Summary of Contents for Vhedia M Series
- Page 2 VHEDIA M-SERIES User Operation Manual...
- Page 3 C O N T E N T S Notice for users Warning Techy Stuff Reverse Camera Settings Main Interface Operation Connecting to WiFi Bluetooth Operation CarPlay and Android Auto Android App Installation Steering Wheel Control System Settings Radio Operation File Management Split Screen Function DAB+ Radio OBD2 Connection...
- Page 4 Vhedia will bear no responsibility for these expenses. In the event of a return for a faulty item. Vhedia will organise and pay for the return shipping costs and provide a replacement unit and help troubleshoot the issue.
- Page 5 To ensure safety and obey the traffic rules, please do not watch video and operate the unit while driving. Please keep this product away from liquids to avoid electric shock. If liquid or foreign object got inside the head unit, park your car in a safe place, turn the ignition switch off (ACC OFF) immediately, and consult your dealer.
- Page 6 Latest Stable Android Operating System (Head units running on Android is a great way to enhance your car's entertainment system. It allows you to integrate your smartphone, tablet, or other device into your car's audio system. HD Capacitive Touch Screen 1280*720 IPS, Full HD, Full Colour and Anti Reflect MT8667, CA75x2 (2.0GHz)+CA55x6 (1.8GHz) MediaTek 8GB DDR3 Rom &...
- Page 7 - Your reverse camera should start working after the reboot NOTE: If your factory or vhedia reverse camera still doesn't work, make sure that you wired it up correctly. You may use the installation video on our youtube channel depending on your car model...
- Page 8 When you turn on the head unit, it boots into the main interface. You can swipe left or right from the home screen to access other widgets. You can also change the apps from the home screen and customize them based on the apps that you often use.
- Page 9 WIFI SETTINGS - Tap Network & Internet from the System Settings page. Tap WiFi to enter the WiFi Settings page, the system will automatically search for an available network, to connect, simply select the WIFI name, tap it then input the password. The WIFI icon will appear at the top of the notification bar once connected.
- Page 10 CONNECTING BLUETOOTH - To use the bluetooth hands-free feature, you first need to connect your phone and head unit via Bluetooth. You can also connect other devices like OBD2 scan tool etc., 1) Turn on the Bluetooth of your phone. 2) Open the head unit's Bluetooth app and tap the search/magnifying glass icon on the top right corner of the app.
- Page 11 4) After pairing, the head unit and phone will be successfully connected. 4) If you would like to sync your phone contacts to the head unit, tap the contact icon or the person icon from the right menu of the Bluetooth app. From there, tap the download/sync icon and wait for the sync to finish.
- Page 12 BLUETOOTH MUSIC PLAYING- If your mobile phone supports Bluetooth music playing function, open the Music player or app on your phone, play a song and simply tap the Music icon from the Bluetooth interfact to start controlling the music.
- Page 13 Vhedia M Series head unit support Wireless Apple Carplay and Wireless & Wired Android Auto. Here's how you can set it up: WIRELESS CARPLAY - Make sure that the iPhone and Headunit are connected via Bluetooth (refer to page 10). Once connected, open the Auto Link app from the head unit and wait for the wireless carplay to connect.
- Page 14 WIRED ANDROID AUTO - Plug your android phone cable to your phone and the head unit's USB port. Once done, you will see an android auto notification on your android phone, tap on it and allow the phone to connect to Android Auto After tapping CONNECT, open the AutoLink app on the head unit and wait for the Anroid Auto to connect...
-
Page 15: Option 1: Google Play Store
One best feature Vhedia head unit has is that it runs Android operating system. That means, you can install android apps on it like you would on a normal android phone. There are two options how to install apps on your head unit OPTION 1: GOOGLE PLAY STORE Open PlayStore from the app menu and look for an app that you would like to install. - Page 16 You can also update the apps installed on the head unit by opening playstore and tap on your profile icon > then tap on manage apps and device. Tap on Update All if you would like to update all available updates or tap See Details to update the apps manually or select app that you only want to update.
- Page 17 STEERING WHEEL CONTROL LEARNING - The steering wheel controls of the head unit are appropriate for the original car steering wheel controls. Please note that if your head unit has a CANBUS, you may not need to learn the steering wheel control. Tap the SWC icon on the system setting interface to enter the steering wheel buttons setting interface, as in the shown picture: To set/assign functions of steering wheel buttons, tap the function you want from...
