Sharp PC-MV10 Series Quick Setup Manual

PC-MV10 Series Quick Setup Guide
Thank you for your purchasing a SHARP PC-MV10 Series personal computer.
Follow the instructions below to use the computer for the first time.
1.
Be sure to check all the following items are included:
• Notebook Computer
• AC Adapter
• AC Power Cord
• Battery Pack
• Modem Cable
• Core for a LAN cable
• Parallel Cable Adapter
• Weight Saver
• Recovery CD-ROMs Pack
• Windows Quick Start Guide
• Operation Manual
2.
Install the battery pack into the
computer.
1. Place the computer upside down.
2. Insert the battery pack into the computer by
matching the projected parts of the battery to the
notched parts on the computer.
3. Push the battery pack until you hear the clicking
sound.
Carefully inspect each component to make sure nothing is
missing or damaged. If any of these items is missing or
damaged, notify your dealer immediately. Be sure to save the
shipping materials and carton in case you need to ship or store
the computer in the future.
Attach the included core to your LAN cable to insure
compliance with requirements of EMC regulations for
computing equipment.
Some brochures or supplements may be contained other than
the above.
3.
Connect the computer to AC power.
1. Plug the AC adapter cable to the AC adapter jack
on the left side of your computer.
2. Plug the AC power cord into the AC adapter.
3. Plug the AC power cord into a wall outlet.
Projected Part
AC Adapter Jack
Notched Part
• Always use the AC adapter included with the computeror
the optional one (may not be available in some countries).
Using other AC adapters may damage the compute.
• Always hold the AC power cord by its plug when removing
it from the wall outlet. Never pull on the cord.
• When using the computer for the first time, be sure to
connect it to AC power. If using the battery instead, you
may not be able to complete the Windows setup if the
battery does not have enough power.
AC Adapter
AC Power Cord
To Wall
Outlet
Please turn over and
go to the next section
2
TINSE3424ACZZ
