sIde exhaust pIpe Tools needed: Š 7 mm hex key, either socket or regular Š 5 mm Allen key Dismantle the left side and remove the split sheet. With the 7mm socket key, unscrew the 3 mounting screws from the mesh on the back of the stove structure. - Page 16 Move the smoke extractor With the Allen key, remove the grub screw from the hole as shown in the figure Move the grub screw that was just removed to the hole indicated in the figure Turn the volute to the side exhaust position Re-assemble the stove in reverse order from step 5 through 1 above.
-
Page 17: Ducting
All adjustment, inspection and cleaning activities must be performed by qualified staff. In the P1210 DUCTED stove, there is the dual possibility to use an air flow on the back of the stove that can be ducted and transported to another room. -
Page 18: Identification Of The Components In The 1210 Ducted Stove
IdentIFIcatIon oF the coMponents In the 1210 ducted stove. The 1210 DUCTED stove is comprised of: A. Display B. Pellet hopper cover C. Door D. Handle E. Fire pot F. Scrapers for cleaning heat exchangers G. Main starter switch H. Power socket for electric cable I. -
Page 19: Technical Data P1210
Thermal power 12.4 Nominal Thermal power Thermal power Reduced Thermal power 89.4 Nominal Yield Thermal power 87.4 Reduced Thermal power 213.0 Nominal Exhaust gas temperature °C Thermal power Reduced Thermal power 7.55 Nominal Mass flow of fumes Thermal power 6.36... -
Page 20: Operator Interface
operator InterFace Control panel DISPLAYING THE vARIOUS SETTINGS OPERATING POWER TExT MESSAGES TEMPERATURE ADJUSTMENTS TO ACCESS BUTTON THE MENU ON/OFF controlled FunctIons 1 Increase - rooM teMperature This button allows you to increase the temperature from 7° to 40°. When changing the user parameters, it allows you to increase the value shown on the display. 2 decrease - rooM teMperature This button allows you to decrease the temperature from 40°... -
Page 21: Command Console Segment
coMMand console segMent chrono IgnIter auger Flue gas exhaust heat exchanger not used The Figure to the side gives the meaning of the activation signals for each part of the stove. alarM When the mark is enabled near the symbol on the LCD monitor, it signals the ignition of the component(s): MaIn Menu Increase or decrease the speed of the duct blower. -
Page 22: User Menu
user Menu Menu 01 - adJust Blowers - not used. MENU LEVEL Figure 4.3 SET BLOWER 2 SET BLOWER 3 DIALOGUE Menu 02 - set clocK Set the current date and time. The board has a Lithium battery that gives the internal clock 3-5 years autonomy. Table 3 Menu 2 - Set Clock shows the diagram of levels and the value to enter to correctly set the clock. -
Page 23: Menu 03 - Set Chrono
Table 3 Description sub-menu state SET CLOCK suB-Menu set clocK level 1 level 2 level 3 level 4 02 SET CLOCK DAY OF THE WEEK HOURS TIME MINUTES MINUTE MONTH YEAR Menu 03 - set chrono This allows you to globally enable or disable all of the functions of the timed thermostat. The sub-menus shown in Table 4 are used to perform all of the adjustments for: •... - Page 24 Table 4 Description sub-menu state SET CHRONO suB-Menu set chrono level 1 level 2 level 3 level 4 03 - WEEKLYPROGRAM 01-WEEKLY CHRONO ON/OFF (FIRST IGNITION) 02-START PROG.1 TIME 03-STOP PROG 1 TIME 04- MONDAY PROG 1 ON/OFF 05-TUESDAY PROG 1 ON/OFF 06-WEDNESDAY PROG 1 ON/OFF...