- Page 18 Touch the Gear/Settings icon gear on the main interface/home screen to enter the Settings screen. WIFI SETTINGS - Tap Network & Internet from the System Settings page. Tap WiFi to enter the WiFi Settings page, the system will automatically search for an available network, to connect, simply select the WIFI name, click it then input the password.
- Page 19 APPS & NOTIFICATIONS -Allows you to personalise or change notifications for apps, default apps used on the head unit, allows you to manage app permission, clear app cache, and uninstall apps. STORAGE - Allows you to manage your internet and extenal (optional) storage. Give you an option to free up some space, shows you how much storage has been used, allows you to turn on and off storage manager which you can remove older photos and videos etc.
- Page 20 Tap the Radio widget on the homescreen or the Radio app from the apps to open the head unit's radio. Tap the FM icon to choose FM frequency as you like from P1, P2, P3, P4, P5, P6. Tap the AM icon to choose AM frequency as you like from AM1, AM2. MANUAL STATION SEARCH - Tap the |<...
- Page 21 ST FOR STEREO/MONO CONVERSION - FM radio signal is stronger at the center of the city, usually receive in a stereo way. However in the remote area, the radio signal is not stable, you can switch to mono mode to improve the signal of the radio.
- Page 22 Search FileExplorer from the head unit's app menu Tap the ✔ the icon to select a file/s. Tap the copy icon to copy a file/s. ㊢ Tap the paste icon to paste the copied file/s. Tap the trash icon to delete files NOTE: You can copy and paste files from internal storage to the external one or vice-versa.
- Page 23 You can switch and run two apps on the head unit's screen side by side. So go ahead listen to music through your favorite app whilst navigating, or make a phone call with your browser open. Simply tap the open apps icon from the top-right screen (beside the back touch icon).
- Page 24 With using of a DAB+ USB (sold separately), the DAB+ (Digital audio broadcasting) tuner lets you enjoy the convenience of digital radio as Auto DAB+ Tuning makes sure there are fewer signal interruptions. DAB+ digital radio brings you high-detail, digital-quality sound with lots of stations, program information, and more. If you purchased DAB+ USB, you will have a stick-on antenna which you need to stick to your windshield, run the wires through your side trims, all the way down to your glove box.
- Page 25 All Vhedia head units come with a free OBD2 Scan Tool which you can connect to the head unit and access car info, and troubleshoot codes directly from there. First, plug in the OBD2 Scan Tool on your car's OBD2 port. This is normally located under the dashboard, beneath the steering wheel column above the pedals.
- Page 26 From the CAR SCANNER app, tap Settings on the top-right corner > then tap Connection > Select Bluetooth > Tap Select Device > Tap on OBD II After that, tap on CHOOSE CONNECTION PROFILE and search for your car model. But normally, OBD II universal works on almost all cars.
- Page 27 The car scanner app will then start connecting to the OBD2 and car's ECU Once done with the connection, you can start accessing options like Dashboard, Diagnostic Trouble Codes, etc., whichever info you need on the car...
- Page 28 Vhedia M Series Head Unit has a built-in 4G module which helps the head unit work like a phone of its own by putting in a SIM card on the 4G antenna. You would need this feature if you'd like your head unit to have its own internet connection (via a simcard cellular data).
- Page 29 If you have problems operating the head unit, please refer to this basic troubleshooting guide for a quick solution. If the problem still exists or not that confident, kindly reach out to us via phone, chat, or email and our lovely techs will assist you with your concerns The most common problems are listed below, along with likely causes and solutions.
-
Page 30: Poor Radio Reception
FROZEN UP OR RUNNING SLOW Close unused apps. Tap the open apps icon located beside the back icon on the top-right corner of the screen and close all apps that you're not using. Try rebooting the head unit. Just like other gadgets with processors, it accumulates system cache over time. -
Page 31: No Gps Signal
NO GPS SIGNAL Make sure that the GPS antenna is securely plugged in at the back of the head unit Do not put the GPS antenna together with other antennas, meaning the wires of other antennas should not be tangled up with the wires of the GPS antenna as it may cause signal interference.
