Meyer Lot Pro 41300 Assembly And Installation Manual

Plow with e-58h 12v hydraulic unit and plow with e-72 12v hydraulic unit
Hide thumbs
Table of Contents

Advertisement

Quick Links

Form No. 1-1054
March 2012
EZ Build Assembly and Installation
41300 Lot Pro Plow with E-58H 12V Hydraulic Unit and
41350 Lot Pro Plow with E-72 12V Hydraulic Unit
Meyer Products LLC reserves the right, under its continuing product
improvement program, to change construction or design details,
Meyer Products LLC
specifications and prices without notice or without incurring any obligation.
18513 Euclid Ave. • Cleveland, Ohio 44112-1084
Phone 216-486-1313
© 2012 Printed in the U.S.A.
www.meyerproducts.com• email info@meyerproducts.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Lot Pro 41300 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Meyer Lot Pro 41300

Summary of Contents for Meyer Lot Pro 41300

  • Page 1 41300 Lot Pro Plow with E-58H 12V Hydraulic Unit and 41350 Lot Pro Plow with E-72 12V Hydraulic Unit Meyer Products LLC reserves the right, under its continuing product improvement program, to change construction or design details, Meyer Products LLC specifications and prices without notice or without incurring any obligation.

  • Page 2: Table Of Contents

    4. The vehicle must be equipped with a “Heavy Duty Battery” (70 Amp, Hr. Min.), 550 C.C.A. and “Alternator” (60 Amp. Min.) to obtain maximum performance. 5. Follow these instructions explicitly. Warranty does not apply to a Meyer product which has been negligently or improperly assembled or installed.

  • Page 3: Illustrated Parts Lists

    • Hose 1/4 x 22” Parts indented are included in the carton, bag or assembly under which they are indented. Meyer Products LLC reserves the right, under its continuing product improvement program, to change construction or design details, specifications and prices without notice or without incurring any obligation.
  • Page 4 41300 E-58H and 41350 E-72 Assembly 41350 E-72 41300 E-58H Specific Components Specific Components 57 59...
  • Page 5 10 • Flatwasher 3/8” Parts indented are included in the assembly under which they are indented. Meyer Products LLC reserves the right, under its continuing product improvement program, to change construction or design details, specifications and prices without notice or without incurring any obligation.

  • Page 6: Attaching Plow To Ez Build Assembly

    Attaching Plow to EZ Build Assembly Attach L.H. and R.H. Light Brackets (47 & 48) to the side plates of Lift Frame 07031 (12) in the upper two holes using 5/16”-18 x 1-1/4” bolts (56), 5/16” lockwashers (57), and 5/16”-18 hex nuts (59). Note: Light brackets may be adjusted down two 20309 levels in height for better appearance on lower profile vehicles.

  • Page 7: Vehicle Side Wiring Diagram

    Operate the Angle cylinders (2) until they are filled with Meyer M-1 Hydraulic Fluid and are not spongy. Top off the unit to the fill line on the reservoir with Meyer M-1 Hydraulic Fluid. (S) terminal white wire (I) terminal black wire w/white stripe NOTE: Proper fluid level is to the fill line on the reservoir for the E-72 or 1”...

  • Page 8: Drop Speed Adjustment

    Check snow plow light blinkers to make sure the wires have not been reversed. Note: All electrical connections should have both ends coated with a dielectric grease, Meyer Part No. 15632, prior to final installation. This will ensure a good connection and help in preventing corrosion.

  • Page 9: Mount Plow System To Vehicle

    G. Remove weather cover on male end and connect one piece electrical plug. The spring loaded cover will lock one piece plug. Meyer Products assumes no responsibility for installations not made in accordance with these instructions.

  • Page 10: Dis-Mount Plow System From Vehicle

    C. Remove crankstand from lift frame. plug and install weather cover on male end. D. Attach crankstand to a-frame H. Back vehicle away from plow assembly. Meyer Products assumes no responsibility for installations not made in accordance with these instructions.

  • Page 11: Pre-Delivery Inspection

    PRE-DELIVERY INSPECTION Vehicle Make: Vehicle Model: Vehicle Year: Vehicle VIN#: Vehicle FGAWR: Installing Company: Mounting Type: Plow Type: EZ Plus Hydraulic Serial Number: Moldboard Serial Number: All bolts torqued to specification Plow Operation Up Clevis height Plow Operation Left Suspension interference Clevis height in inches Plow Operation Right Plow Operation Down...

  • Page 12: Accessories

    16529 Optional Light Guards Meyer 16536 (‘99-07 Ford) Winch Cradle 16537 (‘99 + Chevy) 16539 (‘99 + Dodge) Meyer Products LLC 18513 Euclid Ave. • Cleveland, Ohio 44112-1084 Phone 216-486-1313 www.meyerproducts.com• email info@meyerproducts.com © 2012 Printed in the U.S.A. (11)

This manual is also suitable for:

Lot pro 41350