-
Page 25: Menu 04 - Set Language
IMportant When programming the timer, be careful not to overlap ignition and shut-down times. At any level, if a button is not pressed within 5 seconds the display will automatically return to the main menu. If you wish to return to the main menu, there is no need to use any of the buttons, just wait 5 seconds. Suggestions for programming the Timed thermostat: In order to avoid confusion and unwanted shut-down operations, only activate one program at a time unless you know exactly what you wish to achieve. -
Page 26: Menu 09 - Pellet Type
Menu 09 - pellet tYpe Allows you to display and modify the combustion calibration parameter. If the stove has operating problems due to the quantity of pellets, you can adjust the pellet load directly from the control panel. Problems related to fuel quantity can be divided into 2 categories: Fuel shortage: the stove never manages to develop an adequate flame, tending to remain very low even at high power. -
Page 27: Commissioning
coMMIssIonIng Electrical connection The stove is equipped with a power cable which must be connected to the socket located in the back of the stove and then plugged into a 230 v - 50 Hz earthed outlet. The proper voltage is 230 v - 50 Hz. Only use the cable that is provided with the stove. -
Page 28: Use
NOTE When reading this chapter, refer to the figures in the control panel shown in the Operator Interface warnIngs on use Š Always keep the use and maintenance manual handy. Š During service, refrain from any action that raises doubts about safety. danger! Do not remove the stove protections. -
Page 29: Stove Start-Up
Stove status display when idle Clock Room temperature Figure 6.1 Dialogue Power stove start-up To turn the stove on, press the 4 button for 3 seconds. The stove will automatically initiate all of the ignition procedures until it reaches the Work state (see Figure 6.2). Stove status display when working Clock Room temperature... -
Page 30: Maintenance
MaIntenance notes on MaIntenance Inspection and maintenance activities must be performed by specialized technicians who are familiar with the instructions in this manual. Before performing any type of operation, make sure that: Š The power cable is unplugged since the stove could be programmed to start. Š... - Page 31 Remove the flame trap (see Figure 7.2 - A) Š vacuum any residue in the fire pot and surface (see Figure 7.2 - B) Š Remove the fire pot (see Figure 7.2 - C) and make sure the holes are not blocked and that the inner walls of the fire pot do not have any incrustations.Otherwise, clear the holes and remove any residue...
- Page 32 Š vacuum the inside of the fire pot and the fire pot area Š Lower the lid that protects the ash drawer (see Figure (see Figure 7.3 - A) 7.3 - B) Remove the ash drawer below the fire pot and empty it (see vacuum the area below the ash drawer (see Figure 7.3 - D) Figure 7.3 - C) Š...
-
Page 33: Suggestions For Proper Use
1) If used or installed improperly, the pellet stove could cause damage and maximum efficiency is not ensured. 2) OPERA provides the user with all information regarding safe use of the stove in order to avoid injury or damage to property or parts of the stove. -
Page 34: Alarms
alarMs dIsplaY explanatIon resolutIon Occurs when The stove goes into the shut-down state. al01 BlacK out there is no electricity for more Clean the fire pot and restart the stove. than ten seconds. The stove goes into the shut-down state. al02 proBe Occurs when there is a probe You can try to relight it after the shut-down cycle has... -
Page 35: Warranty Conditions
WARRANTY CONDITIONS Opera is a trademark of Dal Zotto S. p. A., located in Via Astico, 67 36030 FARA VICENTINO (Vicenza), guarantees this product for 2 (two) YEARS from purchase date for manufacturer and material faults. The warranty becomes void in case the defect of conformity is not filed with the dealer within two months from date of its finding. - Page 36 Š Masonry work Š The system particulars for the production of domestic hot water not supplied by Dal Zotto S.p.A. (water products only). Š The heat exchanger is excluded from the warranty unless an adequate anti-condensate circuit is realised, which guarantees a minimum return temperature of the appliance of at least 55°C (only water products).
- Page 37 ENGLISH...
- Page 38 ENGLISH...
- Page 39 ENGLISH...
- Page 40 Tel. 0445/300810 - Fax 0445/300372 - opera.info@dalzotto.com - www.operastyle.it Opera is a trademark of Dal Zotto, which reserves the right to make changes to thefeatures and data contained in this document at anytime and without prior notice, in order to improve its products.
