Meyer Drive Pro 41200 Assembly And Installation Manual

Plow with e-58h 12v hydraulic uniе
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Form No. 1-1052
March 2012
EZ Build Assembly and Installation
EZ Build Assembly and Installation
41141200 Drive Pro Plow 7'-6" with E-58H 12V Hydraulic Unit
41200 Drive Pro Plow 7'-6" with E-58H 12V Hydraulic Unit
and
and
41250 Drive Pro Plow 7'-6" with E-72 12V Hydraulic Unit
41250 Drive Pro Plow 7'-6" with E-72 12V Hydraulic Unit
Meyer Products LLC reserves the right, under its continuing product
Meyer Products LLC
improvement program, to change construction or design details,
18513 Euclid Ave. • Cleveland, Ohio 44112-1084
specifications and prices without notice or without incurring any obligation.
Phone 216-486-1313
www.meyerproducts.com• email info@meyerproducts.com
© 2012 Printed in the U.S.A.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Drive Pro 41200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Meyer Drive Pro 41200

Summary of Contents for Meyer Drive Pro 41200

  • Page 1 41250 Drive Pro Plow 7’-6” with E-72 12V Hydraulic Unit 41250 Drive Pro Plow 7’-6” with E-72 12V Hydraulic Unit Meyer Products LLC reserves the right, under its continuing product Meyer Products LLC improvement program, to change construction or design details, 18513 Euclid Ave.

  • Page 2: Table Of Contents

    4. The vehicle must be equipped with a “Heavy Duty Battery” (70 Amp, Hr. Min.), 550 C.C.A. and “Alternator” (60 Amp. Min.) to obtain maximum performance. 5. Follow these instructions explicitly. Warranty does not apply to a Meyer product which has been negligently or improperly assembled or installed.

  • Page 3: Illustrated Parts Lists

    • Hose 1/4 x 22” Parts indented are included in the carton, bag or assembly under which they are indented. Meyer Products LLC reserves the right, under its continuing product improvement program, to change construction or design details, specifications and prices without notice or without incurring any obligation.
  • Page 4 41200 E-58H and 41250 E-72 Assembly 41250 E-72 41200 E-58H Specific Components Specific Components 56 58...
  • Page 5 • Flatwasher 3/8 Parts indented are included in the assembly under which they are indented. Meyer Products LLC reserves the right, under its continuing product improvement program, to change construction or design details, specifications and prices without notice or without incurring any obligation.

  • Page 6: Attaching Plow To Ez Build Assembly

    Attaching Plow to EZ Build Assembly A. Attach L.H. and R.H. Light Brackets (46 & 47) to the side plates of Lift Frame (12) in Note: Proper tension is attained when Trip Spring (35) coils just begin to separate and the upper two holes using 5/16”-18 x 1-1/4” bolts (55), 5/16” lockwashers (56), and then tightening top locknut four additional turns. Tighten bottom Locknut (20530) 5/16”-18 hex nuts (58).

  • Page 7: Vehicle Side Wiring Diagram

    Check snow plow light blinkers to make sure the wires have not been reversed. and are not spongy. Note: All electrical connections should have both ends coated with a dielectric c. Top off the unit to the fill line on the reservoir with Meyer M-1 Hydraulic Fluid. grease, Meyer Part No. 15632, prior to final installation. This will ensure a good NOTE: Proper fluid level is to the fill line on the reservoir for the E-72 or 1” below connection and help in preventing corrosion.

  • Page 8: Drop Speed Adjustment

    L. Refer to Operation and Maintenance Manual for complete controller operation. N. A ssemb le a djust abl e sta ckin g sto p bo lts to l ift fra me (12) us i ng 5/8-11 x 3” bolts (61), lockwasher (24) and jamnuts (62). See below. M.

  • Page 9: Mount Plow System To Vehicle

    G. Remove weather cover on male end and connect one piece electrical plug. The spring loaded cover will lock one piece plug. Meyer Products assumes no responsibility for installations not made in accordance with these instructions.

  • Page 10: Dis-Mount Plow System From Vehicle

    C. Remove crankstand from lift frame. G. Disconnect one piece electrical plug and install weather cover on male end. D. Attach crankstand to a-frame H. Back vehicle away from plow assembly. Meyer Products assumes no responsibility for installations not made in accordance with these instructions.

  • Page 11: Pre-Delivery Inspection

    PRE-DELIVERY INSPECTION Vehicle Make: Vehicle Model: Vehicle Year: Vehicle VIN#: Vehicle FGAWR: Installing Company: Mounting Type: Plow Type: EZ Plus Hydraulic Serial Number: Moldboard Serial Number: All bolts torqued to specification Plow Operation Up Clevis height Suspension interference Plow Operation Left Clevis height in inches Plow Operation Right Diode Installed...

  • Page 12: Accessories

    16529 Optional Light Guards Meyer 16536 (‘99-07 Ford) Winch Cradle 16537 (‘99 + Chevy) 16539 (‘99 + Dodge) Meyer Products LLC 18513 Euclid Ave. • Cleveland, Ohio 44112-1084 Phone 216-486-1313 (11) www.meyerproducts.com• email info@meyerproducts.com © 2012 Printed in the U.S.A.
