Operating Instructions
Universal Explosion Proof LED Lighting
Model THT-L1219
Top Hi-Tech Co., Ltd.
5F., No. 113, Zhongcheng Rd.,
Tucheng District,
New Taipei City, 236 Taiwan
Website:
www.tht-ex.com
Contents
General Safety Instructions ..................................................................................................1
1.
Intended Field of Application ...............................................................................................1
2.
Technical Data ..................................................................................................................2
3.
Model Code ....................................................................................................................2
4.
Dimension .......................................................................................................................2
5.
Assembly And Installation ........................................................................................................3
6.
Maintenance ...................................................................................................................4
7.
Accessories And Spare Parts .................................................................................................4
8.
Transport, Storage And Disposal ............................................................................................4
9.
General Safety Instructions
1.
This manual contains basic safety instructions to be observed during installation, operation and
maintenance of the apparatus, and for properly and safety run of the apparatus according to its
performance data. Any damage of the apparatus may result explosion protection null and void. This manual
represents the most relevant information about the product, applicable codes and regulations shall
supplement it. Non-observance will endanger persons, plant and the environment. The person in charge is
required to secure its employment in the industrial unit. Any improper usage, as well as non-compliance
with the rules under this manual, shall release the manufacturer's all responsibilities.
1.1 Before assembly/commissioning:
Read through the operating instructions.
Give adequate training to the assembly and
operating personnel.
Ensure that the contents of the operating
instructions are fully understood by the
personnel in charge.
The national installation and assembly
regulations (e.g. IEC/EN 60079-14) apply.
Intended Field of Application
2.
The Universal Explosion Proof LED Lighting, Model THT-L1219 is intended for using in gas explosive
atmospheres (Zone 1 and Zone 2 according to IEC60079-10-1) and dust explosion hazards (Zone 21 and Zone
22 according to IEC60079-10-2). The use in other potentially explosive atmospheres does not correspond to the
designated use and is therefore not allowed.
The apparatus is designed for using in indoor and outdoor environments.
TEL: +886 2 22689570
FAX: +886 2 22689571
e-mail: sales@tht-ex.com
Revision: EX-L1219-01
Subject to alterations.
WARNING
1.2 When operating the device:
1
Ensure the operating instructions are made
available for the person in charge on
location at all times.
Observe these instructions, other working
instructions and national safety regulations.
Verify the implementation of safety
instructions.
Advertisement
Table of Contents
Related Manuals for THT-EX THT-L1219
Summary of Contents for THT-EX THT-L1219
- Page 1 (e.g. IEC/EN 60079-14) apply. Intended Field of Application The Universal Explosion Proof LED Lighting, Model THT-L1219 is intended for using in gas explosive atmospheres (Zone 1 and Zone 2 according to IEC60079-10-1) and dust explosion hazards (Zone 21 and Zone 22 according to IEC60079-10-2).
- Page 2 9.4kg 9.6kg Model Code 4.1 L1219A 1219 THT-EX (1) Brand name. (2) Series designation, 1219=L1219 series. (3) C.C.T., C=Cool white, W=Warm white, R=Red light, G=Green light. (4) Voltage, A=24Vac, B=100Vac, C=110Vac, D=200Vac, E=220Vac, F=120Vac, G=208Vac. (5) Type of LED carrier, S=Short Cylinder.
- Page 3 4.2 L1219B 1219 THT-EX (1) Brand name (2) Series designation, 1219=L1219 series. (3) C.C.T., C=Cool white, W=Warm white. (4) Voltage, A=24Vac, B=100Vac, C=110Vac, D=200Vac, E=220Vac, F=120Vac, G=208Vac. (5) Type of LED carrier, C=Cylinder. (6) Type of Top Cover, A=Tall type (L1105T), B=Short type (L1105S).
- Page 4 Dimensions (All Dimensions in mm) – Subject to Alterations Tall Top Cover Type Short Top Cover Type Assembly and Installation 6.1 Electrical Connection Overview A: Top Cover B: M6 Screw×4 1: Sleeve 2: O-Ring 3: Connector (G 3/4”) 4: Pressure nut 5: Washer 6: Tube 7: Washer...
- Page 5 Orderly assemble the O-ring (8), Washers (7) & (5) and Tube (6), and Screw tighten Pressure nut (4) with the Body of Cable Gland by appropriate tool, 600 kgf-cm. Screw and tighten the M4 Socket Set Screw (13), 24.5 kgf-cm. ...
- Page 6 Step 5 Step 6 Put the parts that are worn by the cable as described in Press the Nut Plate against the cable and use M4 the Step 2 into the Cable Gland, then clockwise screw screws to fix the Pressure Nut with cable. Use a M4 the "Pressure Nut"...
- Page 7 Ceiling Mount Bracket 6.2.2 The mount bracket is for the use of ceiling mount (Figure 3). Position the bracket holders and fix it by means of the provided M6 screws, 24.5 kgf-cm. Secure the wall mounting bracket to the structure Figure 3 by using four fasteners M8/SUS316, not...
- Page 8 Screws of the mounting bracket are tightened. Accessories and Spare Parts WARNING Use only original THT-EX accessories and spare parts. For accessories and spare parts, see data sheet at www.tht-ex.com. Transport, Storage and Disposal Transport and storage is only allowed in the original packaging, on the way pointed out on the carton box.
