Summary of Contents for Pacifica IZL106
- Page 1 Island Hood IZL106...
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION **Read the complete manual carefully before installation** Intended for Domestic Kitchen Use Only Warnings: TO REDUCE THE RISK OF FIRE, ELECTRICAL SHOCK OR PERSONAL INJURY, PLEASE OBSERVE THE FOL-LOWING: Installation and electrical work must be done by a qualified person in accordance with all ap-plicable codes and standards If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or a similarly qualified person to avoid a hazard. - Page 3 CAUTION To reduce the risk of fire and to properly exhaust air, be sure to duct air outside. Do not vent exhaust air into spaces within walls or ceiling or into attics, crawl spaces or garages. Take care when using cleaning agents or detergents. Avoid using food products that produce flames under the range hood.
-
Page 4: Installation Instructions
INSTALLATION INSTRUCTIONS Before You Start... 1. Read this manual carefully and completely. 2. The range hoods conform to related appliances standards. Please check your local building codes for any additional requirements. 3. The appliance has been manufactured as class I, there-fore ground connection is necessary. - Page 5 Installing the Ductwork 1. Plan where the ductwork will run between the hood toroof c ap and the outside. The hoods exhaust vertically but can be ducted to the rear behind the chimney duct through an outside wall or vertically up through the ceiling to the roof.
- Page 6 Installing Guideline Wall Mounted Island hood step 1 Island hood step 2 Island hood step 3 Island hood step 4 Note: The above installation guideline for references only, please contact local dealer for installation service.
-
Page 7: Installation Alternatives
Leveling Device When mounting hood on the wall,the level can be adjusted by turning the two screws on the motor housing. INSTALLATION ALTERNATIVES The cooker hood can be installed in the following ways: Circulating indoor air (A) Outdoor venting (B) REMEMBER! The distance between the top of the hob and the lowest part of the cooker hood must be at least 65 cm. -
Page 8: Description Of The Controls
USE AND CARE INSTRUCTIONS Operations For optimum performance in removing cooking odors, it is recommended that you turn on your range hood prior to cooking and you leave it operating for 15 min-utes after cooking. Clean the surfaces of the range hood regularly using a non-abrasive detergent. - Page 9 B. Touch Control For model COLLIDER For model V.I.P. Remote controller For model AUVRORA ...
- Page 10 Remote controller C. Push button control D. Electric control with LCD screen TIMER DELAY OFF LIGHT ON/OFF MOTOR ON/OFF TIME SETTING LCD SCREEN SET INCREASE SET DECREASE...
-
Page 11: Care And Cleaning
CARE AND CLEANING General Replacing the charcoal filter (standard hood) Regular maintenance is required to ensure that the cooker hood functions properly. This is Replace the charcoal filter (standard espe-cially true of the grease and charcoal hood) as follows: filters. Remove the grease filter. - Page 12 If you clean the grease flter in the dishwasher: load only the grease flter and no other items as food particles from dishes can fasten in the filter. Emptying and cleaning the oil collector (For these hood fitted with oil collector) The fan is fitted with a oil collector that collects oil from the fan blades and fan housing.
- Page 13 Halogen and LED Lights. With the grease filter removed, from inside the hood press the light fixture out of its mounting bracket. Unplug the light from the wiring harness. Avoid direct contact between the lense and your hands. Replace the damaged lamp by reversing the steps. Snap in place. Replace the bulbs as follows: Lift up and remove the light fitting with a screwdriver or other suitable tool.
- Page 14 Hood Size: 600/700/800/900 3 19 3 19 5 10 5 20 9 00 7 00 4 00 4 00 9 00...
-
Page 15: Troubleshooting Guide
Trouble Shooting Guide Problem Possible Reason Solution No electrical supply. Check the plug is connect-ed. Hood doesn't turn on. Check the plug is connect-ed. Power cord is damaged Contact technician service Aluminum grease filters Clean the filters and replace clogged when dry. - Page 16 Menara Lien Hoe (HQ) Lot 11.3, 11th Floor, Menara Lien Hoe, 8, Persiaran Tropicana, 47410 Petaling Jaya, Selangor.
