- Page 1 INNOVATIVE PARTS CART PANEL TRAIN PN: R1150 RHINOMOTIVE LTD - UK 71-75 Shelton Street, London, United Kingdom Scan QR Code www.rhinomotive.com...
-
Page 2: Technical Specifications
• Box 1 + Box 2 includes: • 3 shelves • 2pcs 600mm arms • o 6 “S” shape hooks • 6 x 4inch Pu Castors (Two Swivel with Brake) • Weight: 41.5 Kg • Maximum Load Capacity: 150 Kg • Made in PRC www.rhinomotive.com... -
Page 3: Parts List
Vertical Support Bar with Foam Support Arm Buckle with Knob Base Tube Back Base Tube Support Arm with Holes (L) L-shape Connectors Support Arm with Holes (R) Bolt (M10x50) Mesh Shelf Lock Nut (Ø10) Bolt (M8x50) Pin (M8x50) 5. PARTS BREAKDOWN www.rhinomotive.com www.rhinomotive.com... - Page 4 6. ASSEMBLY INSTRUCTIONS 1) Install wheels. No washer required. 2) Remove rear wheel caster nut from cart and discard lock washer. 3) Install Leg Connector, noting direction as shown. www.rhinomotive.com...
- Page 5 5) Install protective rubber cap. Adhesive can be used to better keep rubber cap in place 6) Center the post holder on back side of cart. Tighten knobs. Posts shown above in stored position. RHINOMOTIVE LTD - UK 71-75 Shelton Street, London, United Kingdom Scan QR Code www.rhinomotive.com...
