- Page 1 Installation Guide Model: NG-D2310 Series Lock Body: American Deadbolt Version: 1.0 English...
-
Page 2: Table Of Contents
Important Notes Please read this Installation Guide carefully and contact the Customer Care for any installation queries. It is recommended that installation be carried out by a professional technician to prevent any potential service charges that can occur due to incorrect installation. Four alkaline AA batteries (not included) are required to power on the device. -
Page 3: What's In The Box
What's in the Box Outdoor Assembly Indoor Assembly Mounting Plate Deadbolt Strike Plate and Box Studs Manual Screw C Double-sided Tape Keys Mounting Plate (optional) User Files Screw D Screw E Screws A Screws B Indoor Assembly Plug Deadbolt/Strike Mounting Plate Note: Screws for doors with a thickness of 35 to 55 mm are included in the standard package. -
Page 4: Installation Diagram
Installation Diagram Battery (not included) Indoor Assembly Screw D Door Mounting Plate Battery Cover Back Cover Screws B Outdoor Plug Assembly Optional Screw E Screws A Deadbolt/Strike Studs Deadbolt Keys Strike Plate and Box Important Note To stabilize the Outdoor Assembly, you can use either the provided Double-sided Tape or Stud. -
Page 5: Drill Holes On The Door
Diameter of Cross Bore: 55 mm Door Thickness: Diameter of 35 to 55 mm Door Hole: 25 mm *Drill Holes on the Door Place the Installation Template at the desired Cylinder height. Mark for the holes to be drilled and drill the marked places. Door thickness 35 to 55mm Center line of the Cylinder... -
Page 6: Install The Deadbolt
Install the Deadbolt Adjust the Deadbolt (if needed) Backset is the distance from the edge of the door to the center of the hole drilled on the door. The default Backset is 60mm, but if you want to change the Backset to 70mm, grasp body and twist the Faceplate as shown below: Press the Bolt inside the Latch Rotate the Faceplate... -
Page 7: Install The Strike Plate And Box
Install the Strike Plate and Box Make sure that the Strike Box is aligned with the Deadbolt. Then, use the Installation Template to drill holes. Align the Strike Plate and Box with the drilled holes and fix them with Screws A. Depth 2(MM) (10/127 “) 27(MM) -
Page 8: Install The Mounting Plate
v Method 2: Installation with Double-sided Tape Remove the double-sided tape from the outdoor assembly's mounting plate. Make sure that the highlighted Spindle is in the horizontal position, as shown below. Route the cable through the opening below the bolt. Attach the Outdoor Assembly to the door by inserting the cable through the drilled holes. -
Page 9: Install The Indoor Assembly
v Method 2: Installation with Double-sided Tape Insert the cable through the Mounting Plate's hole. Install the Mounting Plate on the door and fasten it with Screws B and Screw C. Screws B Screw C Install the Indoor Assembly Connect the cable to the port on the back of Indoor Assembly. Install the Indoor Assembly on the Mounting Plate in the proper location. -
Page 10: Physical Testing
Physical Testing Rotate the Knob to check if the Deadbolt works properly. Insert the Key and rotate to check if the Deadbolt works properly. Note: If the Knob or Key cannot control the Deadbolt correctly, please read the Installation Procedure carefully and re-install the lock. Install the Batteries and Cover Insert four Alkaline AA batteries into the lock and cover them with the battery cover. - Page 11 User Manual Model: NG-D2310 Series Version: 1.0 English...
- Page 12 final interpretation and modification concerning this point. After unlock by APP, fingerprint or password, please do not verify again. NGTeco could not guarantee the exact consistency between the real product and the stated information in this handbook due to constant system and product modifications..
- Page 13 Table of Contents...
- Page 14 Note: The first and second registers will be set as administrators by default, and the first administrator must be password. The Owner is the person who owns the lock, and registers in NGTeco Home App, and has all the privileges.
- Page 15 Search the “NGTeco Home” App in Apple App Store or Google Play Store and download the App to your mobile phone. Open the “NGTeco Home” App and log in with your account. If you do not have an account, create an account with your phone number or Email ID.
- Page 16 (within 10 meters without any obstacle). Program the Features on the Lock It is recommended to use the NGTeco Home App to manage your lock. If you don't have a smartphone or don't want to use the App, you can use the following programming instructions.
- Page 17 Calibrate Enter 7 and verify administrator to calibrate automatically lock in Automatically some situation that the door lock does not automatically lock. Lock Basic Operations Unlock the Door with Fingerprint Press the registered Push the door or fingerprint on the rotate the handle fingerprint sensor down to open...
- Page 18 Warning: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
- Page 19 1600 Union Hill Road Alpharetta, GA 30005 E-mail: service.ng@ngteco.com www.ngteco.com Copyright©2022 NGTECO CO., LIMITED. All rights reserved.
