Summary of Contents for Senal AWS-24G
- Page 1 AWS-24G USER’S GUIDE DUAL 2.4 GHz WIRELESS MICROPHONE SYSTEM...
- Page 3 Thank you for choosing Senal. The Senal AWS-24G Advanced Wireless Microphone System delivers accurate and high-quality 48 kHz audio for two-person shoots, interviews, and broadcasts. Two transmitters can be deployed with a single receiver to capture dialog and interviews from 300 feet away. The transmitters are designed for simple, trouble-free operation, so just turn them on and start recording.
- Page 4 Use only the correct, recommended voltage. • Do not attempt to disassemble or repair the equipment—doing so will void the warranty, and Senal will not be responsible for any damage. • Clean the units with only a soft, dry cloth.
- Page 5 Overview A W S -2 4 A W S -2 4 Transmitter (×2) Receiver Charging Case Lavalier Microphones with Removeable Tie Clips (×2) Fuzzy Wind Muffs (×2) 3.5 mm TRS-TRS Audio Cable 3.5 mm TRS-TRRS Audio Cable 3-in-1 Charging/Audio Output Cable ▪...
- Page 6 Overview - Transmitter (TX) External Mic Port (3.5 mm TRS) A W S -2 4 Antenna Location ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪...
- Page 7 Screen Display - Transmitter (TX) Microphone Active Flashing: Recording A/B Channel Is Connected A/B Channel Is Not Connected ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪...
- Page 8 Overview - Receiver (RX) Headphone Output A W S -2 4 A-Channel Output Gain Control Button B-Channel Output Gain Control Button Power/Mode Button Antenna Location ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪...
- Page 9 Screen Display - Receiver (RX) Meter ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪...
-
Page 10: Charging Case
Charging LEDs Charging Case Place the receiver into the RX charging slot, and the transmitters into the TX charging slots. Use the 3-in-1 cable to connect the charging case’s USB-C port to a USB-A power source. The power indicator lights will blink sequentially to indicate the units are charging. ▪... - Page 11 Power options include a powered computer port, USB charging hub, or an AC adapter. When the case is open during charging, the receiver displays the charging level of each device. Each bar indicates approximately 25% of the unit’s power. If the device cannot be charged, reset the device by inserting the included pin into the reset hole.
- Page 12 A. The second transmitter will send its signal to channel B. AWS-24G Transmitters (TX) If the transmitter is disconnected, re-pair it to the receiver by pressing and holding the Pair button.
- Page 13 Operating the Transmitter (TX) The transmitters have a line-of-sight operating range of 300 feet. By default, the internal microphone is active when the transmitter is powered on. Plug a lavalier microphone into the external mic port to activate it and mute the internal microphone.
- Page 14 Wind Muff When recording outdoors in a light breeze, the wind muffs will minimize wind noise for a cleaner recording. Insert the wind muff’s tabs into the transmitter’s locking buckle. Turn the wind muff clockwise to lock it into place. A W S -2 4 A W S -2 4 A W S -2 4...
- Page 15 Recording The recording feature on the transmitters allows you to record your vocals or speech, and download it via the USB-C port to a computer or other device. The transmitter saves a 48 kHz / 16-bit WAV file up to 8 GB. For continuous recording, the transmitter will create a new WAV file every two hours.
-
Page 16: Operating Modes
Operating the Receiver (RX) Operating Modes Mono: Sums the signal of receiver channels A and B, and outputs the combined signal to your recording device. Stereo: Separates the signals on channels A and B, outputs discretely to separate channels on your recording device. Safety: Outputs two mono tracks. -
Page 17: Analog Audio Output
Analog Audio Output Use the 3.5 mm TRS to TRS cable to connect the receiver’s output jack to a camera. Use the 3.5 mm TRS to TRRS cable to connect the receiver’s output jack to a smartphone or a computer. Plug headphones into the headphone jack to monitor the audio. -
Page 18: Digital Audio Output
Digital Audio Output Use the 3-in-1 audio cable, plus the necessary plug adapters (not included), to connect the receiver to a smartphone, tablet, or computer, and record your audio. AWS-24G ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪... -
Page 19: Specifications
Specifications System Microphone Wireless Technology Microphone Type Wireless 2.4 GHz Lavalier Included Transmitters Bodypack with microphone (×2) Sound Field Mono Max Operating Range Operating Principle Pressure Operated 300 ft. (91.4 m) line of sight Built-In Recorder Polar Pattern Omnidirectional Yes (8 GB ×2) Timecode Support Frequency Range 80 Hz to 20 kHz... - Page 20 Receiver Receiver Type Beltpack Wireless Frequency 2400 to 2483 MHz Transmitting Power +10 dBm Sensitivity -86 dBm >70 dB Latency <20 ms Mounting Options Belt clip Antenna PCB internal Number of Audio Channels Audio I/O 1/8 in. (3.5 mm) TRS female unbalanced mic output Gain Range -12 to +12 dB (2 dB increments) USB/Lightning Connectivity...
- Page 21 Transmitter Transmitter Transmitter Type Battery Type Bodypack with microphone Built-in rechargeable Wireless Frequency 2400 to 2483 MHz Approx Battery Life 5 Hours (Normal Recording Mode) 3.5 Hours (On-board Recording Mode) Sensitivity -86 dBm Recording Time 24 hr. >70 dB USB/Lightning I/O USB Type-C (data, charging) Frequency Response 80 Hz to 20 kHz Analog I/O...
-
Page 22: Troubleshooting
Change the receiver’s operating mode to Stereo. recording on separate channels. • My app is not recording sound Make sure the AWS-24G is selected as the microphone in the app’s settings. from the receiver. • The audio quality is not good Make sure the transmitters and receiver have line-of-sight contact. -
Page 23: One-Year Limited Warranty
One-Year Limited Warranty This Senal product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later. The warranty provider’s responsibility with respect to this limited warranty shall be limited solely to repair or replacement, at the provider’s discretion, of any product that fails during normal use of this product in its... - Page 24 w w w. s e n a l s o u n d . co m...
